▶ EngineEngine Manufacturer John Deere John Deere Engine Model PowerTech 4045 EWL PowerTech 4045 PWL Engine Type Diesel, turbocharged with intercooler, 4-valve HPCR Diesel, turbocharged, air-to-air aftercooled No. of Cylinders 4 4 Displacement 276 in³ 276 in³ Rated Engine Speed 2200 rpm 2100 rpm Engine Power (Gross) 128.5 hp 99.1 hp PTO Power 113.3 hp 85 hp @ 100 rpm Engine Emissions Constraints Tier 4 Tier 4 Cooling System Type Not Published Liquid-cooled (Cool-Gard II coolant) Air Cleaner Dry type air cleaner with safety element Dry air cleaner, primary and secondary elements Fuel System High-pressure common rail (HPCR), 4-valve High pressure common rail (HPCR); electronic fuel control Alternator 120 A, 12 V OOS: 90 A; Cab: 120 A; Field-installed option: 200 A, 12 V ▶ HydraulicsPump Type Tandem gear pump Tandem gear pump Implement Flow 18.4 gpm 18.4 gpm Steering Flow 6.3 gpm 6.3 gpm Total Hydraulic Flow 25.6 gpm 24.7 gpm Overall Hydraulic Pump Flow 25.6 gpm 24.7 gpm Hydraulic System Type Open center Open center Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves 2 (rear); 2 (mid) 2 (rear, Dual SCV) No. of Optional Remote Valves Up to 3 total (rear); up to 3 total (mid) 3 rear valves total (3rd rear SCV optional); up to 3 mid SCVs (XI, XII, XIII) for loader functions ▶ Fluid CapacityFuel Tank Capacity 43.7 gal (Standard Cab) OOS: 29.6 gal; OOS (High Capacity): 37.2 gal; Cab: 37 gal; Cab (High Capacity): 44.9 gal Coolant Capacity Not Published OOS: 5.2 gal; Cab: 5.8 gal Crankcase Capacity Not Published 3.4 gal Transmission / Hydraulic System Capacity Not Published 10.4 gal Front Axle Fluid Capacity Not Published Differential housing (MFWD): 1.3 gal; Wheel hub (each): 0.2 gal ▶ PTO & HitchPTO Type Independent rear PTO, electro-hydraulic clutch Independent rear PTO, electro-hydraulic wet disc clutch: 540/540E standard, 540/540E/1000 optional PTO Rear 540/540E standard; 540/540E/1000 optional 540/540E rpm standard; 1000 rpm optional Mid-PTO Availability Not Published Not Published Category, 3-Point Hitch Category II (convertible to I) Category II (convertible to I) Hitch Lift Capacity Not Published 5,305 lb standard; 6,114 lb optional Hitch Lift Capacity (at 24”) 6,975 lb standard; 7,868 lb optional 5,159 lb standard; 5,954 lb optional Lift Control Type Electrohydraulic Mechanical or electrohydraulic; lower-link draft sensing ▶ Transmission & DrivetrainTransmission Type PowrQuad PLUS 16F/16R or Powr8 32F/16R (cab only) PowrReverser 16F/16R (base); optional 32F/16R PowrReverser Hi-Lo; PowrQuad PLUS 16F/16R and Powr8 32F/16R also offered No. of Speeds 16F/16R (PowrQuad PLUS); 32F/16R (Powr8) 16F/16R standard (PowrReverser); 32F/16R optional (PowrReverser Hi-Lo); 16F/16R (PowrQuad PLUS); 32F/16R (Powr8) Max Travel Speed (Forward) 24 mph 16F/16R PowrReverser, top gear (D-4): 30K config: 18.64 mph; 40K config: 21.72 mph (480/70R28 Mitas rear tires, 2200 rpm) Max Travel Speed (Reverse) Not Published 16F/16R PowrReverser, top gear (D-4): 30K config: 20.54 mph; 40K config: 23.94 mph (480/70R28 Mitas rear tires, 2200 rpm) Clutch Wet