▶ EngineEngine Manufacturer John Deere John Deere Engine Model 3029T PowerTech 4024T Engine Type 3-cylinder liquid-cooled diesel, turbocharged, direct injection 4-cylinder turbocharged liquid-cooled diesel, direct injection No. of Cylinders 3 4 Displacement 179 in³ 149 in³ Rated Engine Speed 2400 rpm 2400 rpm Engine Power (Gross) 64 hp 60 hp PTO Power 55 hp 52 hp Engine Emissions Constraints Not Published Not Published Cooling System Type Liquid-cooled Liquid-cooled Air Cleaner Dry type with safety element Dry type with safety element Fuel System Direct injection, rotary injection pump with electric shutoff Direct injection, mechanical fuel pump Alternator 40 A 70 A ▶ HydraulicsPump Type Tandem gear pump Dual tandem gear pump Implement Flow 11.4 gpm 12 gpm Steering Flow 6.8 gpm 5.1 gpm Total Hydraulic Flow 18.2 gpm 17.1 gpm Overall Hydraulic Pump Flow 18.2 gpm 17.1 gpm Hydraulic System Type Open center Open center Rear Remote Hydraulic Flow 11.4 gpm Not Published No. of Standard Remote Valves Not Published Not Published No. of Optional Remote Valves Not Published Not Published ▶ Fluid CapacityFuel Tank Capacity 18 gal (open station); 23 gal (cab) 14.5 gal (open station); 13.8 gal (cab) Coolant Capacity 10 qt 1.6 gal (open station); 2.2 gal (cab) Crankcase Capacity 9 qt 7.9 qt Transmission / Hydraulic System Capacity 10 gal (CollarShift and SyncShuttle, dry clutch); 11.5 gal (PowrReverser, wet clutch) 10.3 gal (PowrReverser); 9.6 gal (eHydro) Front Axle Fluid Capacity 5.2 qt (MFWD axle housing); 0.6 qt (each wheel hub); 5.7 qt (MFWD assembly) 1.3 gal ▶ PTO & HitchPTO Type Fully independent 540 rpm PTO; shiftable 540/540E with SyncShuttle transmission; lever operated clutch Independent, wet disk clutch and brake PTO Rear 540 rpm (at 2400 engine rpm); 540E (at 1700 engine rpm, SyncShuttle) 540 rpm Mid-PTO Availability Not Published Optional, 2100 rpm Category, 3-Point Hitch Category I and II Category 1 Hitch Lift Capacity Not Published 3130 lb Hitch Lift Capacity (at 24”) 3374 lb 2500 lb Lift Control Type Position and depth control, top link draft sensing Position control ▶ Transmission & DrivetrainTransmission Type CollarShift standard; SyncShuttle optional; PowrReverser optional PowrReverser 12F/12R standard; eHydro hydrostatic optional (4WD) No. of Speeds 9 forward, 3 reverse (CollarShift and SyncShuttle); 12 forward, 12 reverse (PowrReverser) 12 forward, 12 reverse (PowrReverser); infinite forward and reverse, 3 ranges (eHydro) Max Travel Speed (Forward) 15.62 mph (CollarShift and SyncShuttle, gear C-3); 15.52 mph (PowrReverser, gear C-4) 17.3 mph (PowrReverser); 16.9 mph (eHydro) Max Travel Speed (Reverse) 13.33 mph (CollarShift and SyncShuttle, gear C-R); 17.95 mph (PowrReverser, gear C-4 reverse) 17.3 mph (PowrReverser); 16.9 mph (eHydro) Clutch Dual dry clutch (CollarShift and SyncShuttle); multi-disk wet clutch (PowrReverser) Multiple stage wet disk, 5.1 in (PowrReverser) Differential Lock & Limited Slip Options Not Published