▶ EngineEngine Manufacturer John Deere John Deere Engine Model PowerTech 3-cylinder (2.9 L) EWX PowerTech 3029 (2.9L) EWR Engine Type Diesel, turbocharged, aftercooled Diesel, turbocharged No. of Cylinders 3 3 Displacement 177 in³ 179 in³ Rated Engine Speed 2200 rpm 2100 rpm Engine Power (Gross) 73.8 hp 67.6 hp PTO Power 57.7 hp @ 100 rpm PR/TSS OOS: 55.3 hp; PR/TSS Cab: 53.3 hp; eHydro: 44.5 hp Engine Emissions Constraints Tier 4 Tier 4 Cooling System Type Liquid-cooled (Cool-Gard II coolant) Liquid cooled Air Cleaner Not Published Dry type with safety element Fuel System Not Published Electronically controlled, high-pressure common rail Alternator OOS: 90 A; Cab: 120 A 110 A ▶ HydraulicsPump Type Tandem gear pump PR/TSS: tandem gear pump (implement + steering); eHydro: three pumps Implement Flow 18.4 gpm 11.4 gpm Steering Flow 6.3 gpm 6.8 gpm Total Hydraulic Flow 24.7 gpm PR/TSS: 18.2 gpm; eHydro: 29.6 gpm Overall Hydraulic Pump Flow 24.7 gpm PR/TSS: 18.2 gpm; eHydro: 29.6 gpm Hydraulic System Type Open center Open Center Rear Remote Hydraulic Flow Not Published 11.4 gpm at a single rear SCV No. of Standard Remote Valves 2 (rear); 2 (mid) 1 No. of Optional Remote Valves Up to 3 total (rear); up to 3 total (mid) Not Published ▶ Fluid CapacityFuel Tank Capacity OOS: 39.2 gal; OOS (High Capacity): 47.1 gal; Cab: 43.7 gal; Cab (High Capacity): 52 gal OOS: 19 gal; Cab: 21 gal Coolant Capacity OOS: 3.6 gal; Cab: 4.2 gal Not Published Crankcase Capacity 2.2 gal 9.0 qt (with filter) Transmission / Hydraulic System Capacity 10.4 gal Not Published Front Axle Fluid Capacity Differential housing (MFWD): 1.3 gal; Wheel hub (each): 0.2 gal DANA: 1.18 gal diff + 0.21 gal per hub; Carraro: 1.03 gal diff + 0.15 gal per side ▶ PTO & HitchPTO Type Independent rear PTO, electro-hydraulic wet disc clutch: 540/540E standard, 540/540E/1000 optional Independent PTO Rear 540/540E rpm standard; 1000 rpm optional 540 rpm (SyncShuttle); 540/540E rpm (PowrReverser) Mid-PTO Availability Not Published Not Published Category, 3-Point Hitch Category II (convertible to I) Category II, convertible to I Hitch Lift Capacity 5,305 lb standard; 6,114 lb optional 3,968 lb Hitch Lift Capacity (at 24”) 5,150 lb standard; 5,950 lb optional 3,192 lb Lift Control Type Mechanical or Electrohydraulic Position control, draft control, adjustable rate of drop ▶ Transmission & DrivetrainTransmission Type PowrReverser 16F/16R (base); optional 32F/16R PowrReverser Hi-Lo SyncShuttle (standard); PowrReverser or eHydro (optional) No. of Speeds 16F/16R (standard PowrReverser); 32F/16R (optional PowrReverser Hi-Lo) 9F/3R (SyncShuttle); 12F/12R (PowrReverser) Max Travel Speed (Forward) 24 mph 15.5 mph (SyncShuttle) Max Travel Speed (Reverse) 16F/16R PowrReverser, top gear D-4: 20.5 mph (30K gearing); 23.9 mph (40K gearing), with 480/70R28 rear tires at 2200 rpm Not Published Clutch Wet SyncShuttle: dry; PowrReverser: wet; eHydro: hydrostatic Differential Lock & Limited Slip Options Electrohydraulic rear differential lock Mechanical, rear ▶ Chassis, Steering & ControlsFrame Type Cast iron mid-frame Not Published Steering Not Published Hydrostatic power steering Brakes Hydraulically actuated wet disc brakes Hydraulically actuated wet disc brakes, self-equalizing and self-adjusting Seat Suspension & Adjustability OOS: isolated mechanical seat standard (fore/aft, weight, lumbar adjust) or air suspension seat optional; Cab: mechanical seat standard or air suspension seat optional; adjustable weight range 88-330 lb Not Published Front Axle Type MFWD 2WD or MFWD Front Axle Rating 6,613 lb max permissible front axle load Not Published Drawbar Capacity Standard drawbar: 2,756 lb; 2,425 lb; 2,205 lb. Heavy-duty drawbar: 3,197 lb; 2,646 lb Adjustable drawbar with interchangeable hitch balls ▶ Dimensions & ManeuverabilityOverall Width Cab, with fender extension: 85.6 in; Cab, without fender extension: 74 in; OOS, with fender extension: 69.1 in; OOS, without fender extension: 51.7 in Not Published Wheelbase 92.5 in 80.7 in Ground Clearance Not Published Not Published Min. Turn Radius without Brakes 13.1 ft 11.5 ft (2WD); 15.3 ft (MFWD) Height to Top of ROPS 102.1 in (with standard rear tires) Not Published Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model 102.9 in (with standard rear tires) Not Published Overall Length 149.5 in (including draft links) 144.5 in ▶ WeightTractor Weight (Base) 2WD OOS: 8,140 lb; 2WD Cab: 8,580 lb; MFWD OOS: 8,765 lb; MFWD Cab: 9,185 lb (approximate ship weight, less weights) 5,555 to 6,812 lb (shipping weight) Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options Not Published Not Published R1 Agricultural - Front 12.4R24 (320/85R24) R1W Radial MFWD: 11.2-24; 12.4-24 R1 Agricultural - Rear 18.4R30 (460/85R30) R1W Radial 16.9-28 R3 Turf - Front Not Published Not Published R3 Turf - Rear Not Published Not Published R4 Industrial - Front Not Published Not Published R4 Industrial - Rear Not Published Not Published ▶ Loader & AttachmentsQuick Attach Loader System Not Published 520M and H240 loaders (Loader Prep Package includes loader mounting frames and hood guard); not compatible with the 512 loader Loader Model 520M (4WD only); 540M NSL; 540M MSL; 540R; 600M NSL; 600M MSL 500E, 500M or 520M Loader Lift Height 520M: 130-132 in; 540M NSL: 137-141 in; 540M MSL: 138-141 in; 540R: 141.85 in; 600M NSL: 148.8-152.8 in; 600M MSL: 148-153 in 500M: 124 in Loader Lift Capacity (Full Height) 520M NSL: 3,335-3,612 lb; 520M MSL: 2,460-2,661 lb; 540M NSL: 2,394-2,666 lb; 540M MSL: 3,117-3,309 lb; 540R: 3,406 lb; 600M NSL: 3,104-3,236 lb; 600M MSL: 3,891-4,085 lb 500M: 3,225 lb (at pivot, full height) Loader Breakout Force 540M NSL: 6,686 lbf; 540M SL: 5,513 lbf; 540R NSL: 4,945 lbf; 540R SL: 5,291 lbf; H310 NSL: 6,767 lbf (measured at pivot; H310 for MFWD tractors) 500M: 4,354 lb (at pivot) ▶ WarrantyWarranty Length & Coverage Not Published Not Published
