▶ EngineEngine Manufacturer John Deere Kubota Engine Model PowerTech PWL 4045 V3800CR-TIEF4 Engine Type Diesel, turbocharged, aftercooled 4-cylinder, turbocharged and intercooled, common-rail diesel, DPF, DOC and SCR No. of Cylinders 4 4 Displacement 276 in³ 230 in³ Rated Engine Speed 2400 rpm 2400 rpm Engine Power (Gross) 100 hp 105.6 hp PTO Power 85 hp 89 hp Engine Emissions Constraints Tier 4 Tier 4 Cooling System Type Liquid-cooled Liquid-cooled Air Cleaner Dry type with safety element Dry paper, dual element, 8 in diameter, with pre-cleaner Fuel System High Pressure Common Rail Common rail direct injection Alternator OOS: 90 A; Cab: 120 A 60 A ▶ HydraulicsPump Type Tandem gear pump (implement + steering) Gear pump Implement Flow 15.9 gpm 15.7 gpm Steering Flow 6.6 gpm 5.4 gpm Total Hydraulic Flow 22.5 gpm 21.3 gpm Overall Hydraulic Pump Flow 22.5 gpm 21.3 gpm Hydraulic System Type Open Center Open center Rear Remote Hydraulic Flow Not Published 15.7 gpm No. of Standard Remote Valves 2 2 (max 3) No. of Optional Remote Valves 3 1 (3 maximum) ▶ Fluid CapacityFuel Tank Capacity OOS: 25 gal; Cab: 30 gal 27.7 gal Coolant Capacity Cab: 3 gal; OOS: 2.5 gal 11 qt Crankcase Capacity 3.2 gal (with filter) 11.3 qt Transmission / Hydraulic System Capacity 11.5 gal 63.4 qt Front Axle Fluid Capacity MFWD differential housing: 1.3 gal; MFWD wheel hub (each): 0.74 qt 6.3 qt (differential) plus 3.7 qt (each bevel gear case) ▶ PTO & HitchPTO Type Independent, electrohydraulic engagement Live-independent PTO, electro-hydraulic clutch with brake PTO Rear 540/540E rpm 540 rpm (540/540E optional) Mid-PTO Availability Not Published Not Published Category, 3-Point Hitch Category II Category II Hitch Lift Capacity Not Published 7,055 lb (8,600 lb optional) Hitch Lift Capacity (at 24”) 4,630 lb 5,181 lb Lift Control Type Top link draft sensing; mechanical hitch controls Position, draft (top link sensing) and mixed control ▶ Transmission & DrivetrainTransmission Type PowrReverser Fully synchronized main gear shift with electro-hydraulic shuttle No. of Speeds 12F/12R (standard); 24F/12R (optional) 8 forward, 8 reverse Max Travel Speed (Forward) 12F/12R: 21.7 mph; 24F/12R: 24.9 mph (electronically limited) 18.6 mph Max Travel Speed (Reverse) Not Published 18.4 mph Clutch Wet traction clutch Multiple wet disc Differential Lock & Limited Slip Options Pedal-operated differential lock Front: limited-slip differential; Rear: mechanical differential lock ▶ Chassis, Steering & ControlsFrame Type Not Published Not Published Steering Hydrostatic power steering Hydrostatic power steering Brakes Hydraulic wet disc brakes, self-equalizing and self-adjusting Hydraulic wet disc Seat Suspension & Adjustability Not Published Suspension seat with fore and aft travel adjustment, suspension tension knob, backrest tilt adjustment and arm rest Front Axle Type Mechanical front wheel drive (MFWD) Bevel gear type with 55 degree turning angle (4WD) Front Axle Rating 6,615 lb 5,730 lb Drawbar Capacity Standard: 2,755 lb; 2,425 lb (350 and 15.7 in extended). Heavy-Duty: 3,195 lb; 2,645 lb (350 and 15.7 in extended) 3,300 lb ▶ Dimensions & ManeuverabilityOverall Width Not Published 79.1 in Wheelbase 92.5 in 88.6 in Ground Clearance ROPS: 17 in; Cab: 15.2 in 17.7 in (drawbar bracket) Min. Turn Radius without Brakes Not Published 13.8 ft Height to Top of ROPS 100.8 in 99.8 in Height to Top of ROPS (folded) 78.6 in Not Published Height to Top of Cab Model 101.2 in Not Applicable Overall Length 159.13 in 155.9 in ▶ WeightTractor Weight (Base) OOS: 7,275 lb (shipping weight); Cab: 8,150 lb (shipping weight) 6,283 lb Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options Not Published Front: 7.50-18, 9.5L-15, 9.5-22, 10.00-16, 11.2-24, 12.4-24; Rear: 16.9-30, 16.9-34, 18.4-30 R1 Agricultural - Front 12.4-24 12.4-24 R1 Agricultural - Rear 18.4-30 18.4-30 R3 Turf - Front Not Published 9.5L-15 F2 or 27x9.50-15 HF-1 (rib fronts paired with the R3 rears) R3 Turf - Rear Not Published 18.4-26 R3 or 19.5L-24 R3 R4 Industrial - Front 12.5/80-18 9.5L-15 F2 (rib front paired with the R4 rear) R4 Industrial - Rear 19.5L-24 19.5L-24 R4 ▶ Loader & AttachmentsQuick Attach Loader System 520M; 540M Quick coupler, standard; Euro-type quick coupler, optional; tool-free attach and detach; single-lever hydraulic hose coupler, optional Loader Model 520M and 540M (previously H240 and H260) LA1854 Loader Lift Height 520M MSL: 132.0 in 145.7 in (height position); 131.9 in (power position) Loader Lift Capacity (Full Height) 520M MSL: 2,606 lb (to maximum height, measured at pivot) 3,990 lb (height position); 4,144 lb (power position) Loader Breakout Force 520M MSL: 4,793 lb (measured at pivot) LA1854: 5,501 lbf (height position); 6,470 lbf (power position) ▶ WarrantyWarranty Length & Coverage Not Published Basic 24 months or 2,000 hours, powertrain 36 months or 3,000 hours
