▶ EngineEngine Manufacturer John Deere Shibaura Engine Model CD3029DLV50 N4LDI-TA Engine Type 3-cylinder, naturally aspirated, direct injection, liquid-cooled diesel 4-cylinder turbocharged intercooled diesel, liquid-cooled No. of Cylinders 3 4 Displacement 179 in³ 135.2 in³ Rated Engine Speed 2400 rpm 2600 rpm Engine Power (Gross) 53 hp 53.9 hp PTO Power 45 hp Mech: 41.3 hp; HST: 39.7 hp Engine Emissions Constraints Not Published Tier 4 Cooling System Type Liquid-cooled Liquid-cooled Air Cleaner Dry type with safety element Dry Fuel System Direct injection, rotary injection pump, electric shutoff Common rail direct injection Alternator 40 A Not Published ▶ HydraulicsPump Type Tandem gear pump Engine-driven gear-type pump Implement Flow 11.4 gpm Not Published Steering Flow 6.8 gpm Not Published Total Hydraulic Flow 18.2 gpm Not Published Overall Hydraulic Pump Flow 18.2 gpm 12.6 gpm Hydraulic System Type Open center Open center Rear Remote Hydraulic Flow 11.4 gpm 12.1 gpm No. of Standard Remote Valves Not Published Cab: 1 pair No. of Optional Remote Valves Not Published Up to 3 ▶ Fluid CapacityFuel Tank Capacity 18 gal (open station); 22 gal (cab) 14 gal Coolant Capacity 10 qt 7.08 qt Crankcase Capacity 9 qt 6.87 qt Transmission / Hydraulic System Capacity 10 gal (CollarShift and SyncShuttle, dry clutch); 11.5 gal (PowrReverser, wet clutch) Power Shuttle: 10.04 gal; HST: 9.25 gal Front Axle Fluid Capacity 5.3 qt (MFWD differential housing); 0.63 qt (each wheel hub) 9 qt ▶ PTO & HitchPTO Type Fully independent 540 rpm PTO; shiftable 540/540E with SyncShuttle transmission; lever-operated clutch Independent, with soft-start feature PTO Rear 540 rpm (at 2400 engine rpm); 540E (at 1700 engine rpm, SyncShuttle) 540 rpm (6-spline) Mid-PTO Availability Not Published Optional, 2,000 rpm Category, 3-Point Hitch Category I and II Category I with extendable ball ends Hitch Lift Capacity Not Published Not Published Hitch Lift Capacity (at 24”) 3,374 lb 3,086 lb Lift Control Type Position and depth control, top link draft sensing Draft control optional ▶ Transmission & DrivetrainTransmission Type CollarShift standard; SyncShuttle optional; PowrReverser optional 12 x 12 power shuttle or 3-range hydrostatic No. of Speeds 9 forward, 3 reverse (CollarShift and SyncShuttle); 12 forward, 12 reverse (PowrReverser) 12 x 12 Power Shuttle (3 ranges, 4 gears); HST: 3-range, infinite speeds in each range Max Travel Speed (Forward) 14.98 mph (CollarShift and SyncShuttle, gear C-3); 14.89 mph (PowrReverser, gear C-4) Not Published Max Travel Speed (Reverse) 12.78 mph (CollarShift and SyncShuttle, gear C-R); 17.21 mph (PowrReverser, gear C-4 reverse) Not Published Clutch Dual dry clutch (CollarShift and SyncShuttle); multi-disk wet clutch (PowrReverser) Single stage dry type Differential Lock & Limited Slip Options Not Published Mechanical engagement via right side heel pedal ▶ Chassis, Steering & ControlsFrame Type Two-post ROPS; cab optional; two-wheel drive or MFWD Not Published Steering Hydrostatic power steering Power steering Brakes Wet disk, self-equalizing, self-adjusting Internal wet disc brakes, independent foot pedals Seat Suspension & Adjustability Not Published Suspended seat with armrests and seat belts (vinyl on ROPS, cloth on cab), tilt steering Front Axle Type Two-wheel drive or mechanical front wheel drive (MFWD) Cast-steel 4WD front axle, center driveline, bevel-gear final drives Front Axle Rating 2,720 to 4,700 lb (2WD, by front tire, no loader); 2,760 to 4,620 lb (MFWD, by front tire, without loader) Not Published Drawbar Capacity 1,675 lb (maximum permissible static vertical load, drawbar fully extended) Not Published ▶ Dimensions & ManeuverabilityOverall Width 94.6 in (maximum) 65.4 in Wheelbase 80.7 in 77.9 in Ground Clearance 19 in (2WD front axle); 17 in (MFWD front axle); 14.3 in (drawbar) 14.8 in Min. Turn Radius without Brakes 11.3 ft (2WD); 12.5 ft (MFWD engaged); 11.3 ft (MFWD disengaged) Not Published Height to Top of ROPS 88.7 in (extended) 102.4 in Height to Top of ROPS (folded) 76.7 in Not Published Height to Top of Cab Model 97 in 92.9 in Overall Length 122.6 in (2WD); 125.9 in (MFWD) (less drawbar and front weights) (without 3-point hitch) 132.3 in ▶ WeightTractor Weight (Base) 4,370 lb (2WD); 4,730 lb (MFWD); add 1,000 lb with cab 12x12 Power Shuttle: 3,968 lb (ROPS base weight) Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options Front: 6.50-16, 7.50-16, 9.5L-15, 27/9.5L-15, 11L-15 (2WD); 9.5L-16, 8.3-24, 9.5-24, 10.5/80-18, 11.2-24 (MFWD). Rear: 13.6-28, 14.9-24, 14.9-28, 16.9-24, 16.9-28, 18.4-16.1 AG, Turf, Industrial, Snow R1 Agricultural - Front 8.3-24 (MFWD) 9.5x16 R1 Agricultural - Rear 13.6-28 13.6x28 R3 Turf - Front Not Published 27x10.50-15 R3 Turf - Rear Not Published 44x18.00-20 R4 Industrial - Front Not Published 10-16.5 R4 Industrial - Rear Not Published 17.5L-24 ▶ Loader & AttachmentsQuick Attach Loader System Not Published DL135: Skid steer quick attach Loader Model 521; 541; 541 self-leveling; 542; 542 self-leveling DL135 Loader Lift Height 521: 122 in; 541: 126 in; 541 self-leveling: 130 in DL135: 111 in (at pivot pin) Loader Lift Capacity (Full Height) 521: 2,500 lb; 541: 2,500 lb; 541 self-leveling: 2,800 lb (full at pin) DL135: 2,610 lb (at pivot pin, full height) Loader Breakout Force 521: 3,485 lbf; 541: 3,484 lbf; 541 self-leveling: 4,125 lbf (at pin) DL135: 4,000 lb (at pivot pin) ▶ WarrantyWarranty Length & Coverage Not Published Five-year powertrain warranty
