▶ EngineEngine Manufacturer John Deere Yanmar Engine Model 3029T 4TNV86CHT-MJT Engine Type 3-cylinder liquid-cooled diesel, turbocharged, direct injection Turbocharged 4-cylinder Diesel No. of Cylinders 3 4 Displacement 179 in³ 127.6 in³ Rated Engine Speed 2400 rpm 2600 rpm Engine Power (Gross) 64 hp 65.9 hp PTO Power 55 hp 51.9 hp Engine Emissions Constraints Not Published Tier 4 Cooling System Type Liquid-cooled Liquid Air Cleaner Dry type with safety element Dual element Fuel System Direct injection, rotary injection pump with electric shutoff High-pressure common rail direct injection Alternator 40 A 75 A, 12 V ▶ HydraulicsPump Type Tandem gear pump Dual Independent Implement Flow 11.4 gpm 10.2 gpm Steering Flow 6.8 gpm 5.7 gpm Total Hydraulic Flow 18.2 gpm 15.9 gpm Overall Hydraulic Pump Flow 18.2 gpm 15.9 gpm Hydraulic System Type Open center Open center Rear Remote Hydraulic Flow 11.4 gpm Not Published No. of Standard Remote Valves Not Published 2 No. of Optional Remote Valves Not Published Not Published ▶ Fluid CapacityFuel Tank Capacity 18 gal (open station); 23 gal (cab) Open station: 15.0 gal; Cab: 14.7 gal (if equipped) Coolant Capacity 10 qt Open station: 6.8 qt; Cab: 8.0 qt (if equipped) Crankcase Capacity 9 qt 5.6 qt (with filter) Transmission / Hydraulic System Capacity 10 gal (CollarShift and SyncShuttle, dry clutch); 11.5 gal (PowrReverser, wet clutch) 12.5 gal Front Axle Fluid Capacity 5.2 qt (MFWD axle housing); 0.6 qt (each wheel hub); 5.7 qt (MFWD assembly) 5.3 qt ▶ PTO & HitchPTO Type Fully independent 540 rpm PTO; shiftable 540/540E with SyncShuttle transmission; lever operated clutch Independent (electrohydraulic) PTO Rear 540 rpm (at 2400 engine rpm); 540E (at 1700 engine rpm, SyncShuttle) 540 rpm Mid-PTO Availability Not Published No mid-PTO offered Category, 3-Point Hitch Category I and II Category I/II Hitch Lift Capacity Not Published 3,130 lb Hitch Lift Capacity (at 24”) 3374 lb 2,500 lb Lift Control Type Position and depth control, top link draft sensing Position control ▶ Transmission & DrivetrainTransmission Type CollarShift standard; SyncShuttle optional; PowrReverser optional eHydro (3-range hydrostatic); no PowrReverser gear option offered No. of Speeds 9 forward, 3 reverse (CollarShift and SyncShuttle); 12 forward, 12 reverse (PowrReverser) eHydro: Infinitely-variable, 3 range Max Travel Speed (Forward) 15.62 mph (CollarShift and SyncShuttle, gear C-3); 15.52 mph (PowrReverser, gear C-4) 18.6 mph Max Travel Speed (Reverse) 13.33 mph (CollarShift and SyncShuttle, gear C-R); 17.95 mph (PowrReverser, gear C-4 reverse) 18.6 mph Clutch Dual dry clutch (CollarShift and SyncShuttle); multi-disk wet clutch (PowrReverser) Wet; wet clutch disk diameter 5.08 in Differential Lock & Limited Slip Options Not Published Differential lock: Yes ▶ Chassis, Steering & ControlsFrame Type Two-post ROPS; cab optional; two-wheel drive or MFWD ROPS - Foldable Steering Hydrostatic power steering Power steering (hydrostatic) Brakes Wet disk, self-equalizing, self-adjusting Wet disc Seat Suspension & Adjustability Not Published Not Published Front Axle Type Two-wheel drive or mechanical front wheel drive (MFWD) Mechanical front wheel drive (MFWD) - Standard Front Axle Rating 2720 to 4700 lb (2WD, by front tire, no loader); 2760 to 4620 lb (MFWD, by front tire, without loader) (Continuous) 3307 lb Drawbar Capacity 1675 lb Max vertical load 1103 lb ▶ Dimensions & ManeuverabilityOverall Length with 3-Point Hitch 123.6 in (2WD); 128.1 in (MFWD) (w/o 3P, less hitch, drawbar and front weights) (without 3-point hitch) 134.7 in Overall Width 66.7 in 71.3 in Wheelbase 80.7 in 73.0 in Ground Clearance 18.1 in (2WD front axle); 14.8 in (MFWD front axle); 15.8 in (2WD drawbar); 16.3 in (MFWD drawbar) Front axle: 15.2 in; Drawbar support: 14.5 in Min. Turn Radius without Brakes 11.3 ft (2WD); 12.5 ft (MFWD engaged); 11.3 ft (MFWD disengaged) 17.1 ft (5.2 m) Height to Top of ROPS 88.7 in 91.1 in Height to Top of ROPS (folded) 75.5 in 65.9 in Height to Top of Cab Model 97.9 in Not Published ▶ WeightTractor Weight (Base) 4350 lb (2WD); 4750 lb (MFWD); add approximately 1000 lb with cab 4,255 lb Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options Front: 6.50-16, 7.50-16, 9.5L-15, 27/9.5L-15, 11L-15 (2WD); 9.5L-16, 8.3-24, 9.5-24, 10.5/80-18, 11.2-24 (MFWD). Rear: 13.6-28, 14.9-24, 14.9-28, 16.9-24, 16.9-28, 16.9-30, 18.4-16.1 R4 Industrial R1 Agricultural - Front 7.50-16 (2WD); 9.5-24 (MFWD) Not Published R1 Agricultural - Rear 14.9-28 Not Published R3 Turf - Front Not Published Not Published R3 Turf - Rear Not Published Not Published R4 Industrial - Front Not Published 31.5x13-16.5 (10PR) R4 Industrial - Rear Not Published 16.9-24 ▶ Loader & AttachmentsQuick Attach Loader System Not Published Rigid mounted with parking kit available; Parking stand kit BW16127 (parkable) Loader Model 521; 541; 541 self-leveling 440R (Quik-Park) Loader Lift Height 521: 122 in; 541: 126 in; 541 self-leveling: 130 in 110 in Loader Lift Capacity (Full Height) 521: 2500 lb; 541: 2500 lb; 541 self-leveling: 2800 lb (full at pin) 2,539 lb (at pivot, NSL) Loader Breakout Force 521: 3485 lbf; 541: 3484 lbf; 541 self-leveling: 4125 lbf (at pin) At pivot: 3,853 lbf; @ 19.7 in ahead of pivot: 2,902 lbf ▶ WarrantyWarranty Length & Coverage Not Published 6-year/2,000-hour powertrain; 2-year/2,000-hour basic (full machine)
