▶ EngineEngine Manufacturer John Deere FPT Industrial Engine Model John Deere PowerTech 4.5L diesel F5G Engine Type 4-cylinder, turbocharged and intercooled diesel, 4-valve high pressure common rail 4-cylinder diesel No. of Cylinders 4 4 Displacement 276 in³ 207 in³ Rated Engine Speed 2200 rpm 2300 rpm Engine Power (Gross) 90 hp 86 hp PTO Power 75 hp @ 100 rpm 73 hp Engine Emissions Constraints Tier 4 Tier 4B Cooling System Type Liquid-cooled Liquid-cooled Air Cleaner Dry type with safety element Not Published Fuel System High pressure common rail, 4 valve, electronic fuel control Electronic high-pressure common rail fuel injection Alternator 200 A Not Published ▶ HydraulicsPump Type Tandem gear pump (open center); variable axial-piston implement pump (PFC, optional) Open-center tandem gear pumps: implement pump plus steering and services pump Implement Flow 19.3 gpm (open center); 30.9 gpm (PFC) 16.9 gpm Steering Flow 6.3 gpm (open center) 9.7 gpm Total Hydraulic Flow 25.6 gpm (open center) 26.6 gpm Overall Hydraulic Pump Flow 25.6 gpm (open center); 30.9 gpm (PFC) 26.6 gpm Hydraulic System Type Open center (standard); closed center PFC (optional) Open center Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves 2 rear and 2 mid (stackable) 2 or 3 (base) No. of Optional Remote Valves Rear: 3 (mechanical or proportional EH, optional; 4th rear by conversion kit); Mid: 3 Deluxe (mechanical or EH, optional) Third rear remote (dealer-installed) ▶ Fluid CapacityFuel Tank Capacity 38 gal 30.3 gal Coolant Capacity 4.25 gal Not Published Crankcase Capacity 3.1 gal Not Published Transmission / Hydraulic System Capacity 11.75 gal (open center); 12.5 gal (closed center PFC) Not Published Front Axle Fluid Capacity 1.3 gal (MFWD differential housing); 0.2 gal (each wheel hub) Not Published ▶ PTO & HitchPTO Type Independent, electro-hydraulic engagement, wet PTO clutch, reversible 540/1000 shaft Hydraulic PTO with power shuttle transmissions; lever-engaged PTO with mechanical shuttle PTO Rear 540/540E/1000 rpm 540 (12x12 base); 540/540E or 540/1000 (12x12 optional); 540/540E (24x24 Dual Command base); 540/1000 (24x24 Dual Command optional) Mid-PTO Availability Not Published Not Published Category, 3-Point Hitch Category II (telescoping draft links with Category II balls) Category II (flexible link ends) Hitch Lift Capacity 7,158 lb; 8,157 lb throughout lift range at hitch ball; 11,122 lb / 12,515 lb maximum Not Published Hitch Lift Capacity (at 24”) 6,975 lb; 7,868 lb throughout lift range 5,620 lb (7,351 lb with optional auxiliary lift ram) Lift Control Type Electro-hydraulic hitch with fender controls, lower-link draft sensing 12x12: rear hitch control levers; Dual Command cab: Electronic Draft Control (EDC) mouse and fender switches; single-lever Lift-O-Matic Plus (optional on 12x12, standard on Dual Command ROPS) ▶ Transmission & DrivetrainTransmission Type CommandQuad 16F/16R manual with electronic range and gear shifting, AutoClutch and wet traction clutch (standard); CommandQuad 16F/16R Auto, CommandQuad 16F/16R manual with creeper, or Command8 32F/16R (optional) 12x12 mechanical shuttle (standard); 12x12 power shuttle, 20x20 power shuttle with creeper, 24x24 Dual Command Hi-Lo powershift with electrohydraulic power shuttle, or 40x40 Dual Command with creeper (optional) No. of Speeds 16F/16R (CommandQuad, standard); 32F/16R (Command8, optional) 12F/12R (standard); 20F/20R, 24F/24R or 40F/40R (optional) Max Travel Speed (Forward) 22.0 mph (D4, 16/16 transmission, 480/70R28 rear tires) 20 mph (12x12 and 20x20 creeper, standard; 25 mph transport option); 25 mph (24x24 and 40x40 Dual Command) Max Travel Speed (Reverse) 18.6 mph Not Published Clutch Wet traction clutch with AutoClutch Not Published Differential Lock & Limited Slip Options Electro-hydraulic differential