▶ EngineEngine Manufacturer John Deere John Deere Engine Model PowerTech 4045 EWL John Deere PowerTech 4.5L diesel Engine Type Diesel, turbocharged with intercooler, 4-valve HPCR 4-cylinder, turbocharged and intercooled diesel, 4-valve high pressure common rail No. of Cylinders 4 4 Displacement 276 in³ 276 in³ Rated Engine Speed 2200 rpm 2200 rpm Engine Power (Gross) 128.5 hp 90 hp PTO Power 113.3 hp 75 hp @ 100 rpm Engine Emissions Constraints Tier 4 Tier 4 Cooling System Type Not Published Liquid-cooled Air Cleaner Dry type air cleaner with safety element Dry type with safety element Fuel System High-pressure common rail (HPCR), 4-valve High pressure common rail, 4 valve, electronic fuel control Alternator 120 A, 12 V 200 A ▶ HydraulicsPump Type Tandem gear pump Tandem gear pump (open center); variable axial-piston implement pump (PFC, optional) Implement Flow 18.4 gpm 19.3 gpm (open center); 30.9 gpm (PFC) Steering Flow 6.3 gpm 6.3 gpm (open center) Total Hydraulic Flow 25.6 gpm 25.6 gpm (open center) Overall Hydraulic Pump Flow 25.6 gpm 25.6 gpm (open center); 30.9 gpm (PFC) Hydraulic System Type Open center Open center (standard); closed center PFC (optional) Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves 2 (rear); 2 (mid) 2 rear and 2 mid (stackable) No. of Optional Remote Valves Up to 3 total (rear); up to 3 total (mid) Rear: 3 (mechanical or proportional EH, optional; 4th rear by conversion kit); Mid: 3 Deluxe (mechanical or EH, optional) ▶ Fluid CapacityFuel Tank Capacity 43.7 gal (Standard Cab) 38 gal Coolant Capacity Not Published 4.25 gal Crankcase Capacity Not Published 3.1 gal Transmission / Hydraulic System Capacity Not Published 11.75 gal (open center); 12.5 gal (closed center PFC) Front Axle Fluid Capacity Not Published 1.3 gal (MFWD differential housing); 0.2 gal (each wheel hub) ▶ PTO & HitchPTO Type Independent rear PTO, electro-hydraulic clutch Independent, electro-hydraulic engagement, wet PTO clutch, reversible 540/1000 shaft PTO Rear 540/540E standard; 540/540E/1000 optional 540/540E/1000 rpm Mid-PTO Availability Not Published Not Published Category, 3-Point Hitch Category II (convertible to I) Category II (telescoping draft links with Category II balls) Hitch Lift Capacity Not Published 7,158 lb; 8,157 lb throughout lift range at hitch ball; 11,122 lb / 12,515 lb maximum Hitch Lift Capacity (at 24”) 6,975 lb standard; 7,868 lb optional 6,975 lb; 7,868 lb throughout lift range Lift Control Type Electrohydraulic Electro-hydraulic hitch with fender controls, lower-link draft sensing ▶ Transmission & DrivetrainTransmission Type PowrQuad PLUS 16F/16R or Powr8 32F/16R (cab only) CommandQuad 16F/16R manual with electronic range and gear shifting, AutoClutch and wet traction clutch (standard); CommandQuad 16F/16R Auto, CommandQuad 16F/16R manual with creeper, or Command8 32F/16R (optional) No. of Speeds 16F/16R (PowrQuad PLUS); 32F/16R (Powr8) 16F/16R (CommandQuad, standard); 32F/16R (Command8, optional) Max Travel Speed (Forward) 24 mph 22.0 mph (D4, 16/16 transmission, 480/70R28 rear tires) Max Travel Speed (Reverse) Not Published 18.6 mph Clutch Wet Wet traction clutch with AutoClutch Differential Lock & Limited Slip Options Electro-hydraulic rear differential lock Electro-hydraulic differential lock ▶ Chassis, Steering & ControlsFrame Type Cast iron mid-frame design Cab standard with air conditioning; mechanical front-wheel drive (MFWD) Steering Power steering Hydrostatic power steering Brakes Hydraulic wet disc brakes, self-equalizing and self-adjusting Hydraulic wet disc, self-equalizing and self-adjusting, lockable turning brakes; electronic park brake Seat Suspension & Adjustability Mechanical-suspension seat, standard; air-suspension seat, optional; heated low-frequency air-suspension seat, optional Not Published Front Axle Type MFWD MFWD, electro-hydraulic engagement, planetary final drives Front Axle Rating Not Published 7,937 lb (MFWD closed center); 7,055 lb (MFWD open center) Drawbar Capacity 3,197 lb 2,756 lb (standard drawbar, 9.8 in extended); 2,205 lb (standard, 13.8 in extended); 3,197 lb (heavy duty, 9.8 in extended); 2,646 lb (heavy duty, 13.8 in extended) ▶ Dimensions & ManeuverabilityOverall Width Not Published 87 in (with fender extension); 74 in (without fender extension); 66.9 in (narrow cab, without fender extension) Wheelbase 92.5 in 88.6 in Ground Clearance Not Published Not Published Min. Turn Radius without Brakes 13.1 ft Not Published Height to Top of ROPS Not Applicable Not Published Height to Top of ROPS (folded) Not Applicable Not Published Height to Top of Cab Model Not Published 106.1 in Overall Length Not Published 147.8 in ▶ WeightTractor Weight (Base) 9,185 lb 9,811 lb (base machine weight, with all fluids) Weight with ROPS and Loader Not Applicable Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options R1 Agricultural 320/85R24 (12.4R24) R1-W radial front and 460/85R30 (18.4R30) R1-W radial rear standard; optional 11.2R28/13.6R38, 380/70R20/480/70R28, 13.6R24/16.9R34, 380/70R24/480/70R34 R1; R3 44x18-20/23.1-26; R4 12.5/80-18/19.5L-24 R1 Agricultural - Front 12.4R24 320/85R24 (12.4R24) R1-W radial R1 Agricultural - Rear 18.4R30 460/85R30 (18.4R30) R1-W radial R3 Turf - Front Not Published 44x18-20 R3 Turf - Rear Not Published 23.1-26 R4 Industrial - Front 12.5/80-18 in, 12PR R4 Bias 12.5/80-18 R4 Industrial - Rear 19.5L-24 in, 10PR R4 Bias 19.5L-24 ▶ Loader & AttachmentsQuick Attach Loader System Not Published Global carrier in base; John Deere 500-style carrier optional (540R) Loader Model 520M (4WD only); 540M (NSL and MSL); 540R (NSL and MSL); 600M (NSL only) 540R (non self-leveling and mechanical self-leveling) Loader Lift Height 520M: NSL/MSL 130-132 in; 540M: NSL 137-141 in, MSL 138-141 in; 540R: 141.85 in; 600M: NSL 148.8-152.8 in 540R: 141.5 in Loader Lift Capacity (Full Height) 520M (4WD): NSL 3,335-3,612 lb, MSL 2,460-2,661 lb; 540M: NSL 2,394-2,666 lb, MSL 3,117-3,309 lb; 540R: 3,406 lb; 600M: NSL 3,104-3,236 lb 540R NSL: 4,246 lb (measured at pivot) Loader Breakout Force Not Published 540R NSL: 4,945 lbf (measured at pivot) ▶ WarrantyWarranty Length & Coverage Basic 24 months or 2,000 hours, whole-machine standard agricultural equipment term Not Published
