▶ EngineEngine Manufacturer John Deere FPT Industrial Engine Model PowerTech 4045 PWL F5G Engine Type 4-cylinder in-line turbocharged and air-to-air aftercooled diesel, electronic fuel control 4-cylinder diesel, turbocharged and aftercooled No. of Cylinders 4 4 Displacement 276 in³ 207 in³ Rated Engine Speed 2200 rpm 2300 rpm Engine Power (Gross) 90 hp 86 hp PTO Power 75 hp 73 hp Engine Emissions Constraints Tier 4 Tier 4 Cooling System Type Liquid-cooled Liquid-cooled Air Cleaner Dry type with safety element Not Published Fuel System High pressure common rail, 4 valve, electronic fuel control Electronic high-pressure common rail fuel injection Alternator 200 A ROPS: 120 A; Cab: 150 A ▶ HydraulicsPump Type Tandem gear pump (open center); variable axial piston implement pump (pressure-and-flow compensated, optional) Open-center; dual pumps (implement pump plus dedicated steering pump) Implement Flow 19.3 gpm (open center); 30.9 gpm (PFC) 16.9 gpm Steering Flow 6.2 gpm (open center) 9.7 gpm Total Hydraulic Flow 25.6 gpm (open center) 26.6 gpm Overall Hydraulic Pump Flow 25.5 gpm (open center); 31 gpm (PFC) 26.6 gpm Hydraulic System Type Open center (standard); closed center PFC (optional) Open center Rear Remote Hydraulic Flow 19.3 gpm (open center); 26.4 gpm (PFC) Not Published No. of Standard Remote Valves 2 rear and 2 mid (stackable) 2 rear remotes (open center with detent) No. of Optional Remote Valves Mid and front SCVs optional; up to 3 rear 1 (third rear remote, DIA kit) ▶ Fluid CapacityFuel Tank Capacity 38 gal 30.3 gal Coolant Capacity 4.25 gal Not Published Crankcase Capacity 3.1 gal Not Published Transmission / Hydraulic System Capacity 11.75 gal (open center); 12.5 gal (closed center PFC) Not Published Front Axle Fluid Capacity 1.3 gal (MFWD differential housing); 0.2 gal (each wheel hub) Not Published ▶ PTO & HitchPTO Type Independent, electro-hydraulic engagement, wet PTO clutch, reversible 540/1000 shaft Fully independent hydraulic PTO PTO Rear 540/540E/1000 rpm 540 rpm (standard); 540/1000 rpm with interchangeable shafts (optional) Mid-PTO Availability Not Published Not Published Category, 3-Point Hitch Category II (telescoping draft links with Category II balls) Category II Hitch Lift Capacity 7158 lb; 8157 lb throughout lift range at hitch ball; 11122 lb / 12515 lb maximum Not Published Hitch Lift Capacity (at 24”) 6975 lb; 7868 lb throughout lift range 5,620 lb Lift Control Type Electro-hydraulic hitch with fender controls, lower link draft sensing Mechanical draft control; Lift-O-Matic PLUS single-lever raise/lower (standard) ▶ Transmission & DrivetrainTransmission Type CommandQuad manual 16F/16R standard (electronic range and gear shifting, AutoClutch); CommandQuad manual with creeper optional; Command8 32F/16R optional 12x12 power shuttle, column-mounted (standard); 20x20 power shuttle with creeper (optional) No. of Speeds 16 forward, 16 reverse (CommandQuad); 32 forward, 16 reverse (Command8) 12F/12R (standard); 20F/20R with creeper (optional) Max Travel Speed (Forward) 22.0 mph (D4, 16/16 transmission, 480/70R28 rear tires); limited to 24.9 mph 27 mph (4WD front axle); 20 mph (2WD front axle) Max Travel Speed (Reverse) 18.6 mph (limited to 18.6 mph) 27.25 mph (12x12, 4WD front axle, 18R34 tires) Clutch Wet traction clutch with AutoClutch Not Published Differential Lock & Limited