▶ EngineEngine Manufacturer John Deere John Deere Engine Model CD3029DLV50 John Deere PowerTech 3029 Engine Type 3-cylinder, naturally aspirated, direct injection, liquid-cooled diesel Diesel, turbocharged, liquid-cooled No. of Cylinders 3 3 Displacement 179 in³ 179 in³ Rated Engine Speed 2400 rpm 2100 rpm Engine Power (Gross) 53 hp 50 hp PTO Power 45 hp 37 hp Engine Emissions Constraints Not Published Tier 4 Cooling System Type Liquid-cooled Liquid-cooled Air Cleaner Dry type with safety element Dry Type Air Cleaner with Safety Element Fuel System Direct injection, rotary injection pump, electric shutoff Not Published Alternator 40 A 40 A ▶ HydraulicsPump Type Tandem gear pump Not Published Implement Flow 11.4 gpm 11.4 gpm Steering Flow 6.8 gpm 6.8 gpm Total Hydraulic Flow 18.2 gpm 18.2 gpm Overall Hydraulic Pump Flow 18.2 gpm 18.2 gpm Hydraulic System Type Open center Open Center Rear Remote Hydraulic Flow 11.4 gpm Not Published No. of Standard Remote Valves Not Published 1 No. of Optional Remote Valves Not Published 2 ▶ Fluid CapacityFuel Tank Capacity 18 gal (open station); 22 gal (cab) 19.6 gal Coolant Capacity 10 qt 10 qt Crankcase Capacity 9 qt 9 qt Transmission / Hydraulic System Capacity 10 gal (CollarShift and SyncShuttle, dry clutch); 11.5 gal (PowrReverser, wet clutch) 10.3 gal Front Axle Fluid Capacity 5.3 qt (MFWD differential housing); 0.63 qt (each wheel hub) MFWD Dana axle: 1.18 gal differential housing, 0.21 gal each wheel hub; MFWD Carraro axle: 1.03 gal differential housing, 0.15 gal each side reduction gear ▶ PTO & HitchPTO Type Fully independent 540 rpm PTO; shiftable 540/540E with SyncShuttle transmission; lever-operated clutch Independent PTO Rear 540 rpm (at 2400 engine rpm); 540E (at 1700 engine rpm, SyncShuttle) 540 rpm Mid-PTO Availability Not Published Not Published Category, 3-Point Hitch Category I and II Category II, convertible to I Hitch Lift Capacity Not Published Not Published Hitch Lift Capacity (at 24”) 3,374 lb 3,192 lb Lift Control Type Position and depth control, top link draft sensing Position control with top link draft sensing ▶ Transmission & DrivetrainTransmission Type CollarShift standard; SyncShuttle optional; PowrReverser optional SyncShuttle No. of Speeds 9 forward, 3 reverse (CollarShift and SyncShuttle); 12 forward, 12 reverse (PowrReverser) 9F/3R Max Travel Speed (Forward) 14.98 mph (CollarShift and SyncShuttle, gear C-3); 14.89 mph (PowrReverser, gear C-4) Not Published Max Travel Speed (Reverse) 12.78 mph (CollarShift and SyncShuttle, gear C-R); 17.21 mph (PowrReverser, gear C-4 reverse) Not Published Clutch Dual dry clutch (CollarShift and SyncShuttle); multi-disk wet clutch (PowrReverser) Dry Differential Lock & Limited Slip Options Not Published Mechanical, pedal controlled ▶ Chassis, Steering & ControlsFrame Type Two-post ROPS; cab optional; two-wheel drive or MFWD Not Published Steering Hydrostatic power steering Hydrostatic power steering Brakes Wet disk, self-equalizing, self-adjusting Hydraulically Actuated Wet Disk Brakes, Self-Equalizing and Self-Adjusting Seat Suspension & Adjustability Not Published Not Published Front Axle Type Two-wheel drive or mechanical front wheel drive (MFWD) 2WD or MFWD Front Axle Rating 2,720 to 4,700 lb (2WD, by front tire, no loader); 2,760 to 4,620 lb (MFWD, by front tire, without loader) Not Published Drawbar Capacity 1,675 lb (maximum permissible static vertical load, drawbar fully extended) 1,675 lb (fully extended); 2,470 lb (short position) ▶ Dimensions & ManeuverabilityOverall Width 94.6 in (maximum) 57.3 in (rear axle between flanges) Wheelbase 80.7 in 80.7 in Ground Clearance 19 in (2WD front axle); 17 in (MFWD front axle); 14.3 in (drawbar) 2WD: 18.8 in; MFWD: 13.4 in Min. Turn Radius without Brakes 11.3 ft (2WD); 12.5 ft (MFWD engaged); 11.3 ft (MFWD disengaged) 11.5 ft (2WD); 15.3 ft (4WD); 12.8 ft (4WD, Carraro axle) Height to Top of ROPS 88.7 in (extended) 94.4 in Height to Top of ROPS (folded) 76.7 in 75.8 in Height to Top of Cab Model 97 in Not Published Overall Length 122.6 in (2WD); 125.9 in (MFWD) (less drawbar and front weights) (without 3-point hitch) 137.8 in ▶ WeightTractor Weight (Base) 4,370 lb (2WD); 4,730 lb (MFWD); add 1,000 lb with cab 2WD: 4,414 lb; MFWD: 5,401 lb Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options Front: 6.50-16, 7.50-16, 9.5L-15, 27/9.5L-15, 11L-15 (2WD); 9.5L-16, 8.3-24, 9.5-24, 10.5/80-18, 11.2-24 (MFWD). Rear: 13.6-28, 14.9-24, 14.9-28, 16.9-24, 16.9-28, 18.4-16.1 Not Published R1 Agricultural - Front 8.3-24 (MFWD) MFWD: 9.5-24 R1 Agricultural - Rear 13.6-28 13.6-28 R3 Turf - Front Not Published 9.5-16 R3 Turf - Rear Not Published 21.5L-16.1; 22.5LL-16.1 (Turf Special) R4 Industrial - Front Not Published 12.5/80-18 R4 Industrial - Rear Not Published 16.9-24 ▶ Loader & AttachmentsQuick Attach Loader System Not Published H240 (NSL or MSL); 520M Loader Model 521; 541; 541 self-leveling; 542; 542 self-leveling H240NSL Loader Lift Height 521: 122 in; 541: 126 in; 541 self-leveling: 130 in 131 in Loader Lift Capacity (Full Height) 521: 2,500 lb; 541: 2,500 lb; 541 self-leveling: 2,800 lb (full at pin) 3,671 lb Loader Breakout Force 521: 3,485 lbf; 541: 3,484 lbf; 541 self-leveling: 4,125 lbf (at pin) 4,504 lb ▶ WarrantyWarranty Length & Coverage Not Published Not Published
