▶ EngineEngine Manufacturer John Deere FPT Industrial Engine Model PowerTech 4045 (4.5L) PWL F5G Engine Type 4-cylinder, turbocharged and aftercooled diesel, electronic fuel control 4-cylinder diesel No. of Cylinders 4 4 Displacement 276 in³ 207 in³ Rated Engine Speed 2400 rpm 2300 rpm Engine Power (Gross) 90 hp 86 hp PTO Power 76.7 hp 73 hp Engine Emissions Constraints Tier 4 Tier 4B Cooling System Type Liquid-cooled Liquid-cooled Air Cleaner Dry type with safety element Not Published Fuel System High pressure common rail, electronic fuel control Electronic high-pressure common rail fuel injection Alternator OOS: 90 A; Cab: 120 A Not Published ▶ HydraulicsPump Type Tandem gear pump, two engine-mounted pumps Open-center tandem gear pumps: implement pump plus steering and services pump Implement Flow 15.9 gpm 16.9 gpm Steering Flow 6.6 gpm 9.7 gpm Total Hydraulic Flow 22.5 gpm 26.6 gpm Overall Hydraulic Pump Flow 22.5 gpm 26.6 gpm Hydraulic System Type Open center Open center Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves 2 rear; 0 mid 2 or 3 (base) No. of Optional Remote Valves 3 rear; up to 3 mid Third rear remote (dealer-installed) ▶ Fluid CapacityFuel Tank Capacity 25 gal (open operator station); 30 gal (cab) 30.3 gal Coolant Capacity 2.5 gal (open operator station); 3 gal (cab) Not Published Crankcase Capacity 3.2 gal Not Published Transmission / Hydraulic System Capacity 11.5 gal Not Published Front Axle Fluid Capacity 1.3 gal (MFWD differential housing); 0.74 qt (each wheel hub) Not Published ▶ PTO & HitchPTO Type Independent, electro-hydraulic engagement, wet PTO clutch Hydraulic PTO with power shuttle transmissions; lever-engaged PTO with mechanical shuttle PTO Rear 540/540E standard; 540/1000 optional 540 (12x12 base); 540/540E or 540/1000 (12x12 optional); 540/540E (24x24 Dual Command base); 540/1000 (24x24 Dual Command optional) Mid-PTO Availability Not Published Not Published Category, 3-Point Hitch Category 2, convertible to Category 1 Category II (flexible link ends) Hitch Lift Capacity 5,159 lb (maximum lift force at hitch ball); 3,846 lb throughout lift range Not Published Hitch Lift Capacity (at 24”) 4,630 lb (electrohydraulic hitch) 5,620 lb (7,351 lb with optional auxiliary lift ram) Lift Control Type Electro-hydraulic hitch with electronic quick raise and lower (premium cab); top-link draft sensing 12x12: rear hitch control levers; Dual Command cab: Electronic Draft Control (EDC) mouse and fender switches; single-lever Lift-O-Matic Plus (optional on 12x12, standard on Dual Command ROPS) ▶ Transmission & DrivetrainTransmission Type PowrReverser 12F/12R standard; PowrReverser Hi-Lo 24F/12R optional 12x12 mechanical shuttle (standard); 12x12 power shuttle, 20x20 power shuttle with creeper, 24x24 Dual Command Hi-Lo powershift with electrohydraulic power shuttle, or 40x40 Dual Command with creeper (optional) No. of Speeds 12 forward, 12 reverse (standard); 24 forward, 12 reverse (Hi-Lo) 12F/12R (standard); 20F/20R, 24F/24R or 40F/40R (optional) Max Travel Speed (Forward) 21.7 mph (electronically limited) 20 mph (12x12 and 20x20 creeper, standard; 25 mph transport option); 25 mph (24x24 and 40x40 Dual Command) Max Travel Speed (Reverse) 21.7 mph (electronically limited) Not Published Clutch Wet Not Published Differential Lock & Limited Slip Options Rear differential lock Mechanical rear differential lock, pedal (12x12 models); electrohydraulic rear differential lock, rocker switch (Dual Command