▶ EngineEngine Manufacturer John Deere Mahindra Engine Model PowerTech 4045 EWL Not Published Engine Type Diesel, turbocharged with intercooler, 4-valve HPCR 4-cylinder, liquid-cooled inline diesel No. of Cylinders 4 4 Displacement 276 in³ 215.6 in³ Rated Engine Speed 2200 rpm 2300 rpm Engine Power (Gross) 128.5 hp 125 hp PTO Power 113.3 hp 106 hp Engine Emissions Constraints Tier 4 Tier 4 Cooling System Type Not Published Liquid-cooled Air Cleaner Dry type air cleaner with safety element Not Published Fuel System High-pressure common rail (HPCR), 4-valve Common Rail Diesel Technology (mCRD) Alternator 120 A, 12 V Not Published ▶ HydraulicsPump Type Tandem gear pump Not Published Implement Flow 18.4 gpm 21.2 gpm Steering Flow 6.3 gpm 9.25 gpm Total Hydraulic Flow 25.6 gpm Not Published Overall Hydraulic Pump Flow 25.6 gpm Not Published Hydraulic System Type Open center Open center, position and draft control, telescoping stabilizers and flex links Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves 2 (rear); 2 (mid) 2 (9125 S); 3 (9125 P) No. of Optional Remote Valves Up to 3 total (rear); up to 3 total (mid) One (3rd outlet on S models; 4th outlet on P model) ▶ Fluid CapacityFuel Tank Capacity 43.7 gal (Standard Cab) Not Published Coolant Capacity Not Published Not Published Crankcase Capacity Not Published Not Published Transmission / Hydraulic System Capacity Not Published Not Published Front Axle Fluid Capacity Not Published Not Published ▶ PTO & HitchPTO Type Independent rear PTO, electro-hydraulic clutch Independent PTO Rear 540/540E standard; 540/540E/1000 optional 540 @ 2220 rpm, 1000 @ 2227 rpm (9125 S); 540 @ 2220 rpm, 750 @ 2208 rpm, 1000 @ 2227 rpm (9125 P) Mid-PTO Availability Not Published Not Published Category, 3-Point Hitch Category II (convertible to I) Category II with telescopic link ends Hitch Lift Capacity Not Published Not Published Hitch Lift Capacity (at 24”) 6,975 lb standard; 7,868 lb optional 5,787 lb (9125 S); 7,628 lb (9125 P) Lift Control Type Electrohydraulic Electronic draft control with fender switches ▶ Transmission & DrivetrainTransmission Type PowrQuad PLUS 16F/16R or Powr8 32F/16R (cab only) Power shuttle with synchromesh No. of Speeds 16F/16R (PowrQuad PLUS); 32F/16R (Powr8) 12F / 12R (9125 S); 24F / 24R + 8 creepers (9125 P) Max Travel Speed (Forward) 24 mph Not Published Max Travel Speed (Reverse) Not Published Not Published Clutch Wet Not Published Differential Lock & Limited Slip Options Electro-hydraulic rear differential lock Not Published ▶ Chassis, Steering & ControlsFrame Type Cast iron mid-frame design Not Published Steering Power steering Power steering Brakes Hydraulic wet disc brakes, self-equalizing and self-adjusting Wet disc Seat Suspension & Adjustability Mechanical-suspension seat, standard; air-suspension seat, optional; heated low-frequency air-suspension seat, optional Seat with adjustable air-suspension, folding adjustable armrest, recline and adjustable headrest Front Axle Type MFWD Not Published Front Axle Rating Not Published Not Published Drawbar Capacity 3,197 lb Not Published ▶ Dimensions & ManeuverabilityOverall Width Not Published 91.3 in Wheelbase 92.5 in Not Published Ground Clearance Not Published Not Published Min. Turn Radius without Brakes 13.1 ft Not Published Height to Top of ROPS Not Applicable Not Published Height to Top of ROPS (folded) Not Applicable Not Published Height to Top of Cab Model Not Published 107 in Overall Length Not Published 169.3 in ▶ WeightTractor Weight (Base) 9,185 lb 9,385 lb Weight with ROPS and Loader Not Applicable Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options R1 Agricultural Not Published R1 Agricultural - Front 12.4R24 Not Published R1 Agricultural - Rear 18.4R30 Not Published R3 Turf - Front Not Published Not Published R3 Turf - Rear Not Published Not Published R4 Industrial - Front 12.5/80-18 in, 12PR R4 Bias Not Published R4 Industrial - Rear 19.5L-24 in, 10PR R4 Bias Not Published ▶ Loader & AttachmentsQuick Attach Loader System Not Published Skid steer style quick attach couplers Loader Model 520M (4WD only); 540M (NSL and MSL); 540R (NSL and MSL); 600M (NSL only) 9125L Loader Lift Height 520M: NSL/MSL 130-132 in; 540M: NSL 137-141 in, MSL 138-141 in; 540R: 141.85 in; 600M: NSL 148.8-152.8 in 162 in Loader Lift Capacity (Full Height) 520M (4WD): NSL 3,335-3,612 lb, MSL 2,460-2,661 lb; 540M: NSL 2,394-2,666 lb, MSL 3,117-3,309 lb; 540R: 3,406 lb; 600M: NSL 3,104-3,236 lb 5,415 lb (at pivot pin) Loader Breakout Force Not Published 6,874 lb (at pivot pin) ▶ WarrantyWarranty Length & Coverage Basic 24 months or 2,000 hours, whole-machine standard agricultural equipment term Not Published
