▶ EngineEngine Manufacturer John Deere Iseki Engine Model 3029D E4FH Engine Type 3-cylinder liquid-cooled diesel, naturally aspirated, direct injection 4-cylinder, turbocharged, liquid-cooled diesel No. of Cylinders 3 4 Displacement 179 in³ 148.6 in³ Rated Engine Speed 2400 rpm 2600 rpm Engine Power (Gross) 53 hp 53.6 hp PTO Power 45 hp 40 hp Engine Emissions Constraints Not Published Tier 4 Cooling System Type Liquid-cooled Liquid cooled Air Cleaner Dry type with safety element Dry Fuel System Direct injection, rotary injection pump with electric shutoff Common rail direct injection Alternator 40 A Not Published ▶ HydraulicsPump Type Tandem gear pump Two gear-type pumps for steering and 3-point/remotes Implement Flow 11.4 gpm 12.6 gpm Steering Flow 6.8 gpm 7 gpm Total Hydraulic Flow 18.2 gpm 19.6 gpm (12.6 + 7, computed) Overall Hydraulic Pump Flow 18.2 gpm 19.6 gpm (12.6 + 7, computed) Hydraulic System Type Open center Open center Rear Remote Hydraulic Flow 11.4 gpm Not Published No. of Standard Remote Valves Not Published Not Published No. of Optional Remote Valves Not Published Not Published ▶ Fluid CapacityFuel Tank Capacity 18 gal (open station); 23 gal (cab) 14.0 gal Coolant Capacity 10 qt 7.61 qt Crankcase Capacity 9 qt 7.82 qt Transmission / Hydraulic System Capacity 10 gal (CollarShift and SyncShuttle, dry clutch); 11.5 gal (PowrReverser, wet clutch) 10.04 gal Front Axle Fluid Capacity 5.2 qt (MFWD axle housing); 0.6 qt (each wheel hub); 5.7 qt (MFWD assembly) 9 qt ▶ PTO & HitchPTO Type Fully independent 540 rpm PTO; shiftable 540/540E with SyncShuttle transmission; lever operated clutch Independent with SoftStart electronic modulation PTO Rear 540 rpm (at 2400 engine rpm); 540E (at 1700 engine rpm, SyncShuttle) 540 rpm (1-3/8 in) Mid-PTO Availability Not Published Optional, 2,000 rpm Category, 3-Point Hitch Category I and II Category I and II Hitch Lift Capacity Not Published 3,483 lb Hitch Lift Capacity (at 24”) 3374 lb 3,086 lb Lift Control Type Position and depth control, top link draft sensing Not Published ▶ Transmission & DrivetrainTransmission Type CollarShift standard; SyncShuttle optional; PowrReverser optional 12x12 power shuttle No. of Speeds 9 forward, 3 reverse (CollarShift and SyncShuttle); 12 forward, 12 reverse (PowrReverser) 12 forward and 12 reverse Max Travel Speed (Forward) 14.98 mph (CollarShift and SyncShuttle, gear C-3); 14.89 mph (PowrReverser, gear C-4) Not Published Max Travel Speed (Reverse) 12.78 mph (CollarShift and SyncShuttle, gear C-R); 17.21 mph (PowrReverser, gear C-4 reverse) Not Published Clutch Dual dry clutch (CollarShift and SyncShuttle); multi-disk wet clutch (PowrReverser) Not Published Differential Lock & Limited Slip Options Not Published Not Published ▶ Chassis, Steering & ControlsFrame Type Two-post ROPS; cab optional; two-wheel drive or MFWD Not Published Steering Hydrostatic power steering Power steering Brakes Wet disk, self-equalizing, self-adjusting Wet disc Seat Suspension & Adjustability Not Published Open station: vinyl-clad seat; standard cab: spring-suspension seat with armrests; deluxe cab: air-ride seat with armrests Front Axle Type Two-wheel drive or mechanical front wheel drive (MFWD) Solid cast front axle Front Axle Rating 2720 to 4700 lb (2WD, by front tire, no loader); 2760 to 4620 lb (MFWD, by front tire, without loader) Not Published Drawbar Capacity 1675 lb Not Published ▶ Dimensions & ManeuverabilityOverall Length with 3-Point Hitch 122.6 in (2WD); 125.9 in (MFWD) (w/o 3P, less hitch, drawbar and front weights) (without 3-point hitch) 132.3 in Overall Width 65.4 in 70.1 in Wheelbase 80.7 in Not Published Ground Clearance 19.5 in (2WD front axle); 13.4 in (MFWD front axle); 15.8 in (2WD drawbar); 14.9 in (MFWD drawbar) 14.0 in Min. Turn Radius without Brakes 11.3 ft (2WD); 12.5 ft (MFWD engaged); 11.3 ft (MFWD disengaged) Not Published Height to Top of ROPS 87.8 in 102.4 in Height to Top of ROPS (folded) 74.6 in Not Published Height to Top of Cab Model 97 in 92.9 in ▶ WeightTractor Weight (Base) 4250 lb (2WD); 4650 lb (MFWD); add approximately 1000 lb with cab ROPS: 4,035 lb; Cab: 4,420 lb Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options Front: 6.50-16, 7.50-16, 9.5L-15, 27/9.5L-15, 11L-15 (2WD); 9.5L-16, 8.3-24, 9.5-24, 10.5/80-18, 11.2-24 (MFWD). Rear: 13.6-28, 14.9-24, 14.9-28, 16.9-24, 16.9-28, 16.9-30, 18.4-16.1 R1 Agricultural, R3 Turf, R4 Industrial R1 Agricultural - Front 6.5-16 (2WD); 8.3-24 (MFWD) 9.5-16 R1 Agricultural - Rear 13.6-28 13.6-28 standard; 16.9-24 optional R3 Turf - Front Not Published 27x10.50-15 R3 Turf - Rear Not Published 44x18.00-20 R4 Industrial - Front Not Published 10-16.5 R4 Industrial - Rear Not Published 14.9-24; 17.5L-24 ▶ Loader & AttachmentsQuick Attach Loader System Not Published FL2814: pin-type or skid steer Loader Model 521; 541; 541 self-leveling FL2814 Loader Lift Height 521: 122 in; 541: 126 in; 541 self-leveling: 130 in FL2814: 111 in Loader Lift Capacity (Full Height) 521: 2500 lb; 541: 2500 lb; 541 self-leveling: 2800 lb (full at pin) FL2814: 2,570 lb Loader Breakout Force 521: 3485 lbf; 541: 3484 lbf; 541 self-leveling: 4125 lbf (at pin) FL2814: 3,910 lb ▶ WarrantyWarranty Length & Coverage Not Published 5-year powertrain warranty
