▶ EngineEngine Manufacturer John Deere John Deere Engine Model PowerTech 4045 PWL PowerTech 4045 (4.5L) PWL Engine Type Diesel, turbocharged, air-to-air aftercooled 4-cylinder, turbocharged and aftercooled diesel, electronic fuel control No. of Cylinders 4 4 Displacement 276 in³ 276 in³ Rated Engine Speed 2200 rpm 2400 rpm Engine Power (Gross) 89.2 hp 90 hp PTO Power 75 hp @ 100 rpm 76.7 hp Engine Emissions Constraints Tier 4 Tier 4 Cooling System Type Cool-Gard II coolant Liquid-cooled Air Cleaner Primary and secondary air cleaner elements Dry type with safety element Fuel System High pressure common rail; electronic fuel control High pressure common rail, electronic fuel control Alternator OOS: 90 A; Cab: 120 A; Field-installed option: 200 A, 12 V OOS: 90 A; Cab: 120 A ▶ HydraulicsPump Type Tandem gear pump Tandem gear pump, two engine-mounted pumps Implement Flow 18.4 gpm 15.9 gpm Steering Flow 6.3 gpm 6.6 gpm Total Hydraulic Flow 24.7 gpm 22.5 gpm Overall Hydraulic Pump Flow 24.7 gpm 22.5 gpm Hydraulic System Type Open center Open center Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves 2 (rear, Dual SCV) 2 rear; 0 mid No. of Optional Remote Valves Up to 1 additional rear valve (3 total with Triple SCV); up to 3 mid SCVs (XI, XII, XIII) for loader functions 3 rear; up to 3 mid ▶ Fluid CapacityFuel Tank Capacity OOS: 29.6 gal; OOS (High Capacity): 37.2 gal; Cab: 37 gal; Cab (High Capacity): 44.9 gal 25 gal (open operator station); 30 gal (cab) Coolant Capacity OOS: 5.2 gal; Cab: 5.8 gal 2.5 gal (open operator station); 3 gal (cab) Crankcase Capacity 3.4 gal 3.2 gal Transmission / Hydraulic System Capacity 10.4 gal 11.5 gal Front Axle Fluid Capacity Differential housing (MFWD): 1.3 gal; Wheel hub (each): 0.2 gal 1.3 gal (MFWD differential housing); 0.74 qt (each wheel hub) ▶ PTO & HitchPTO Type Independent rear PTO, electro-hydraulic actuation: 540/540E standard, 540/540E/1000 optional Independent, electro-hydraulic engagement, wet PTO clutch PTO Rear 540/540E rpm standard; 1000 rpm optional 540/540E standard; 540/1000 optional Mid-PTO Availability Not Published Not Published Category, 3-Point Hitch Category II (convertible to I) Category 2, convertible to Category 1 Hitch Lift Capacity 5,305 lb; 6,114 lb, at hitch ball throughout lift range 5,159 lb (maximum lift force at hitch ball); 3,846 lb throughout lift range Hitch Lift Capacity (at 24”) 5,159 lb standard; 5,954 lb optional 4,630 lb (electrohydraulic hitch) Lift Control Type Mechanical or electrohydraulic (draft control) Electro-hydraulic hitch with electronic quick raise and lower (premium cab); top-link draft sensing ▶ Transmission & DrivetrainTransmission Type PowrReverser 16F/16R (base); optional 32F/16R PowrReverser Hi-Lo or 12F/4R SyncShuttle Plus PowrReverser 12F/12R standard; PowrReverser Hi-Lo 24F/12R optional No. of Speeds 16F/16R (standard PowrReverser); 12F/4R (optional SyncShuttle Plus); 32F/16R (optional PowrReverser Hi-Lo) 12 forward, 12 reverse (standard); 24 forward, 12 reverse (Hi-Lo) Max Travel Speed (Forward) 16F/16R PowrReverser, top gear (D-4): 30K config: 18.6 mph; 40K config: 21.7 mph 21.7 mph (electronically limited) Max Travel Speed (Reverse) 16F/16R PowrReverser, top gear (D-4): 30K config: 20.5 mph; 40K config: 23.9 mph 21.7 mph (electronically limited) Clutch Wet Wet Differential Lock & Limited Slip Options Electro-hydraulic rear differential lock, engage on the go Rear differential lock ▶ Chassis, Steering & ControlsFrame Type Cast iron mid-frame Foldable ROPS (open operator station); standard or premium cab; MFWD Steering Not Published Hydrostatic power steering Brakes Not Published Hydraulic wet disc, self-equalizing and self-adjusting, dual-stage Seat Suspension & Adjustability OOS: isolated mechanical seat, mechanical seat, or air suspension seat (fore/aft, weight and lumbar adjustment); Cab: mechanical suspension seat or air suspension seat; adjustable weight range 88-330 lb Mechanical seat standard; air-suspension seat optional for cab Front Axle Type MFWD (standard); 2WD (optional) MFWD Front Axle Rating 6,613 lb (MFWD, max permissible front axle load) 6,615 lb Drawbar Capacity Standard drawbar: 2,756 lb; 2,425 lb; 2,205 lb. Heavy-duty drawbar: 3,197 lb; 2,646 lb 2,755 lb (standard drawbar, 9.8 in extended); 2,425 lb (standard drawbar, 350 and 15.7 in extended); 3,195 lb (heavy-duty drawbar, 9.8 in extended); 2,645 lb (heavy-duty drawbar, 350 and 15.7 in extended) ▶ Dimensions & ManeuverabilityOverall Width Cab, with fender extension: 85.6 in; Cab, without fender extension: 74 in; OOS, with fender extension: 69.1 in; OOS, without fender extension: 51.7 in 83.6 in (minimum, 16.9-30 R1 tires); 85.1 in (minimum, 18.4-30 R1 tires) Wheelbase 92.5 in 92.5 in Ground Clearance Not Published 17 in (front axle) Min. Turn Radius without Brakes Not Published 11.6 ft (MFWD) Height to Top of ROPS 102.1 in 101.1 in Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model 102.9 in 102.4 in Overall Length 149.5 in (including draft links) 159.13 in ▶ WeightTractor Weight (Base) 2WD, OOS: 8,140 lb; 2WD, Cab: 8,580 lb; MFWD, OOS: 8,765 lb; MFWD, Cab: 9,185 lb (shipping weight, less weights) 7,275 lb (MFWD open operator station, shipping weight); 8,150 lb (MFWD cab, shipping weight) Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options Not Published 18.4-30 R1 bias rear standard; 16.9-30 R1 also listed R1 Agricultural - Front 12.4R24 (320/85R24) R1W Radial 12.4-24 R1 Agricultural - Rear 18.4R30 (460/85R30) R1W Radial 18.4-30 R1 bias R3 Turf - Front Not Published Not Published R3 Turf - Rear Not Published Not Published R4 Industrial - Front Not Published Not Published R4 Industrial - Rear Not Published Not Published ▶ Loader & AttachmentsQuick Attach Loader System Not Published Quick attach option with integrated parking stand Loader Model 540M NSL; 540M SL; 540R NSL; 540R SL; H310 NSL (MFWD required for H310) 520M (NSL and MSL); 540M (NSL) Loader Lift Height 540M NSL: 138 in; 540M SL: 138 in; 540R NSL: 141 in; 540R SL: 141 in; H310 NSL: 149 in 520M MSL: 132.0 in Loader Lift Capacity (Full Height) 540M NSL: 3,674 lb; 540M SL: 3,058 lb; 540R NSL: 4,246 lb; 540R SL: 3,395 lb; H310 NSL: 4,644 lb (measured at pivot) 520M MSL: 2,606 lb (to maximum height, measured at pivot) Loader Breakout Force 540M NSL: 6,686 lbf; 540M SL: 5,513 lbf; 540R NSL: 4,945 lbf; 540R SL: 5,291 lbf; H310 NSL: 6,767 lbf (measured at pivot) 520M NSL: 4,511 lbf; 520M MSL: 4,793 lbf (at pivot point) ▶ WarrantyWarranty Length & Coverage Not Published Powertrain 5 years or 2,000 hours, as sold new
