▶ EngineEngine Manufacturer John Deere FPT Engine Model PowerTech 4045 PWL F5D Engine Type Diesel, turbocharged, air-to-air aftercooled Turbocharged and intercooled 4-cylinder diesel No. of Cylinders 4 4 Displacement 276 in³ 207 in³ Rated Engine Speed 2100 rpm 2300 rpm Engine Power (Gross) 99.1 hp 98 hp PTO Power 85 hp @ 100 rpm 82 hp Engine Emissions Constraints Tier 4 Tier 4A Cooling System Type Liquid-cooled (Cool-Gard II coolant) Liquid-cooled Air Cleaner Dry air cleaner, primary and secondary elements Dual dry element Fuel System High pressure common rail (HPCR); electronic fuel control Electronic high-pressure common-rail fuel injection Alternator OOS: 90 A; Cab: 120 A; Field-installed option: 200 A, 12 V 120 A ▶ HydraulicsPump Type Tandem gear pump Dual engine-driven pumps (open center) Implement Flow 18.4 gpm 12.5 gpm (16.9 gpm optional) Steering Flow 6.3 gpm 7.3 gpm Total Hydraulic Flow 24.7 gpm 19.8 gpm (12.5 + 7.3, computed) Overall Hydraulic Pump Flow 24.7 gpm 19.8 gpm (12.5 + 7.3, computed) Hydraulic System Type Open center Open center Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves 2 (rear, Dual SCV) 1 No. of Optional Remote Valves 3 rear valves total (3rd rear SCV optional); up to 3 mid SCVs (XI, XII, XIII) for loader functions 2 (3rd remote available through Parts Division) ▶ Fluid CapacityFuel Tank Capacity OOS: 29.6 gal; OOS (High Capacity): 37.2 gal; Cab: 37 gal; Cab (High Capacity): 44.9 gal 30.3 gal Coolant Capacity OOS: 5.2 gal; Cab: 5.8 gal Not Published Crankcase Capacity 3.4 gal Not Published Transmission / Hydraulic System Capacity 10.4 gal Not Published Front Axle Fluid Capacity Differential housing (MFWD): 1.3 gal; Wheel hub (each): 0.2 gal Not Published ▶ PTO & HitchPTO Type Independent rear PTO, electro-hydraulic wet disc clutch: 540/540E standard, 540/540E/1000 optional Independent, mechanical engagement PTO Rear 540/540E rpm standard; 1000 rpm optional 540/1000 (base); 540 (optional) Mid-PTO Availability Not Published Not Published Category, 3-Point Hitch Category II (convertible to I) Category II (ball ends convert to Category I) Hitch Lift Capacity 5,305 lb standard; 6,114 lb optional Not Published Hitch Lift Capacity (at 24”) 5,159 lb standard; 5,954 lb optional 5,620 lb Lift Control Type Mechanical or electrohydraulic; lower-link draft sensing Single-lever position control with draft-sensing top link ▶ Transmission & DrivetrainTransmission Type PowrReverser 16F/16R (base); optional 32F/16R PowrReverser Hi-Lo; PowrQuad PLUS 16F/16R and Powr8 32F/16R also offered Not Published No. of Speeds 16F/16R standard (PowrReverser); 32F/16R optional (PowrReverser Hi-Lo); 16F/16R (PowrQuad PLUS); 32F/16R (Powr8) 12F/12R mechanical (20F/12R mechanical with creeper; 12F/12R power shuttle; 20F/20R optional) Max Travel Speed (Forward) 16F/16R PowrReverser, top gear (D-4): 30K config: 18.64 mph; 40K config: 21.72 mph (480/70R28 Mitas rear tires, 2200 rpm) Not Published Max Travel Speed (Reverse) 16F/16R PowrReverser, top gear (D-4): 30K config: 20.54 mph; 40K config: 23.94 mph (480/70R28 Mitas rear tires, 2200 rpm) Not Published Clutch Wet Not Published Differential Lock & Limited Slip Options Electro-hydraulic rear differential lock, engage on the go Mechanical rear differential lock ▶ Chassis, Steering & ControlsFrame Type Cast iron mid-frame Not Published Steering Not Published Power steering Brakes Not Published Wet disc (mechanical on ROPS, hydraulic on cab) Seat Suspension & Adjustability OOS: isolated mechanical seat (fore/aft, weight, and lumbar adjustment); Cab: mechanical suspension seat standard, air suspension seat optional; adjustable weight range 88-330 lb Air suspension seat with 15-degree swivel (optional, cab) Front Axle Type MFWD 2WD or MFD Front Axle Rating 6,613 lb (MFWD, max permissible front axle load) Not Published Drawbar Capacity Standard drawbar: 2,756 lb; 2,425 lb; 2,205 lb. Heavy-duty drawbar: 3,197 lb; 2,646 lb Not Published ▶ Dimensions & ManeuverabilityOverall Width Cab, with fender extension: 85.6 in; Cab, without fender extension: 74 in; OOS, with fender extension: 69.1 in; OOS, without fender extension: 51.7 in 83 in Wheelbase 92.5 in 89 in (MFD) Ground Clearance Not Published Not Published Min. Turn Radius without Brakes Not Published Not Published Height to Top of ROPS 102.1 in 103 in Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model 102.9 in 100 in Overall Length 149.5 in 149 in (MFD cab, 16.9R-34 rear tires) ▶ WeightTractor Weight (Base) 2WD, OOS: 8,140 lb; 2WD, Cab: 8,580 lb; MFWD, OOS: 8,765 lb; MFWD, Cab: 9,185 lb (shipping weight, less weights) 7,937 lb (MFD cab, 16.9R-34 rear tires) Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options Not Published Not Published R1 Agricultural - Front 12.4R24 (320/85R24) R1W Radial Not Published R1 Agricultural - Rear 18.4R30 (460/85R30) R1W Radial 16.9R-34 R3 Turf - Front Not Published Not Published R3 Turf - Rear Not Published Not Published R4 Industrial - Front Not Published Not Published R4 Industrial - Rear Not Published Not Published ▶ Loader & AttachmentsQuick Attach Loader System Not Published Skid steer-style quick attach (hydraulic coupler) Loader Model 540M NSL; 540M SL; 540R NSL; 540R SL; H310 NSL (MFWD required for H310) L620; L630; L735 Loader Lift Height 540M NSL: 138 in; 540M SL: 138 in; 540R NSL: 141 in; 540R SL: 141 in; H310 NSL: 149 in L620: 126.3 in (NSL) / 125.9 in (MSL); L630: 134 in (NSL) / 135 in (MSL); L735: 137 in Loader Lift Capacity (Full Height) 540M NSL: 3,674 lb; 540M SL: 3,058 lb; 540R NSL: 4,246 lb; 540R SL: 3,395 lb; H310 NSL: 4,644 lb (measured at pivot) L620: 3,461 lb (NSL) / 3,573 lb (MSL); L630: 3,849 lb (NSL) / 4,204 lb (MSL); L735: 4,034 lb (NSL) / 3,505 lb (MSL) (maximum height at pins) Loader Breakout Force 540M NSL: 6,686 lbf; 540M SL: 5,513 lbf; 540R NSL: 4,945 lbf; 540R SL: 5,291 lbf; H310 NSL: 6,767 lbf (measured at pivot) L620: 5,530 lb (NSL) / 5,483 lb (MSL); L630: 6,649 lb (NSL) / 6,767 lb (MSL); L735: 4,960 lb (NSL) / 4,122 lb (MSL) (breakout at pins) ▶ WarrantyWarranty Length & Coverage Not Published Not Published