lock Mechanical rear differential lock, pedal (12x12 models); electrohydraulic rear differential lock, rocker switch (Dual Command models) ▶ Chassis, Steering & ControlsFrame Type Cab standard with air conditioning; mechanical front-wheel drive (MFWD) Not Published Steering Hydrostatic power steering Power steering Brakes Hydraulic wet disc, self-equalizing and self-adjusting, lockable turning brakes; electronic park brake Wet disc Seat Suspension & Adjustability Not Published Cab: fabric mechanical-suspension seat or fabric air-suspension seat with swivel; full-size instructor seat available. ROPS: vinyl mechanical-suspension seat with armrests Front Axle Type MFWD, electro-hydraulic engagement, planetary final drives Standard-duty, electronically engaged 4WD front axle (standard); optional: mechanically engaged standard-duty 4WD, electronically engaged heavy-duty 4WD, or heavy-duty 2WD front axle Front Axle Rating 7,937 lb (MFWD closed center); 7,055 lb (MFWD open center) 9,479 lb (standard-duty 4WD, in-action capacity at 4 mph); 10,361 lb (heavy-duty 4WD, in-action capacity at 4 mph) Drawbar Capacity 2,756 lb (standard drawbar, 9.8 in extended); 2,205 lb (standard, 13.8 in extended); 3,197 lb (heavy duty, 9.8 in extended); 2,646 lb (heavy duty, 13.8 in extended) Not Published ▶ Dimensions & ManeuverabilityOverall Width 87 in (with fender extension); 74 in (without fender extension); 66.9 in (narrow cab, without fender extension) 75.7 in Wheelbase 88.6 in 92.2 in (2WD); 89.9 in (4WD) Ground Clearance Not Published Not Published Min. Turn Radius without Brakes Not Published 134 in (2WD heavy-duty front axle) Height to Top of ROPS Not Published 106.5 in Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model 106.1 in 102.1 in Overall Length 147.8 in 163.1 in (2WD); 160.9 in (4WD) ▶ WeightTractor Weight (Base) 9,811 lb (base machine weight, with all fluids) 6,988 lb (2WD ROPS); 7,672 lb (4WD ROPS) Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options 320/85R24 (12.4R24) R1-W radial front and 460/85R30 (18.4R30) R1-W radial rear standard; optional 11.2R28/13.6R38, 380/70R20/480/70R28, 13.6R24/16.9R34, 380/70R24/480/70R34 R1; R3 44x18-20/23.1-26; R4 12.5/80-18/19.5L-24 Ag: 11.2-24 front, 16.9-30 rear; 13.6-24 front, 16.9-34 rear; 12.4-24 front, 18.4-30 rear; 14.9-24 front, 18.4-34 rear; Turf: 13.6-16.1 front, 16.9-24 rear; Industrial: 12.5/80-18 front, 19.5L24 rear R1 Agricultural - Front 320/85R24 (12.4R24) R1-W radial 4WD: 11.2-24, 13.6-24, 12.4-24 or 14.9-24 (paired with 16.9-30, 16.9-34, 18.4-30 or 18.4-34 rears) R1 Agricultural - Rear 460/85R30 (18.4R30) R1-W radial 16.9-30, 16.9-34, 18.4-30 or 18.4-34 R3 Turf - Front 44x18-20 13.6-16.1 R3 Turf - Rear 23.1-26 16.9-24 R4 Industrial - Front 12.5/80-18 12.5/80-18 R4 Industrial - Rear 19.5L-24 19.5L24 ▶ Loader & AttachmentsQuick Attach Loader System Global carrier in base; John Deere 500-style carrier optional (540R) Skid-steer-style or Euro-style quick attach faceplate Loader Model 540R (non self-leveling and mechanical self-leveling) Factory-fit: 655TL (NSL or MSL), 665TL (NSL or MSL); field-fit: 632TL (NSL), 637TL (MSL) Loader Lift Height 540R: 141.5 in 655TL NSL: 126 in; 655TL MSL: 125 in; 665TL NSL: 134 in; 665TL MSL: 135 in; 632TL: 134 in; 637TL: 134 in Loader Lift Capacity (Full Height) 540R NSL: 4,246 lb (measured at pivot) 655TL NSL: 2,478 lb; 655TL MSL: 3,179 lb; 665TL NSL: 2,632 lb; 665TL MSL: 3,428 lb (at 31.5 in from pivot point); 632TL: 2,028 lb; 637TL: 3,175 lb (to max height, 31.5 in from pivot point) Loader Breakout Force 540R NSL: 4,945 lbf (measured at pivot) 655TL NSL: 3,739 lb; 655TL MSL: 3,860 lb; 665TL NSL: 4,455 lb; 665TL MSL: 5,661 lb (at 31.5 in from bucket pivot point); 632TL: 3,351 lb; 637TL: 3,461 lb ▶ WarrantyWarranty Length & Coverage Not Published Not Published
