▶ EngineEngine Manufacturer John Deere John Deere Engine Model PowerTech PWL 4045 PowerTech 4045 (4.5L) PWL Engine Type Diesel, turbocharged, aftercooled 4-cylinder, turbocharged and aftercooled diesel, electronic fuel control No. of Cylinders 4 4 Displacement 276 in³ 276 in³ Rated Engine Speed 2400 rpm 2400 rpm Engine Power (Gross) 100 hp 90 hp PTO Power 85 hp 76.7 hp Engine Emissions Constraints Tier 4 Tier 4 Cooling System Type Liquid-cooled Liquid-cooled Air Cleaner Dry type with safety element Dry type with safety element Fuel System High Pressure Common Rail High pressure common rail, electronic fuel control Alternator OOS: 90 A; Cab: 120 A OOS: 90 A; Cab: 120 A ▶ HydraulicsPump Type Tandem gear pump (implement + steering) Tandem gear pump, two engine-mounted pumps Implement Flow 15.9 gpm 15.9 gpm Steering Flow 6.6 gpm 6.6 gpm Total Hydraulic Flow 22.5 gpm 22.5 gpm Overall Hydraulic Pump Flow 22.5 gpm 22.5 gpm Hydraulic System Type Open Center Open center Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves 2 2 rear; 0 mid No. of Optional Remote Valves 3 3 rear; up to 3 mid ▶ Fluid CapacityFuel Tank Capacity OOS: 25 gal; Cab: 30 gal 25 gal (open operator station); 30 gal (cab) Coolant Capacity Cab: 3 gal; OOS: 2.5 gal 2.5 gal (open operator station); 3 gal (cab) Crankcase Capacity 3.2 gal (with filter) 3.2 gal Transmission / Hydraulic System Capacity 11.5 gal 11.5 gal Front Axle Fluid Capacity MFWD differential housing: 1.3 gal; MFWD wheel hub (each): 0.74 qt 1.3 gal (MFWD differential housing); 0.74 qt (each wheel hub) ▶ PTO & HitchPTO Type Independent, electrohydraulic engagement Independent, electro-hydraulic engagement, wet PTO clutch PTO Rear 540/540E rpm 540/540E standard; 540/1000 optional Mid-PTO Availability Not Published Not Published Category, 3-Point Hitch Category II Category 2, convertible to Category 1 Hitch Lift Capacity Not Published 5,159 lb (maximum lift force at hitch ball); 3,846 lb throughout lift range Hitch Lift Capacity (at 24”) 4,630 lb 4,630 lb (electrohydraulic hitch) Lift Control Type Top link draft sensing; mechanical hitch controls Electro-hydraulic hitch with electronic quick raise and lower (premium cab); top-link draft sensing ▶ Transmission & DrivetrainTransmission Type PowrReverser PowrReverser 12F/12R standard; PowrReverser Hi-Lo 24F/12R optional No. of Speeds 12F/12R (standard); 24F/12R (optional) 12 forward, 12 reverse (standard); 24 forward, 12 reverse (Hi-Lo) Max Travel Speed (Forward) 12F/12R: 21.7 mph; 24F/12R: 24.9 mph (electronically limited) 21.7 mph (electronically limited) Max Travel Speed (Reverse) Not Published 21.7 mph (electronically limited) Clutch Wet traction clutch Wet Differential Lock & Limited Slip Options Pedal-operated differential lock Rear differential lock ▶ Chassis, Steering & ControlsFrame Type Not Published Foldable ROPS (open operator station); standard or premium cab; MFWD Steering Hydrostatic power steering Hydrostatic power steering Brakes Hydraulic wet disc brakes, self-equalizing and self-adjusting Hydraulic wet disc, self-equalizing and self-adjusting, dual-stage Seat Suspension & Adjustability Not Published Mechanical seat standard; air-suspension seat optional for cab Front Axle Type Mechanical front wheel drive (MFWD) MFWD Front Axle Rating 6,615 lb 6,615 lb Drawbar Capacity Standard: 2,755 lb; 2,425 lb (350 and 15.7 in extended). Heavy-Duty: 3,195 lb; 2,645 lb (350 and 15.7 in extended) 2,755 lb (standard drawbar, 9.8 in extended); 2,425 lb (standard drawbar, 350 and 15.7 in extended); 3,195 lb (heavy-duty drawbar, 9.8 in extended); 2,645 lb (heavy-duty drawbar, 350 and 15.7 in extended) ▶ Dimensions & ManeuverabilityOverall Width Not Published 83.6 in (minimum, 16.9-30 R1 tires); 85.1 in (minimum, 18.4-30 R1 tires) Wheelbase 92.5 in 92.5 in Ground Clearance ROPS: 17 in; Cab: 15.2 in 17 in (front axle) Min. Turn Radius without Brakes Not Published 11.6 ft (MFWD) Height to Top of ROPS 100.8 in 101.1 in Height to Top of ROPS (folded) 78.6 in Not Published Height to Top of Cab Model 101.2 in 102.4 in Overall Length 159.13 in 159.13 in ▶ WeightTractor Weight (Base) OOS: 7,275 lb (shipping weight); Cab: 8,150 lb (shipping weight) 7,275 lb (MFWD open operator station, shipping weight); 8,150 lb (MFWD cab, shipping weight) Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options Not Published 18.4-30 R1 bias rear standard; 16.9-30 R1 also listed R1 Agricultural - Front 12.4-24 12.4-24 R1 Agricultural - Rear 18.4-30 18.4-30 R1 bias R3 Turf - Front Not Published Not Published R3 Turf - Rear Not Published Not Published R4 Industrial - Front 12.5/80-18 Not Published R4 Industrial - Rear 19.5L-24 Not Published ▶ Loader & AttachmentsQuick Attach Loader System 520M; 540M Quick attach option with integrated parking stand Loader Model 520M and 540M (previously H240 and H260) 520M (NSL and MSL); 540M (NSL) Loader Lift Height 520M MSL: 132.0 in 520M MSL: 132.0 in Loader Lift Capacity (Full Height) 520M MSL: 2,606 lb (to maximum height, measured at pivot) 520M MSL: 2,606 lb (to maximum height, measured at pivot) Loader Breakout Force 520M MSL: 4,793 lb (measured at pivot) 520M NSL: 4,511 lbf; 520M MSL: 4,793 lbf (at pivot point) ▶ WarrantyWarranty Length & Coverage Not Published Powertrain 5 years or 2,000 hours, as sold new
