▶ EngineEngine Manufacturer John Deere FPT Engine Model PowerTech 3-cylinder (2.9 L) EWX F5C Engine Type Diesel, turbocharged, aftercooled 4-cylinder diesel, turbocharged No. of Cylinders 3 4 Displacement 177 in³ 207 in³ Rated Engine Speed 2200 rpm 2300 rpm Engine Power (Gross) 73.8 hp 74 hp PTO Power 57.7 hp @ 100 rpm 65 hp Engine Emissions Constraints Tier 4 US EPA Tier 4B Cooling System Type Liquid-cooled (Cool-Gard II coolant) Liquid-cooled Air Cleaner Not Published Dry Fuel System Not Published Common rail fuel injection Alternator OOS: 90 A; Cab: 120 A 120 A ▶ HydraulicsPump Type Tandem gear pump Open center, dual pumps: implement pump plus dedicated steering and services pump Implement Flow 18.4 gpm 12.5 gpm Steering Flow 6.3 gpm 7.3 gpm (mechanical shuttle); 9.5 gpm (power shuttle) Total Hydraulic Flow 24.7 gpm 19.8 gpm (mechanical shuttle; 12.5 + 7.3, computed); 22.0 gpm (power shuttle; 12.5 + 9.5, computed) Overall Hydraulic Pump Flow 24.7 gpm 19.8 gpm (mechanical shuttle; 12.5 + 7.3, computed); 22.0 gpm (power shuttle; 12.5 + 9.5, computed) Hydraulic System Type Open center Open center Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves 2 (rear); 2 (mid) Not Published No. of Optional Remote Valves Up to 3 total (rear); up to 3 total (mid) Up to 3 rear remotes ▶ Fluid CapacityFuel Tank Capacity OOS: 39.2 gal; OOS (High Capacity): 47.1 gal; Cab: 43.7 gal; Cab (High Capacity): 52 gal 23.8 gal Coolant Capacity OOS: 3.6 gal; Cab: 4.2 gal Not Published Crankcase Capacity 2.2 gal Not Published Transmission / Hydraulic System Capacity 10.4 gal Not Published Front Axle Fluid Capacity Differential housing (MFWD): 1.3 gal; Wheel hub (each): 0.2 gal Not Published ▶ PTO & HitchPTO Type Independent rear PTO, electro-hydraulic wet disc clutch: 540/540E standard, 540/540E/1000 optional Fully independent PTO Rear 540/540E rpm standard; 1000 rpm optional 540 rpm at 1,958 engine rpm (standard); 540E at 1,592 engine rpm (optional) Mid-PTO Availability Not Published Not Published Category, 3-Point Hitch Category II (convertible to I) Category II / I Hitch Lift Capacity 5,305 lb standard; 6,114 lb optional Not Published Hitch Lift Capacity (at 24”) 5,150 lb standard; 5,950 lb optional 3,664 lb Lift Control Type Mechanical or Electrohydraulic Mechanical draft control; top link draft sensing ▶ Transmission & DrivetrainTransmission Type PowrReverser 16F/16R (base); optional 32F/16R PowrReverser Hi-Lo 8x8 mechanical synchro shuttle (standard); 8x8 hydraulic power shuttle, 12x12 mechanical synchro shuttle or 12x12 hydraulic power shuttle (optional); creeper available with the power shuttle transmissions No. of Speeds 16F/16R (standard PowrReverser); 32F/16R (optional PowrReverser Hi-Lo) 8F/8R (standard); 12F/12R (optional); 12F/12R or 20F/20R with creeper (optional) Max Travel Speed (Forward) 24 mph 20.1 mph (8x8 and 12x12, 20 mph transmissions); 24.1 mph (optional 24 mph 12x12 transmission, 4WD only) Max Travel Speed (Reverse) 16F/16R PowrReverser, top gear D-4: 20.5 mph (30K gearing); 23.9 mph (40K gearing), with 480/70R28 rear tires at 2200 rpm 20.1 mph Clutch Wet Mechanical dry disc (mechanical shuttle); wet disc (power shuttle) Differential Lock & Limited Slip Options Electrohydraulic