▶ EngineEngine Manufacturer John Deere Mahindra Engine Model John Deere PowerTech 4.5L diesel Not Published Engine Type 4-cylinder, turbocharged and intercooled diesel, 4-valve high pressure common rail Four-stroke, turbocharged, direct injection, water-cooled diesel No. of Cylinders 4 4 Displacement 276 in³ 215.4 in³ Rated Engine Speed 2200 rpm 2300 rpm Engine Power (Gross) 90 hp 91.5 hp PTO Power 75 hp @ 100 rpm 75 hp Engine Emissions Constraints Tier 4 Tier 4 Cooling System Type Liquid-cooled Water-cooled Air Cleaner Dry type with safety element Not Published Fuel System High pressure common rail, 4 valve, electronic fuel control Common rail direct injection Alternator 200 A 140 A ▶ HydraulicsPump Type Tandem gear pump (open center); variable axial-piston implement pump (PFC, optional) Not Published Implement Flow 19.3 gpm (open center); 30.9 gpm (PFC) 17 gpm Steering Flow 6.3 gpm (open center) 5.2 gpm Total Hydraulic Flow 25.6 gpm (open center) 22.2 gpm Overall Hydraulic Pump Flow 25.6 gpm (open center); 30.9 gpm (PFC) 22.2 gpm Hydraulic System Type Open center (standard); closed center PFC (optional) Open center with position and draft control Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves 2 rear and 2 mid (stackable) 2 No. of Optional Remote Valves Rear: 3 (mechanical or proportional EH, optional; 4th rear by conversion kit); Mid: 3 Deluxe (mechanical or EH, optional) 3rd valve optional ▶ Fluid CapacityFuel Tank Capacity 38 gal 25.9 gal Coolant Capacity 4.25 gal Not Published Crankcase Capacity 3.1 gal Not Published Transmission / Hydraulic System Capacity 11.75 gal (open center); 12.5 gal (closed center PFC) Not Published Front Axle Fluid Capacity 1.3 gal (MFWD differential housing); 0.2 gal (each wheel hub) Not Published ▶ PTO & HitchPTO Type Independent, electro-hydraulic engagement, wet PTO clutch, reversible 540/1000 shaft 2-speed independent single lever PTO PTO Rear 540/540E/1000 rpm 540/1000 rpm Mid-PTO Availability Not Published Not Published Category, 3-Point Hitch Category II (telescoping draft links with Category II balls) CAT II with telescoping stabilizers & flex links Hitch Lift Capacity 7,158 lb; 8,157 lb throughout lift range at hitch ball; 11,122 lb / 12,515 lb maximum 5,500 lb Hitch Lift Capacity (at 24”) 6,975 lb; 7,868 lb throughout lift range Not Published Lift Control Type Electro-hydraulic hitch with fender controls, lower-link draft sensing Position and draft control ▶ Transmission & DrivetrainTransmission Type CommandQuad 16F/16R manual with electronic range and gear shifting, AutoClutch and wet traction clutch (standard); CommandQuad 16F/16R Auto, CommandQuad 16F/16R manual with creeper, or Command8 32F/16R (optional) Full synchro mesh with forward/reverse power shuttle and constant-mesh range No. of Speeds 16F/16R (CommandQuad, standard); 32F/16R (Command8, optional) 12F / 12R Max Travel Speed (Forward) 22.0 mph (D4, 16/16 transmission, 480/70R28 rear tires) Not Published Max Travel Speed (Reverse) 18.6 mph Not Published Clutch Wet traction clutch with AutoClutch Power shuttle with torsional damper (wet) Differential Lock & Limited Slip Options Electro-hydraulic differential lock Not Published ▶ Chassis, Steering & ControlsFrame Type Cab standard with air conditioning; mechanical front-wheel drive (MFWD) Steel frame Steering Hydrostatic power steering Power steering Brakes Hydraulic wet disc, self-equalizing and self-adjusting, lockable turning brakes; electronic park brake Oil-immersed brakes, 7-in disc, mechanically actuated Seat Suspension & Adjustability Not Published Seat with integrated folding armrests, recline, and air-suspension standard Front Axle Type MFWD, electro-hydraulic engagement, planetary final drives Not Published Front Axle Rating 7,937 lb (MFWD closed center); 7,055 lb (MFWD open center) Not Published Drawbar Capacity 2,756 lb (standard drawbar, 9.8 in extended); 2,205 lb (standard, 13.8 in extended); 3,197 lb (heavy duty, 9.8 in extended); 2,646 lb (heavy duty, 13.8 in extended) Not Published ▶ Dimensions & ManeuverabilityOverall Width 87 in (with fender extension); 74 in (without fender extension); 66.9 in (narrow cab, without fender extension) 83 in Wheelbase 88.6 in 95.6 in Ground Clearance Not Published 14.1 in Min. Turn Radius without Brakes Not Published 15.5 ft Height to Top of ROPS Not Published Not Published Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model 106.1 in 111.2 in Overall Length 147.8 in 176.6 in ▶ WeightTractor Weight (Base) 9,811 lb (base machine weight, with all fluids) 8,587 lb Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options 320/85R24 (12.4R24) R1-W radial front and 460/85R30 (18.4R30) R1-W radial rear standard; optional 11.2R28/13.6R38, 380/70R20/480/70R28, 13.6R24/16.9R34, 380/70R24/480/70R34 R1; R3 44x18-20/23.1-26; R4 12.5/80-18/19.5L-24 Not Published R1 Agricultural - Front 320/85R24 (12.4R24) R1-W radial 12.4 x 24 R1 Agricultural - Rear 460/85R30 (18.4R30) R1-W radial 18.4 x 30 R3 Turf - Front 44x18-20 Not Published R3 Turf - Rear 23.1-26 Not Published R4 Industrial - Front 12.5/80-18 Not Published R4 Industrial - Rear 19.5L-24 Not Published ▶ Loader & AttachmentsQuick Attach Loader System Global carrier in base; John Deere 500-style carrier optional (540R) Skid steer style quick attach Loader Model 540R (non self-leveling and mechanical self-leveling) 8100CL Loader Lift Height 540R: 141.5 in 8100CL: 139 in Loader Lift Capacity (Full Height) 540R NSL: 4,246 lb (measured at pivot) 8100CL: 4,200 lb (at pivot pin) Loader Breakout Force 540R NSL: 4,945 lbf (measured at pivot) 8100CL: 6,050 lb ▶ WarrantyWarranty Length & Coverage Not Published Not Published
