▶ EngineEngine Manufacturer John Deere FPT Engine Model 3029D R 753 IE4 Engine Type 3-cylinder liquid-cooled diesel, naturally aspirated, direct injection 3-cylinder, FPT turbocharged & aftercooled No. of Cylinders 3 3 Displacement 179 in³ 135.9 in³ Rated Engine Speed 2400 rpm 2600 rpm Engine Power (Gross) 53 hp 53 hp PTO Power 45 hp 45 hp Engine Emissions Constraints Not Published Tier 4 Cooling System Type Liquid-cooled Liquid-cooled Air Cleaner Dry type with safety element Dry Fuel System Direct injection, rotary injection pump with electric shutoff Electronic high pressure common rail Alternator 40 A 75 A ▶ HydraulicsPump Type Tandem gear pump Engine-driven dual gear-type Implement Flow 11.4 gpm 11.9 gpm Steering Flow 6.8 gpm 5.5 gpm Total Hydraulic Flow 18.2 gpm 17.4 gpm (11.9 + 5.5, computed) Overall Hydraulic Pump Flow 18.2 gpm Not Published Hydraulic System Type Open center Open center Rear Remote Hydraulic Flow 11.4 gpm Not Published No. of Standard Remote Valves Not Published 1 No. of Optional Remote Valves Not Published 2 ▶ Fluid CapacityFuel Tank Capacity 18 gal (open station); 23 gal (cab) 17.2 gal Coolant Capacity 10 qt Not Published Crankcase Capacity 9 qt Not Published Transmission / Hydraulic System Capacity 10 gal (CollarShift and SyncShuttle, dry clutch); 11.5 gal (PowrReverser, wet clutch) Not Published Front Axle Fluid Capacity 5.2 qt (MFWD axle housing); 0.6 qt (each wheel hub); 5.7 qt (MFWD assembly) Not Published ▶ PTO & HitchPTO Type Fully independent 540 rpm PTO; shiftable 540/540E with SyncShuttle transmission; lever operated clutch Independent PTO Rear 540 rpm (at 2400 engine rpm); 540E (at 1700 engine rpm, SyncShuttle) 540 / 540E Mid-PTO Availability Not Published Not Published Category, 3-Point Hitch Category I and II Category I/II Hitch Lift Capacity Not Published Not Published Hitch Lift Capacity (at 24”) 3374 lb 2,701 lb Lift Control Type Position and depth control, top link draft sensing Mechanical Draft Control (MDC), top link sensing ▶ Transmission & DrivetrainTransmission Type CollarShift standard; SyncShuttle optional; PowrReverser optional 8x8 mechanical shuttle (dry clutch) No. of Speeds 9 forward, 3 reverse (CollarShift and SyncShuttle); 12 forward, 12 reverse (PowrReverser) 8 forward / 8 reverse Max Travel Speed (Forward) 14.98 mph (CollarShift and SyncShuttle, gear C-3); 14.89 mph (PowrReverser, gear C-4) Not Published Max Travel Speed (Reverse) 12.78 mph (CollarShift and SyncShuttle, gear C-R); 17.21 mph (PowrReverser, gear C-4 reverse) Not Published Clutch Dual dry clutch (CollarShift and SyncShuttle); multi-disk wet clutch (PowrReverser) Dry clutch Differential Lock & Limited Slip Options Not Published Mechanical rear differential lock; limited-slip MFD front axle ▶ Chassis, Steering & ControlsFrame Type Two-post ROPS; cab optional; two-wheel drive or MFWD Not Published Steering Hydrostatic power steering Power steering Brakes Wet disk, self-equalizing, self-adjusting Wet disc Seat Suspension & Adjustability Not Published Not Published Front Axle Type Two-wheel drive or mechanical front wheel drive (MFWD) 2WD or MFD with limited slip Front Axle Rating 2720 to 4700 lb (2WD, by front tire, no loader); 2760 to 4620 lb (MFWD, by front tire, without loader) Not Published Drawbar Capacity 1675 lb Not Published ▶ Dimensions & ManeuverabilityOverall Length with 3-Point Hitch 122.6 in (2WD); 125.9 in (MFWD) (w/o 3P, less hitch, drawbar and front weights) (without 3-point hitch) MFD: 134.0 in; 2WD: 129.5 in Overall Width 65.4 in 67.5 in Wheelbase 80.7 in MFD: 77.7 in; 2WD: 77.5 in Ground Clearance 19.5 in (2WD front axle); 13.4 in (MFWD front axle); 15.8 in (2WD drawbar); 14.9 in (MFWD drawbar) Not Published Min. Turn Radius without Brakes 11.3 ft (2WD); 12.5 ft (MFWD engaged); 11.3 ft (MFWD disengaged) MFD: 190.9 in; 2WD: 135.8 in Height to Top of ROPS 87.8 in MFD: 97.4 in; 2WD: 92.7 in Height to Top of ROPS (folded) 74.6 in 75.9 in Height to Top of Cab Model 97 in Not Published ▶ WeightTractor Weight (Base) 4250 lb (2WD); 4650 lb (MFWD); add approximately 1000 lb with cab MFD: 5,060 lb; 2WD: 4,442 lb Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options Front: 6.50-16, 7.50-16, 9.5L-15, 27/9.5L-15, 11L-15 (2WD); 9.5L-16, 8.3-24, 9.5-24, 10.5/80-18, 11.2-24 (MFWD). Rear: 13.6-28, 14.9-24, 14.9-28, 16.9-24, 16.9-28, 16.9-30, 18.4-16.1 R1 agricultural (bar tread) or R4 industrial tread R1 Agricultural - Front 6.5-16 (2WD); 8.3-24 (MFWD) MFD: 8.3x24; 2WD: 7.5x16 R1 Agricultural - Rear 13.6-28 MFD: 13.6x28; 2WD: 13.6x28 R3 Turf - Front Not Published Not Published R3 Turf - Rear Not Published Not Published R4 Industrial - Front Not Published MFD: 12.5x18 R4 Industrial - Rear Not Published MFD: 18.4x24 ▶ Loader & AttachmentsQuick Attach Loader System Not Published Compatible loaders: L545, L555 Loader Model 521; 541; 541 self-leveling L545; L555 Loader Lift Height 521: 122 in; 541: 126 in; 541 self-leveling: 130 in L545: 106 in; L555: 105 in Loader Lift Capacity (Full Height) 521: 2500 lb; 541: 2500 lb; 541 self-leveling: 2800 lb (full at pin) L545 NSL: 1,565 lb; L545 MSL: 2,205 lb; L555 NSL: 1,940 lb; L555 MSL: 2,734 lb Loader Breakout Force 521: 3485 lbf; 541: 3484 lbf; 541 self-leveling: 4125 lbf (at pin) L545: 3,131 lb; L555: 3,527 lb ▶ WarrantyWarranty Length & Coverage Not Published Not Published