rear differential lock Mechanical rear differential lock ▶ Chassis, Steering & ControlsFrame Type Cast iron mid-frame Not Published Steering Not Published Hydrostatic power steering Brakes Hydraulically actuated wet disc brakes Hydraulic wet disc Seat Suspension & Adjustability OOS: isolated mechanical seat standard (fore/aft, weight, lumbar adjust) or air suspension seat optional; Cab: mechanical seat standard or air suspension seat optional; adjustable weight range 88-330 lb Optional deluxe air suspension seat with fully integrated armrest and 10° swivel to the right; full-size instructor seat with seatbelt Front Axle Type MFWD Heavy-duty 2WD front axle; electronic 4WD front axle (optional) Front Axle Rating 6,613 lb max permissible front axle load Not Published Drawbar Capacity Standard drawbar: 2,756 lb; 2,425 lb; 2,205 lb. Heavy-duty drawbar: 3,197 lb; 2,646 lb Not Published ▶ Dimensions & ManeuverabilityOverall Width Cab, with fender extension: 85.6 in; Cab, without fender extension: 74 in; OOS, with fender extension: 69.1 in; OOS, without fender extension: 51.7 in Not Published Wheelbase 92.5 in 85.8 in (2WD); 83.9 in (4WD) Ground Clearance Not Published Not Published Min. Turn Radius without Brakes 13.1 ft 134 in (2WD front axle) Height to Top of ROPS 102.1 in (with standard rear tires) Not Published Height to Top of ROPS (folded) Not Published 76 to 78.9 in Height to Top of Cab Model 102.9 in (with standard rear tires) 94.8 to 97.8 in Overall Length 149.5 in (including draft links) 151 in ▶ WeightTractor Weight (Base) 2WD OOS: 8,140 lb; 2WD Cab: 8,580 lb; MFWD OOS: 8,765 lb; MFWD Cab: 9,185 lb (approximate ship weight, less weights) 5,027 lb (2WD ROPS); 5,952 lb (4WD ROPS) Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options Not Published Not Published R1 Agricultural - Front 12.4R24 (320/85R24) R1W Radial Not Published R1 Agricultural - Rear 18.4R30 (460/85R30) R1W Radial Not Published R3 Turf - Front Not Published Not Published R3 Turf - Rear Not Published Not Published R4 Industrial - Front Not Published Not Published R4 Industrial - Rear Not Published Not Published ▶ Loader & AttachmentsQuick Attach Loader System Not Published Skid-steer-style or Euro-style quick attach faceplate Loader Model 520M (4WD only); 540M NSL; 540M MSL; 540R; 600M NSL; 600M MSL Factory-fit: 655TL (NSL or MSL); field-fit: 622TL (NSL), 627TL (MSL) Loader Lift Height 520M: 130-132 in; 540M NSL: 137-141 in; 540M MSL: 138-141 in; 540R: 141.85 in; 600M NSL: 148.8-152.8 in; 600M MSL: 148-153 in 655TL NSL: 126 in; 655TL MSL: 125 in; 622TL: 121 in; 627TL: 121 in Loader Lift Capacity (Full Height) 520M NSL: 3,335-3,612 lb; 520M MSL: 2,460-2,661 lb; 540M NSL: 2,394-2,666 lb; 540M MSL: 3,117-3,309 lb; 540R: 3,406 lb; 600M NSL: 3,104-3,236 lb; 600M MSL: 3,891-4,085 lb 655TL NSL: 2,478 lb; 655TL MSL: 3,179 lb; 622TL: 1,830 lb; 627TL: 2,557 lb (to max height, at 31.5 in from pivot point) Loader Breakout Force 540M NSL: 6,686 lbf; 540M SL: 5,513 lbf; 540R NSL: 4,945 lbf; 540R SL: 5,291 lbf; H310 NSL: 6,767 lbf (measured at pivot; H310 for MFWD tractors) 655TL NSL: 3,739 lb; 655TL MSL: 4,665 lb; 622TL: 3,042 lb; 627TL: 3,307 lb ▶ WarrantyWarranty Length & Coverage Not Published Not Published