Wet Differential Lock & Limited Slip Options Electro-hydraulic rear differential lock Electro-hydraulic rear differential lock, engage on the go ▶ Chassis, Steering & ControlsFrame Type Cast iron mid-frame design Cast iron mid-frame Steering Power steering Not Published Brakes Hydraulic wet disc brakes, self-equalizing and self-adjusting Not Published Seat Suspension & Adjustability Mechanical-suspension seat, standard; air-suspension seat, optional; heated low-frequency air-suspension seat, optional OOS: isolated mechanical seat (fore/aft, weight, and lumbar adjustment); Cab: mechanical suspension seat standard, air suspension seat optional; adjustable weight range 88-330 lb Front Axle Type MFWD MFWD Front Axle Rating Not Published 6,613 lb (MFWD, max permissible front axle load) Drawbar Capacity 3,197 lb Standard drawbar: 2,756 lb; 2,425 lb; 2,205 lb. Heavy-duty drawbar: 3,197 lb; 2,646 lb ▶ Dimensions & ManeuverabilityOverall Width Not Published Cab, with fender extension: 85.6 in; Cab, without fender extension: 74 in; OOS, with fender extension: 69.1 in; OOS, without fender extension: 51.7 in Wheelbase 92.5 in 92.5 in Ground Clearance Not Published Not Published Min. Turn Radius without Brakes 13.1 ft Not Published Height to Top of ROPS Not Applicable 102.1 in Height to Top of ROPS (folded) Not Applicable Not Published Height to Top of Cab Model Not Published 102.9 in Overall Length Not Published 149.5 in ▶ WeightTractor Weight (Base) 9,185 lb 2WD, OOS: 8,140 lb; 2WD, Cab: 8,580 lb; MFWD, OOS: 8,765 lb; MFWD, Cab: 9,185 lb (shipping weight, less weights) Weight with ROPS and Loader Not Applicable Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options R1 Agricultural Not Published R1 Agricultural - Front 12.4R24 12.4R24 (320/85R24) R1W Radial R1 Agricultural - Rear 18.4R30 18.4R30 (460/85R30) R1W Radial R3 Turf - Front Not Published Not Published R3 Turf - Rear Not Published Not Published R4 Industrial - Front 12.5/80-18 in, 12PR R4 Bias Not Published R4 Industrial - Rear 19.5L-24 in, 10PR R4 Bias Not Published ▶ Loader & AttachmentsQuick Attach Loader System Not Published Not Published Loader Model 520M (4WD only); 540M (NSL and MSL); 540R (NSL and MSL); 600M (NSL only) 540M NSL; 540M SL; 540R NSL; 540R SL; H310 NSL (MFWD required for H310) Loader Lift Height 520M: NSL/MSL 130-132 in; 540M: NSL 137-141 in, MSL 138-141 in; 540R: 141.85 in; 600M: NSL 148.8-152.8 in 540M NSL: 138 in; 540M SL: 138 in; 540R NSL: 141 in; 540R SL: 141 in; H310 NSL: 149 in Loader Lift Capacity (Full Height) 520M (4WD): NSL 3,335-3,612 lb, MSL 2,460-2,661 lb; 540M: NSL 2,394-2,666 lb, MSL 3,117-3,309 lb; 540R: 3,406 lb; 600M: NSL 3,104-3,236 lb 540M NSL: 3,674 lb; 540M SL: 3,058 lb; 540R NSL: 4,246 lb; 540R SL: 3,395 lb; H310 NSL: 4,644 lb (measured at pivot) Loader Breakout Force Not Published 540M NSL: 6,686 lbf; 540M SL: 5,513 lbf; 540R NSL: 4,945 lbf; 540R SL: 5,291 lbf; H310 NSL: 6,767 lbf (measured at pivot) ▶ WarrantyWarranty Length & Coverage Basic 24 months or 2,000 hours, whole-machine standard agricultural equipment term Not Published
