▶ EngineEngine Manufacturer John Deere Mitsubishi Engine Model CD3029DLV50 K39 Engine Type 3-cylinder, naturally aspirated, direct injection, liquid-cooled diesel 4-cylinder turbocharged and intercooled diesel No. of Cylinders 3 4 Displacement 179 in³ 134.7 in³ Rated Engine Speed 2400 rpm 2500 rpm Engine Power (Gross) 53 hp 53.6 hp PTO Power 45 hp Gear: 42.1 hp; HST: 40.9 hp Engine Emissions Constraints Not Published Tier 4 Cooling System Type Liquid-cooled Liquid-cooled Air Cleaner Dry type with safety element Not Published Fuel System Direct injection, rotary injection pump, electric shutoff Common-rail, direct injection, electronic engine management Alternator 40 A Not Published ▶ HydraulicsPump Type Tandem gear pump Engine-driven gear-type pump Implement Flow 11.4 gpm 11.6 gpm Steering Flow 6.8 gpm 6.8 gpm Total Hydraulic Flow 18.2 gpm Not Published Overall Hydraulic Pump Flow 18.2 gpm Not Published Hydraulic System Type Open center Open center Rear Remote Hydraulic Flow 11.4 gpm 11.6 gpm No. of Standard Remote Valves Not Published 1 No. of Optional Remote Valves Not Published Up to 3 ▶ Fluid CapacityFuel Tank Capacity 18 gal (open station); 22 gal (cab) 14.5 gal Coolant Capacity 10 qt Not Published Crankcase Capacity 9 qt Not Published Transmission / Hydraulic System Capacity 10 gal (CollarShift and SyncShuttle, dry clutch); 11.5 gal (PowrReverser, wet clutch) Not Published Front Axle Fluid Capacity 5.3 qt (MFWD differential housing); 0.63 qt (each wheel hub) Not Published ▶ PTO & HitchPTO Type Fully independent 540 rpm PTO; shiftable 540/540E with SyncShuttle transmission; lever-operated clutch Independent, electro-hydraulically engaged PTO Rear 540 rpm (at 2400 engine rpm); 540E (at 1700 engine rpm, SyncShuttle) 540 rpm (1-3/8 in 6-spline) Mid-PTO Availability Not Published Optional, 2000 rpm Category, 3-Point Hitch Category I and II Category I Hitch Lift Capacity Not Published Not Published Hitch Lift Capacity (at 24”) 3,374 lb 3,086 lb Lift Control Type Position and depth control, top link draft sensing Position control; draft control optional ▶ Transmission & DrivetrainTransmission Type CollarShift standard; SyncShuttle optional; PowrReverser optional 12x12 power shuttle (4 gears, 3 ranges) or 3-range electronic Servo-HST No. of Speeds 9 forward, 3 reverse (CollarShift and SyncShuttle); 12 forward, 12 reverse (PowrReverser) Power shuttle: 12F / 12R; Servo-HST: 3-range infinite Max Travel Speed (Forward) 14.98 mph (CollarShift and SyncShuttle, gear C-3); 14.89 mph (PowrReverser, gear C-4) Not Published Max Travel Speed (Reverse) 12.78 mph (CollarShift and SyncShuttle, gear C-R); 17.21 mph (PowrReverser, gear C-4 reverse) Not Published Clutch Dual dry clutch (CollarShift and SyncShuttle); multi-disk wet clutch (PowrReverser) Wet multi-disc (power shuttle) Differential Lock & Limited Slip Options Not Published Mechanical engagement via heel pedal ▶ Chassis, Steering & ControlsFrame Type Two-post ROPS; cab optional; two-wheel drive or MFWD Drop-axle rear with bull gear final drives Steering Hydrostatic power steering Power steering, tilt steering wheel Brakes Wet disk, self-equalizing, self-adjusting Internal wet disc brakes, independent foot pedals Seat Suspension & Adjustability Not Published Suspended seat with armrests and seat belt (vinyl on ROPS, cloth on cab) Front Axle Type Two-wheel drive or mechanical front wheel drive (MFWD) Cast-steel 4WD front axle, center driveline, bevel-gear final drives Front Axle Rating 2,720 to 4,700 lb (2WD, by front tire, no loader); 2,760 to 4,620 lb (MFWD, by front tire, without loader) Not Published Drawbar Capacity 1,675 lb (maximum permissible static vertical load, drawbar fully extended) Not Published ▶ Dimensions & ManeuverabilityOverall Width 94.6 in (maximum) 65.4 in Wheelbase 80.7 in 77.2 in Ground Clearance 19 in (2WD front axle); 17 in (MFWD front axle); 14.3 in (drawbar) Not Published Min. Turn Radius without Brakes 11.3 ft (2WD); 12.5 ft (MFWD engaged); 11.3 ft (MFWD disengaged) Not Published Height to Top of ROPS 88.7 in (extended) Not Published Height to Top of ROPS (folded) 76.7 in Not Published Height to Top of Cab Model 97 in 92.9 in Overall Length 122.6 in (2WD); 125.9 in (MFWD) (less drawbar and front weights) (without 3-point hitch) 132.3 in ▶ WeightTractor Weight (Base) 4,370 lb (2WD); 4,730 lb (MFWD); add 1,000 lb with cab ROPS: 4,145 lb; Cab: 4,575 lb Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options Front: 6.50-16, 7.50-16, 9.5L-15, 27/9.5L-15, 11L-15 (2WD); 9.5L-16, 8.3-24, 9.5-24, 10.5/80-18, 11.2-24 (MFWD). Rear: 13.6-28, 14.9-24, 14.9-28, 16.9-24, 16.9-28, 18.4-16.1 Ag: 9.5x16 front, 13.6x28 rear (16.9x24 optional); turf: 27x10.50-15 front, 44x18.00-20 rear; industrial: 10-16.5 front, 17.5L-24 rear (also 250/80R16 front, 360/80R28 rear) R1 Agricultural - Front 8.3-24 (MFWD) 9.5-16 R1 Agricultural - Rear 13.6-28 13.6-28 (16.9-24 optional) R3 Turf - Front Not Published 27x10.50-15 R3 Turf - Rear Not Published 44x18.00-20 R4 Industrial - Front Not Published 10-16.5 or 250/80R16 R4 Industrial - Rear Not Published 17.5L-24 or 360/80R28 ▶ Loader & AttachmentsQuick Attach Loader System Not Published DL135: universal skid steer or exclusive compact quick-attach implement tool carrier Loader Model 521; 541; 541 self-leveling; 542; 542 self-leveling DL135 Loader Lift Height 521: 122 in; 541: 126 in; 541 self-leveling: 130 in DL135: 110.2 in (at pivot pin) Loader Lift Capacity (Full Height) 521: 2,500 lb; 541: 2,500 lb; 541 self-leveling: 2,800 lb (full at pin) DL135: 2,420 lb (at pivot pin, full height) Loader Breakout Force 521: 3,485 lbf; 541: 3,484 lbf; 541 self-leveling: 4,125 lbf (at pin) DL135: 2,860 lb (at pivot pin) ▶ WarrantyWarranty Length & Coverage Not Published 5-year powertrain warranty
