▶ EngineEngine Manufacturer John Deere Yanmar Engine Model John Deere PowerTech 4.5L diesel 4TNV86CHT-MJT Engine Type 4-cylinder, turbocharged and intercooled diesel, 4-valve high pressure common rail Turbocharged 4-cylinder Diesel No. of Cylinders 4 4 Displacement 276 in³ 127.6 in³ Rated Engine Speed 2200 rpm 2600 rpm Engine Power (Gross) 90 hp 74.3 hp PTO Power 75 hp @ 100 rpm 60 hp Engine Emissions Constraints Tier 4 Tier 4 Cooling System Type Liquid-cooled Liquid-cooled Air Cleaner Dry type with safety element Dry type with electronic restriction indicator Fuel System High pressure common rail, 4 valve, electronic fuel control High pressure common-rail direct injection Alternator 200 A 75 A ▶ HydraulicsPump Type Tandem gear pump (open center); variable axial-piston implement pump (PFC, optional) Dual Independent Implement Flow 19.3 gpm (open center); 30.9 gpm (PFC) Not Published Steering Flow 6.3 gpm (open center) Not Published Total Hydraulic Flow 25.6 gpm (open center) 15.9 gpm Overall Hydraulic Pump Flow 25.6 gpm (open center); 30.9 gpm (PFC) 15.9 gpm Hydraulic System Type Open center (standard); closed center PFC (optional) Open center Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves 2 rear and 2 mid (stackable) Not Published No. of Optional Remote Valves Rear: 3 (mechanical or proportional EH, optional; 4th rear by conversion kit); Mid: 3 Deluxe (mechanical or EH, optional) 3/4/5 optional ▶ Fluid CapacityFuel Tank Capacity 38 gal 14.7 gal Coolant Capacity 4.25 gal 8.0 qt Crankcase Capacity 3.1 gal 5.7 qt Transmission / Hydraulic System Capacity 11.75 gal (open center); 12.5 gal (closed center PFC) Not Published Front Axle Fluid Capacity 1.3 gal (MFWD differential housing); 0.2 gal (each wheel hub) Not Published ▶ PTO & HitchPTO Type Independent, electro-hydraulic engagement, wet PTO clutch, reversible 540/1000 shaft Independent (wet disc clutch) PTO Rear 540/540E/1000 rpm 540 rpm Mid-PTO Availability Not Published No mid-PTO offered Category, 3-Point Hitch Category II (telescoping draft links with Category II balls) Category I Hitch Lift Capacity 7,158 lb; 8,157 lb throughout lift range at hitch ball; 11,122 lb / 12,515 lb maximum 3,130 lb Hitch Lift Capacity (at 24”) 6,975 lb; 7,868 lb throughout lift range 2,500 lb Lift Control Type Electro-hydraulic hitch with fender controls, lower-link draft sensing Position control ▶ Transmission & DrivetrainTransmission Type CommandQuad 16F/16R manual with electronic range and gear shifting, AutoClutch and wet traction clutch (standard); CommandQuad 16F/16R Auto, CommandQuad 16F/16R manual with creeper, or Command8 32F/16R (optional) Standard: eHydro (3F/3R hydrostatic); Optional: 12F/12R PowrReverser No. of Speeds 16F/16R (CommandQuad, standard); 32F/16R (Command8, optional) eHydro: 3F/3R; PowrReverser: 12F/12R Max Travel Speed (Forward) 22.0 mph (D4, 16/16 transmission, 480/70R28 rear tires) 18.7 mph Max Travel Speed (Reverse) 18.6 mph Not Published Clutch Wet traction clutch with AutoClutch Wet disc (PowrReverser); n/a (eHydro) Differential Lock & Limited Slip Options Electro-hydraulic differential lock Yes, mechanical rear differential lock ▶ Chassis, Steering & ControlsFrame Type Cab standard with air conditioning; mechanical front-wheel drive (MFWD) ComfortGard cab (standard) Steering Hydrostatic power steering Power steering Brakes Hydraulic wet disc, self-equalizing and self-adjusting, lockable turning brakes; electronic park brake Wet disc Seat Suspension & Adjustability Not Published Not Published Front Axle Type MFWD, electro-hydraulic engagement, planetary final drives Mechanical front wheel drive (MFWD) - Standard Front Axle Rating 7,937 lb (MFWD closed center); 7,055 lb (MFWD open center) 3,307 lb Drawbar Capacity 2,756 lb (standard drawbar, 9.8 in extended); 2,205 lb (standard, 13.8 in extended); 3,197 lb (heavy duty, 9.8 in extended); 2,646 lb (heavy duty, 13.8 in extended) Not Published ▶ Dimensions & ManeuverabilityOverall Width 87 in (with fender extension); 74 in (without fender extension); 66.9 in (narrow cab, without fender extension) 78.3 in Wheelbase 88.6 in 73 in Ground Clearance Not Published Not Published Min. Turn Radius without Brakes Not Published Not Published Height to Top of ROPS Not Published Not Published Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model 106.1 in 97.4 in Overall Length 147.8 in 133.4 in ▶ WeightTractor Weight (Base) 9,811 lb (base machine weight, with all fluids) 4,828 lb (operating weight) Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options 320/85R24 (12.4R24) R1-W radial front and 460/85R30 (18.4R30) R1-W radial rear standard; optional 11.2R28/13.6R38, 380/70R20/480/70R28, 13.6R24/16.9R34, 380/70R24/480/70R34 R1; R3 44x18-20/23.1-26; R4 12.5/80-18/19.5L-24 Not Published R1 Agricultural - Front 320/85R24 (12.4R24) R1-W radial 8-16 (6PR) R1 Agricultural - Rear 460/85R30 (18.4R30) R1-W radial 13.6-28 R3 Turf - Front 44x18-20 Not Published R3 Turf - Rear 23.1-26 Not Published R4 Industrial - Front 12.5/80-18 Not Published R4 Industrial - Rear 19.5L-24 Not Published ▶ Loader & AttachmentsQuick Attach Loader System Global carrier in base; John Deere 500-style carrier optional (540R) Not Published Loader Model 540R (non self-leveling and mechanical self-leveling) 440R Loader Lift Height 540R: 141.5 in Not Published Loader Lift Capacity (Full Height) 540R NSL: 4,246 lb (measured at pivot) 440R NSL: 2,539 lb; 440R MSL: 2,213 lb (at pivot pin, 4R Series figures) Loader Breakout Force 540R NSL: 4,945 lbf (measured at pivot) Not Published ▶ WarrantyWarranty Length & Coverage Not Published Basic 2 years or 2,000 hours; powertrain 6 years or 2,000 hours