models) ▶ Chassis, Steering & ControlsFrame Type Foldable ROPS (open operator station); standard or premium cab; MFWD Not Published Steering Hydrostatic power steering Power steering Brakes Hydraulic wet disc, self-equalizing and self-adjusting, dual-stage Wet disc Seat Suspension & Adjustability Mechanical seat standard; air-suspension seat optional for cab Cab: fabric mechanical-suspension seat or fabric air-suspension seat with swivel; full-size instructor seat available. ROPS: vinyl mechanical-suspension seat with armrests Front Axle Type MFWD Standard-duty, electronically engaged 4WD front axle (standard); optional: mechanically engaged standard-duty 4WD, electronically engaged heavy-duty 4WD, or heavy-duty 2WD front axle Front Axle Rating 6,615 lb 9,479 lb (standard-duty 4WD, in-action capacity at 4 mph); 10,361 lb (heavy-duty 4WD, in-action capacity at 4 mph) Drawbar Capacity 2,755 lb (standard drawbar, 9.8 in extended); 2,425 lb (standard drawbar, 350 and 15.7 in extended); 3,195 lb (heavy-duty drawbar, 9.8 in extended); 2,645 lb (heavy-duty drawbar, 350 and 15.7 in extended) Not Published ▶ Dimensions & ManeuverabilityOverall Width 83.6 in (minimum, 16.9-30 R1 tires); 85.1 in (minimum, 18.4-30 R1 tires) 75.7 in Wheelbase 92.5 in 92.2 in (2WD); 89.9 in (4WD) Ground Clearance 17 in (front axle) Not Published Min. Turn Radius without Brakes 11.6 ft (MFWD) 134 in (2WD heavy-duty front axle) Height to Top of ROPS 101.1 in 106.5 in Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model 102.4 in 102.1 in Overall Length 159.13 in 163.1 in (2WD); 160.9 in (4WD) ▶ WeightTractor Weight (Base) 7,275 lb (MFWD open operator station, shipping weight); 8,150 lb (MFWD cab, shipping weight) 6,988 lb (2WD ROPS); 7,672 lb (4WD ROPS) Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options 18.4-30 R1 bias rear standard; 16.9-30 R1 also listed Ag: 11.2-24 front, 16.9-30 rear; 13.6-24 front, 16.9-34 rear; 12.4-24 front, 18.4-30 rear; 14.9-24 front, 18.4-34 rear; Turf: 13.6-16.1 front, 16.9-24 rear; Industrial: 12.5/80-18 front, 19.5L24 rear R1 Agricultural - Front 12.4-24 4WD: 11.2-24, 13.6-24, 12.4-24 or 14.9-24 (paired with 16.9-30, 16.9-34, 18.4-30 or 18.4-34 rears) R1 Agricultural - Rear 18.4-30 R1 bias 16.9-30, 16.9-34, 18.4-30 or 18.4-34 R3 Turf - Front Not Published 13.6-16.1 R3 Turf - Rear Not Published 16.9-24 R4 Industrial - Front Not Published 12.5/80-18 R4 Industrial - Rear Not Published 19.5L24 ▶ Loader & AttachmentsQuick Attach Loader System Quick attach option with integrated parking stand Skid-steer-style or Euro-style quick attach faceplate Loader Model 520M (NSL and MSL); 540M (NSL) Factory-fit: 655TL (NSL or MSL), 665TL (NSL or MSL); field-fit: 632TL (NSL), 637TL (MSL) Loader Lift Height 520M MSL: 132.0 in 655TL NSL: 126 in; 655TL MSL: 125 in; 665TL NSL: 134 in; 665TL MSL: 135 in; 632TL: 134 in; 637TL: 134 in Loader Lift Capacity (Full Height) 520M MSL: 2,606 lb (to maximum height, measured at pivot) 655TL NSL: 2,478 lb; 655TL MSL: 3,179 lb; 665TL NSL: 2,632 lb; 665TL MSL: 3,428 lb (at 31.5 in from pivot point); 632TL: 2,028 lb; 637TL: 3,175 lb (to max height, 31.5 in from pivot point) Loader Breakout Force 520M NSL: 4,511 lbf; 520M MSL: 4,793 lbf (at pivot point) 655TL NSL: 3,739 lb; 655TL MSL: 3,860 lb; 665TL NSL: 4,455 lb; 665TL MSL: 5,661 lb (at 31.5 in from bucket pivot point); 632TL: 3,351 lb; 637TL: 3,461 lb ▶ WarrantyWarranty Length & Coverage Powertrain 5 years or 2,000 hours, as sold new Not Published
