▶ EnginePTO Power — 16.2 hp Alternator — 40 A Air Cleaner — Dual element Engine Type — Diesel Fuel System — Indirect injection Displacement — 60.6 in³ No. of Cylinders — 3 Rated Engine Speed — 3200 rpm Cooling System Type — Water pump Engine Manufacturer — Yanmar Engine Power (Gross) — 21.5 hp @ 200 rpm Engine Emissions Constraints — Tier 4 ▶ WeightTractor Weight (Base) — Open station: 1446 lb Weight with ROPS and Loader — 1446 lb ▶ WarrantyWarranty Length & Coverage — 6-year powertrain warranty (as stated in 2016 review; current terms may vary) ▶ HydraulicsPump Type — Single gear Steering Flow — 3.5 gpm Implement Flow — 3.5 gpm Total Hydraulic Flow — 6.3 gpm 23.8 lpm Hydraulic System Type — Open center System Operating Pressure — 2000 PSI Rear Remote Hydraulic Flow — 3.5 gpm (13.3 lpm) implement circuit Overall Hydraulic Pump Flow — 6.3 gpm total (2.8 gpm steering + 3.5 gpm implement) No. of Optional Remote Valves — 1 additional (optional 3rd SCV kit; standard is 2 mid-SCVs) ▶ PTO & HitchPTO Rear — 540 rpm PTO Type — independent Lift Control Type — Position control (rockshaft lever) Hitch Lift Capacity — 1,433 lbs 1,433 lb Mid-PTO Availability — 2100 rpm Category, 3-Point Hitch — Limited Category 1 Hitch Lift Capacity (at 24”) — 758 lb ▶ Tire OptionsR3 Turf - Rear — 26x12-12 R3 Turf - Front — 18x8.50-10 R4 Industrial - Rear — 26x12-12 R4 Industrial - Front — 18x8.5-10 R1 Agricultural - Rear — 26x12-12 R1 Agricultural - Front — 18x8.5-10 ▶ Fluid CapacityCoolant Capacity — 0.98 gal Crankcase Capacity — 0.71 gal Fuel Tank Capacity — 5.6 gal Front Axle Fluid Capacity — 0.74 gal Transmission / Hydraulic System Capacity — 3.3 gal ▶ Loader & AttachmentsLoader Lift Height — 71.2 in (D120 and H120 loaders) Quick Attach Loader System — Quik-Park Loader System Loader Lift Capacity (Full Height) — D120: 570 lb; H120: 512 lb (at full height, 71.2 in) ▶ Transmission & DrivetrainClutch — Wet disk No. of Speeds — Infinite (hydrostatic, 2-range) Transmission Type — Hydrostatic - two range Max Travel Speed (Forward) — 9.1 mph Max Travel Speed (Reverse) — 9.1 mph Differential Lock & Limited Slip Options — Differential lock Yes; Limited slip differential No ▶ Chassis, Steering & ControlsBrakes — Wet disc (left-hand pedal) Steering — Power Frame Type — Open center frame with two-post foldable ROPS Front Axle Type — MFWD (Mechanical Front-Wheel Drive) 4WD Front Axle Rating — 1349 lb Seat Suspension & Adjustability — Spring suspension seat, adjusts fore/aft ▶ Dimensions & ManeuverabilityWheelbase — 57.1 in. Overall Width — 47.2 in with R3 tires; 47.3 in with R4 tires Ground Clearance — 7.7 in. Height to Top of ROPS — 78.6 in Min. Turn Radius without Brakes — 2.51 m 8.2 ft Overall Length with 3-Point Hitch — 87.6 in
