▶ EngineEngine Manufacturer John Deere Simpson Engine Model 3029T SJV326 Engine Type 3-cylinder liquid-cooled diesel, turbocharged, direct injection 3-cylinder, turbocharged, intercooled, liquid-cooled diesel No. of Cylinders 3 3 Displacement 179 in³ 157.9 in³ Rated Engine Speed 2400 rpm 2000 rpm Engine Power (Gross) 64 hp 65 hp PTO Power 55 hp 55 hp Engine Emissions Constraints Not Published Tier 4 Cooling System Type Liquid-cooled Liquid cooled Air Cleaner Dry type with safety element Not Published Fuel System Direct injection, rotary injection pump with electric shutoff Electronically controlled high-pressure common rail Alternator 40 A Not Published ▶ HydraulicsPump Type Tandem gear pump Mark 1A scotch yoke piston pump Implement Flow 11.4 gpm Not Published Steering Flow 6.8 gpm Not Published Total Hydraulic Flow 18.2 gpm 15.7 gpm Overall Hydraulic Pump Flow 18.2 gpm 15.7 gpm Hydraulic System Type Open center Open center Rear Remote Hydraulic Flow 11.4 gpm 10.6 gpm No. of Standard Remote Valves Not Published 2 No. of Optional Remote Valves Not Published Not Published ▶ Fluid CapacityFuel Tank Capacity 18 gal (open station); 23 gal (cab) 14.5 gal Coolant Capacity 10 qt 4 gal Crankcase Capacity 9 qt 2.5 gal Transmission / Hydraulic System Capacity 10 gal (CollarShift and SyncShuttle, dry clutch); 11.5 gal (PowrReverser, wet clutch) 10.5 gal Front Axle Fluid Capacity 5.2 qt (MFWD axle housing); 0.6 qt (each wheel hub); 5.7 qt (MFWD assembly) 4WD: 1.5 gal differential, plus 0.23 gal per wheel end ▶ PTO & HitchPTO Type Fully independent 540 rpm PTO; shiftable 540/540E with SyncShuttle transmission; lever operated clutch Independent PTO Rear 540 rpm (at 2400 engine rpm); 540E (at 1700 engine rpm, SyncShuttle) 540 rpm, 6-spline Mid-PTO Availability Not Published Not Published Category, 3-Point Hitch Category I and II Category I and II Hitch Lift Capacity Not Published 4,519 lb Hitch Lift Capacity (at 24”) 3374 lb 2,755 lb Lift Control Type Position and depth control, top link draft sensing Draft, position and response control ▶ Transmission & DrivetrainTransmission Type CollarShift standard; SyncShuttle optional; PowrReverser optional 8F x 8R synchro shuttle No. of Speeds 9 forward, 3 reverse (CollarShift and SyncShuttle); 12 forward, 12 reverse (PowrReverser) 8 forward and 8 reverse Max Travel Speed (Forward) 15.62 mph (CollarShift and SyncShuttle, gear C-3); 15.52 mph (PowrReverser, gear C-4) Not Published Max Travel Speed (Reverse) 13.33 mph (CollarShift and SyncShuttle, gear C-R); 17.95 mph (PowrReverser, gear C-4 reverse) Not Published Clutch Dual dry clutch (CollarShift and SyncShuttle); multi-disk wet clutch (PowrReverser) Split torque clutch Differential Lock & Limited Slip Options Not Published Mechanical engagement via right-side heel pedal ▶ Chassis, Steering & ControlsFrame Type Two-post ROPS; cab optional; two-wheel drive or MFWD Not Published Steering Hydrostatic power steering Hydrostatic power steering with separate reservoir Brakes Wet disk, self-equalizing, self-adjusting Oil-immersed wet disc Seat Suspension & Adjustability Not Published ReverseRise adjustable seat with fixed steering column Front Axle Type Two-wheel drive or mechanical front wheel drive (MFWD) 2WD: straight, telescopically adjustable; 4WD: heavy-duty planetary reduction Front Axle Rating 2720 to 4700 lb (2WD, by front tire, no loader); 2760 to 4620 lb (MFWD, by front tire, without loader) Not Published Drawbar Capacity 1675 lb Not Published ▶ Dimensions & ManeuverabilityOverall Length with 3-Point Hitch 123.6 in (2WD); 128.1 in (MFWD) (w/o 3P, less hitch, drawbar and front weights) (without 3-point hitch) 2WD: 138 in; 4WD: 139 in Overall Width 66.7 in 69.9 in Wheelbase 80.7 in 2WD: 80.7 in; 4WD: 81.5 in Ground Clearance 18.1 in (2WD front axle); 14.8 in (MFWD front axle); 15.8 in (2WD drawbar); 16.3 in (MFWD drawbar) Not Published Min. Turn Radius without Brakes 11.3 ft (2WD); 12.5 ft (MFWD engaged); 11.3 ft (MFWD disengaged) Not Published Height to Top of ROPS 88.7 in 93.9 in Height to Top of ROPS (folded) 75.5 in Not Published Height to Top of Cab Model 97.9 in Not Published ▶ WeightTractor Weight (Base) 4350 lb (2WD); 4750 lb (MFWD); add approximately 1000 lb with cab 2WD: 5,115 lb; 4WD: 5,710 lb Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options Front: 6.50-16, 7.50-16, 9.5L-15, 27/9.5L-15, 11L-15 (2WD); 9.5L-16, 8.3-24, 9.5-24, 10.5/80-18, 11.2-24 (MFWD). Rear: 13.6-28, 14.9-24, 14.9-28, 16.9-24, 16.9-28, 16.9-30, 18.4-16.1 2WD standard (ag): 7.5x16 front, 14.9x28 rear; 4WD standard (ag): 9.5x24 front, 14.9x28 rear; industrial: 11L15 front (2WD) or 10.8/80-18 front (4WD) with 14.9x24 rear, or 12.5/80-18 front with 16.9x24 rear (4WD) R1 Agricultural - Front 7.50-16 (2WD); 9.5-24 (MFWD) 2WD: 7.5x16; 4WD: 9.5x24 R1 Agricultural - Rear 14.9-28 14.9x28 (2WD and 4WD) R3 Turf - Front Not Published Not Published R3 Turf - Rear Not Published Not Published R4 Industrial - Front Not Published 2WD: 11L15; 4WD: 10.8/80-18 or 12.5/80-18 R4 Industrial - Rear Not Published 14.9x24 or 16.9x24 (4WD) ▶ Loader & AttachmentsQuick Attach Loader System Not Published Skid steer style coupling Loader Model 521; 541; 541 self-leveling FLx2815 (2WD); 911X (4WD) Loader Lift Height 521: 122 in; 541: 126 in; 541 self-leveling: 130 in FLx2815: 111 in; 911X: 114 in Loader Lift Capacity (Full Height) 521: 2500 lb; 541: 2500 lb; 541 self-leveling: 2800 lb (full at pin) FLx2815: 2,810 lb; 911X: 2,470 lb Loader Breakout Force 521: 3485 lbf; 541: 3484 lbf; 541 self-leveling: 4125 lbf (at pin) FLx2815: 4,240 lb; 911X: 2,755 lb ▶ WarrantyWarranty Length & Coverage Not Published 5-year powertrain warranty