Mechanical rear differential lock ▶ Chassis, Steering & ControlsFrame Type Two-post ROPS; cab optional; two-wheel drive or MFWD Folding ROPS; ComfortGard cab optional; four-wheel drive standard Steering Hydrostatic power steering Power steering Brakes Wet disk, self-equalizing, self-adjusting Wet disk Seat Suspension & Adjustability Not Published Air ride seat optional Front Axle Type Two-wheel drive or mechanical front wheel drive (MFWD) Mechanical front wheel drive (MFWD), standard, all ranges Front Axle Rating 2720 to 4700 lb (2WD, by front tire, no loader); 2760 to 4620 lb (MFWD, by front tire, without loader) 3528 lb Drawbar Capacity 1675 lb 1103 lb ▶ Dimensions & ManeuverabilityOverall Length with 3-Point Hitch 123.6 in (2WD); 128.1 in (MFWD) (w/o 3P, less hitch, drawbar and front weights) (without 3-point hitch) 128.2 in Overall Width 66.7 in 65.6 in (minimum, R1 tires); 89.1 in (maximum, R1 tires) Wheelbase 80.7 in 71.5 in Ground Clearance 18.1 in (2WD front axle); 14.8 in (MFWD front axle); 15.8 in (2WD drawbar); 16.3 in (MFWD drawbar) Not Published Min. Turn Radius without Brakes 11.3 ft (2WD); 12.5 ft (MFWD engaged); 11.3 ft (MFWD disengaged) Not Published Height to Top of ROPS 88.7 in 97.2 in Height to Top of ROPS (folded) 75.5 in Not Published Height to Top of Cab Model 97.9 in 92.4 in ▶ WeightTractor Weight (Base) 4350 lb (2WD); 4750 lb (MFWD); add approximately 1000 lb with cab 3700 lb (open station); 4345 lb (cab) Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options Front: 6.50-16, 7.50-16, 9.5L-15, 27/9.5L-15, 11L-15 (2WD); 9.5L-16, 8.3-24, 9.5-24, 10.5/80-18, 11.2-24 (MFWD). Rear: 13.6-28, 14.9-24, 14.9-28, 16.9-24, 16.9-28, 16.9-30, 18.4-16.1 R1 8.00-16 front and 13.6-28 rear; R3 27x10.5-15 front and 44x18.00-20 rear; R4 10.00-16.5 front and 17.5L-24 rear; golf 27x12LL-15 front and 22.5LL-16.1 rear R1 Agricultural - Front 7.50-16 (2WD); 9.5-24 (MFWD) 8.00-16 R1 Agricultural - Rear 14.9-28 13.6-28 R3 Turf - Front Not Published 27x10.5-15 R3 Turf - Rear Not Published 44x18.00-20 R4 Industrial - Front Not Published 10.00-16.5 R4 Industrial - Rear Not Published 17.5L-24 ▶ Loader & AttachmentsQuick Attach Loader System Not Published Not Published Loader Model 521; 541; 541 self-leveling 400X; 400CX Loader Lift Height 521: 122 in; 541: 126 in; 541 self-leveling: 130 in 400X: 112.8 in; 400CX: 112.8 in; H180 NSL: 109 in; H180 MSL: 109 in; 440R NSL: 109 in; 440R MSL: 109 in Loader Lift Capacity (Full Height) 521: 2500 lb; 541: 2500 lb; 541 self-leveling: 2800 lb (full at pin) 400X: 2346 lb; 400CX: 2194 lb; H180 NSL: 2486 lb; H180 MSL: 2477 lb; 440R NSL: 2486 lb; 440R MSL: 2477 lb (to maximum height at pivot pin) Loader Breakout Force 521: 3485 lbf; 541: 3484 lbf; 541 self-leveling: 4125 lbf (at pin) 400X: 3453 lbf; 400CX: 3435 lbf; H180 NSL: 3934 lbf; H180 MSL: 3917 lbf; 440R NSL: 3934 lbf; 440R MSL: 3917 lbf (at pivot point) ▶ WarrantyWarranty Length & Coverage Not Published 3-year / 2,000-hour limited warranty (as sold new)