Slip Options Electro-hydraulic rear differential lock Mechanical rear differential lock (pedal); limited-slip 4WD front axle with electrohydraulic engagement ▶ Chassis, Steering & ControlsFrame Type Cab standard with air conditioning; four-wheel drive Not Published Steering Hydrostatic power steering Power steering Brakes Hydraulic wet disk, self-equalizing and self-adjusting, lockable turning brakes; electronic park brake Hydraulic wet disc Seat Suspension & Adjustability Not Published Cab: air-suspension cloth seat with armrests, 10° swivel (standard); ROPS: vinyl mechanical-suspension seat with armrests Front Axle Type Mechanical front wheel drive (MFWD), electro-hydraulic engagement, planetary final drives Limited-slip 4WD front axle with electrohydraulic engagement (standard); heavy-duty 2WD front axle (optional) Front Axle Rating Not Published 9,480 lb (standard limited-slip 4WD front axle, maximum capacity); 10,360 lb (optional heavy-duty 4WD front axle); 7,716 lb (optional 2WD heavy-duty front axle) Drawbar Capacity 2756 lb (standard drawbar, 9.8 in extended); 2205 lb (standard, 350 and 15.7 in); 3197 lb (heavy duty, 9.8 in); 2646 lb (heavy duty, 350 and 15.7 in) Not Published ▶ Dimensions & ManeuverabilityOverall Length with 3-Point Hitch 147.8 in 163.1 in (2WD); 160.9 in (4WD) Overall Width 87 in (with fender extension); 74 in (without fender extension); 66.9 in (narrow cab, without fender extension) 75.7 in Wheelbase 88.6 in 92.2 in (2WD); 89.9 in (4WD) Ground Clearance Not Published Not Published Min. Turn Radius without Brakes 12.1 ft 134 in (optional 2WD front axle, w/o brakes) Height to Top of ROPS Not Published 106.5 in Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model 106.1 in 102.1 in ▶ WeightTractor Weight (Base) 9811 lb 6,988 lb (ROPS/2WD); 7,672 lb (ROPS/4WD); 7,473 lb (cab/2WD); 8,157 lb (cab/4WD) Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options 320/85R24 (12.4R24) R1-W radial front and 460/85R30 (18.4R30) R1-W radial rear standard; optional 11.2R28/13.6R38, 380/70R20/480/70R28, 13.6R24/16.9R34, 380/70R24/480/70R34 R1; R3 44x18-20/23.1-26; R4 12.5/80-18/19.5L-24 2WD: 10.00-16 front, 18.4-30 rear; 4WD: 12.4-24 front, 18.4-30 rear (standard); 18.4R34 rear is the reference tire for weights and dimensions R1 Agricultural - Front 12.4R24 2WD: 10.00-16; 4WD: 12.4-24 R1 Agricultural - Rear 18.4R30 18.4R34 (reference tire for OEM weights and dimensions) R3 Turf - Front 44x18-20 Not Published R3 Turf - Rear 23.1-26 Not Published R4 Industrial - Front 12.5/80-18 Not Published R4 Industrial - Rear 19.5L-24 Not Published ▶ Loader & AttachmentsQuick Attach Loader System Global carrier in base; John Deere 500-style carrier optional (540R) Skid-steer-style or Euro-style quick attach faceplate (optional, all four LU loaders) Loader Model 540R (non self-leveling and mechanical self-leveling) 710LU (NSL); 715LU (MSL); 720LU (NSL); 725LU (MSL) Loader Lift Height 540R: 141.9 in 710LU: 126.3 in; 715LU: 125.9 in; 720LU: 134 in; 725LU: 135 in Loader Lift Capacity (Full Height) 540R: 4529 lb (full at pin) 710LU: 3,461 lb; 715LU: 3,573 lb; 720LU: 3,849 lb; 725LU: 4,204 lb Loader Breakout Force 540R: 4934 lbf (at pin) 710LU: 3,739 lb; 715LU: 3,860 lb; 720LU: 4,455 lb; 725LU: 5,661 lb (31.5 in forward of the bucket pivot point) ▶ WarrantyWarranty Length & Coverage Not Published Not Published
