▶ EngineEngine Manufacturer John Deere John Deere Engine Model PowerTech PWL 4045 John Deere PowerTech 4.5L diesel Engine Type Diesel, turbocharged, aftercooled 4-cylinder, turbocharged and intercooled diesel, 4-valve high pressure common rail No. of Cylinders 4 4 Displacement 276 in³ 276 in³ Rated Engine Speed 2400 rpm 2200 rpm Engine Power (Gross) 100 hp 90 hp PTO Power 85 hp 75 hp @ 100 rpm Engine Emissions Constraints Tier 4 Tier 4 Cooling System Type Liquid-cooled Liquid-cooled Air Cleaner Dry type with safety element Dry type with safety element Fuel System High Pressure Common Rail High pressure common rail, 4 valve, electronic fuel control Alternator OOS: 90 A; Cab: 120 A 200 A ▶ HydraulicsPump Type Tandem gear pump (implement + steering) Tandem gear pump (open center); variable axial-piston implement pump (PFC, optional) Implement Flow 15.9 gpm 19.3 gpm (open center); 30.9 gpm (PFC) Steering Flow 6.6 gpm 6.3 gpm (open center) Total Hydraulic Flow 22.5 gpm 25.6 gpm (open center) Overall Hydraulic Pump Flow 22.5 gpm 25.6 gpm (open center); 30.9 gpm (PFC) Hydraulic System Type Open Center Open center (standard); closed center PFC (optional) Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves 2 2 rear and 2 mid (stackable) No. of Optional Remote Valves 3 Rear: 3 (mechanical or proportional EH, optional; 4th rear by conversion kit); Mid: 3 Deluxe (mechanical or EH, optional) ▶ Fluid CapacityFuel Tank Capacity OOS: 25 gal; Cab: 30 gal 38 gal Coolant Capacity Cab: 3 gal; OOS: 2.5 gal 4.25 gal Crankcase Capacity 3.2 gal (with filter) 3.1 gal Transmission / Hydraulic System Capacity 11.5 gal 11.75 gal (open center); 12.5 gal (closed center PFC) Front Axle Fluid Capacity MFWD differential housing: 1.3 gal; MFWD wheel hub (each): 0.74 qt 1.3 gal (MFWD differential housing); 0.2 gal (each wheel hub) ▶ PTO & HitchPTO Type Independent, electrohydraulic engagement Independent, electro-hydraulic engagement, wet PTO clutch, reversible 540/1000 shaft PTO Rear 540/540E rpm 540/540E/1000 rpm Mid-PTO Availability Not Published Not Published Category, 3-Point Hitch Category II Category II (telescoping draft links with Category II balls) Hitch Lift Capacity Not Published 7,158 lb; 8,157 lb throughout lift range at hitch ball; 11,122 lb / 12,515 lb maximum Hitch Lift Capacity (at 24”) 4,630 lb 6,975 lb; 7,868 lb throughout lift range Lift Control Type Top link draft sensing; mechanical hitch controls Electro-hydraulic hitch with fender controls, lower-link draft sensing ▶ Transmission & DrivetrainTransmission Type PowrReverser CommandQuad 16F/16R manual with electronic range and gear shifting, AutoClutch and wet traction clutch (standard); CommandQuad 16F/16R Auto, CommandQuad 16F/16R manual with creeper, or Command8 32F/16R (optional) No. of Speeds 12F/12R (standard); 24F/12R (optional) 16F/16R (CommandQuad, standard); 32F/16R (Command8, optional) Max Travel Speed (Forward) 12F/12R: 21.7 mph; 24F/12R: 24.9 mph (electronically limited) 22.0 mph (D4, 16/16 transmission, 480/70R28 rear tires) Max Travel Speed (Reverse) Not Published 18.6 mph Clutch Wet traction clutch Wet traction clutch with AutoClutch Differential Lock & Limited Slip Options Pedal-operated differential lock Electro-hydraulic differential lock ▶ Chassis, Steering & ControlsFrame Type Not Published Cab standard with air conditioning; mechanical front-wheel drive (MFWD) Steering Hydrostatic power steering Hydrostatic power steering Brakes Hydraulic wet disc brakes, self-equalizing and self-adjusting Hydraulic wet disc, self-equalizing and self-adjusting, lockable turning brakes; electronic park brake Seat Suspension & Adjustability Not Published Not Published Front Axle Type Mechanical front wheel drive (MFWD) MFWD, electro-hydraulic engagement, planetary final drives Front Axle Rating 6,615 lb 7,937 lb (MFWD closed center); 7,055 lb (MFWD open center) Drawbar Capacity Standard: 2,755 lb; 2,425 lb (350 and 15.7 in extended). Heavy-Duty: 3,195 lb; 2,645 lb (350 and 15.7 in extended) 2,756 lb (standard drawbar, 9.8 in extended); 2,205 lb (standard, 13.8 in extended); 3,197 lb (heavy duty, 9.8 in extended); 2,646 lb (heavy duty, 13.8 in extended) ▶ Dimensions & ManeuverabilityOverall Width Not Published 87 in (with fender extension); 74 in (without fender extension); 66.9 in (narrow cab, without fender extension) Wheelbase 92.5 in 88.6 in Ground Clearance ROPS: 17 in; Cab: 15.2 in Not Published Min. Turn Radius without Brakes Not Published Not Published Height to Top of ROPS 100.8 in Not Published Height to Top of ROPS (folded) 78.6 in Not Published Height to Top of Cab Model 101.2 in 106.1 in Overall Length 159.13 in 147.8 in ▶ WeightTractor Weight (Base) OOS: 7,275 lb (shipping weight); Cab: 8,150 lb (shipping weight) 9,811 lb (base machine weight, with all fluids) Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options Not Published 320/85R24 (12.4R24) R1-W radial front and 460/85R30 (18.4R30) R1-W radial rear standard; optional 11.2R28/13.6R38, 380/70R20/480/70R28, 13.6R24/16.9R34, 380/70R24/480/70R34 R1; R3 44x18-20/23.1-26; R4 12.5/80-18/19.5L-24 R1 Agricultural - Front 12.4-24 320/85R24 (12.4R24) R1-W radial R1 Agricultural - Rear 18.4-30 460/85R30 (18.4R30) R1-W radial R3 Turf - Front Not Published 44x18-20 R3 Turf - Rear Not Published 23.1-26 R4 Industrial - Front 12.5/80-18 12.5/80-18 R4 Industrial - Rear 19.5L-24 19.5L-24 ▶ Loader & AttachmentsQuick Attach Loader System 520M; 540M Global carrier in base; John Deere 500-style carrier optional (540R) Loader Model 520M and 540M (previously H240 and H260) 540R (non self-leveling and mechanical self-leveling) Loader Lift Height 520M MSL: 132.0 in 540R: 141.5 in Loader Lift Capacity (Full Height) 520M MSL: 2,606 lb (to maximum height, measured at pivot) 540R NSL: 4,246 lb (measured at pivot) Loader Breakout Force 520M MSL: 4,793 lb (measured at pivot) 540R NSL: 4,945 lbf (measured at pivot) ▶ WarrantyWarranty Length & Coverage Not Published Not Published
