▶ EngineEngine Manufacturer John Deere John Deere Engine Model 4045T John Deere PowerTech 4.5L diesel Engine Type 4-cylinder turbocharged diesel 4-cylinder, turbocharged and intercooled diesel, 4-valve high pressure common rail No. of Cylinders 4 4 Displacement 278 in³ 276 in³ Rated Engine Speed 2400 rpm 2200 rpm Engine Power (Gross) 89 hp 90 hp PTO Power 75 hp 75 hp @ 100 rpm Engine Emissions Constraints Not Published Tier 4 Cooling System Type Liquid-cooled Liquid-cooled Air Cleaner Not Published Dry type with safety element Fuel System Not Published High pressure common rail, 4 valve, electronic fuel control Alternator 40 A 200 A ▶ HydraulicsPump Type Tandem gear pump Tandem gear pump (open center); variable axial-piston implement pump (PFC, optional) Implement Flow 15.9 gpm 19.3 gpm (open center); 30.9 gpm (PFC) Steering Flow 6.6 gpm 6.3 gpm (open center) Total Hydraulic Flow 22.5 gpm (15.9 + 6.6, computed) 25.6 gpm (open center) Overall Hydraulic Pump Flow Not Published 25.6 gpm (open center); 30.9 gpm (PFC) Hydraulic System Type Open center Open center (standard); closed center PFC (optional) Rear Remote Hydraulic Flow 15.9 gpm Not Published No. of Standard Remote Valves 2 to 3 rear 2 rear and 2 mid (stackable) No. of Optional Remote Valves Not Published Rear: 3 (mechanical or proportional EH, optional; 4th rear by conversion kit); Mid: 3 Deluxe (mechanical or EH, optional) ▶ Fluid CapacityFuel Tank Capacity 22 gal (straddle mount, early model); 25 gal (straddle mount, late model); 27 gal (IOOS or cab, small filler neck); 29.5 gal (IOOS or cab, large filler neck) 38 gal Coolant Capacity 11.4 qt 4.25 gal Crankcase Capacity 9 qt 3.1 gal Transmission / Hydraulic System Capacity 10 gal (CollarShift and SyncShuttle, dry clutch); 11.5 gal (PowrReverser, wet clutch) 11.75 gal (open center); 12.5 gal (closed center PFC) Front Axle Fluid Capacity 5.2 qt (MFWD differential housing); 0.74 qt (each wheel hub); 6.6 qt (assembly) 1.3 gal (MFWD differential housing); 0.2 gal (each wheel hub) ▶ PTO & HitchPTO Type Fully independent 540 rpm PTO; shiftable 540/540E with SyncShuttle transmission; lever-operated clutch Independent, electro-hydraulic engagement, wet PTO clutch, reversible 540/1000 shaft PTO Rear 540 rpm (at 2400 engine rpm); 540E (at 1700 engine rpm, SyncShuttle) 540/540E/1000 rpm Mid-PTO Availability Not Published Not Published Category, 3-Point Hitch Category I and II Category II (telescoping draft links with Category II balls) Hitch Lift Capacity Not Published 7,158 lb; 8,157 lb throughout lift range at hitch ball; 11,122 lb / 12,515 lb maximum Hitch Lift Capacity (at 24”) 3,374 lb 6,975 lb; 7,868 lb throughout lift range Lift Control Type Top link sensing Electro-hydraulic hitch with fender controls, lower-link draft sensing ▶ Transmission & DrivetrainTransmission Type CollarShift 9F/3R standard; SyncShuttle 9F/3R optional (also with shiftable 540/540E PTO); PowrReverser 12F/12R optional CommandQuad 16F/16R manual with electronic range and gear shifting, AutoClutch and wet traction clutch (standard); CommandQuad 16F/16R Auto, CommandQuad 16F/16R manual with creeper, or Command8 32F/16R (optional) No. of Speeds 9 forward, 3 reverse (CollarShift and SyncShuttle); 12 forward, 12 reverse (PowrReverser) 16F/16R (CommandQuad, standard); 32F/16R (Command8, optional) Max Travel Speed (Forward) 16.8 mph (CollarShift and SyncShuttle, gear C-3); 16.8 mph (PowrReverser, gear C-4) 22.0 mph (D4, 16/16 transmission, 480/70R28 rear tires) Max Travel Speed (Reverse) 14.4 mph (CollarShift and SyncShuttle, gear R-3); 19.5 mph (PowrReverser, gear C-4 reverse) 18.6 mph Clutch Not Published Wet traction clutch with AutoClutch Differential Lock & Limited Slip Options Not Published Electro-hydraulic differential lock ▶ Chassis, Steering & ControlsFrame Type Straddle-mount frame; isolated open operator station or cab; 2WD or MFWD Cab standard with air conditioning; mechanical front-wheel drive (MFWD) Steering Hydrostatic power steering Hydrostatic power steering Brakes Hydraulic wet, self-adjusting, self-equalizing Hydraulic wet disc, self-equalizing and self-adjusting, lockable turning brakes; electronic park brake Seat Suspension & Adjustability Not Published Not Published Front Axle Type Two-wheel drive or mechanical front wheel drive (MFWD) MFWD, electro-hydraulic engagement, planetary final drives Front Axle Rating 2,720 to 4,700 lb (2WD, by front tire, no loader); 2,760 to 4,620 lb (MFWD, by front tire, without loader) 7,937 lb (MFWD closed center); 7,055 lb (MFWD open center) Drawbar Capacity 1,675 lb (drawbar fully extended); 2,470 lb (short position) (maximum permissible static vertical load) 2,756 lb (standard drawbar, 9.8 in extended); 2,205 lb (standard, 13.8 in extended); 3,197 lb (heavy duty, 9.8 in extended); 2,646 lb (heavy duty, 13.8 in extended) ▶ Dimensions & ManeuverabilityOverall Width 74 in (straddle mount and IOOS, outside edge of tires); 77 in (cab, 60.4 in tread setting) 87 in (with fender extension); 74 in (without fender extension); 66.9 in (narrow cab, without fender extension) Wheelbase 86 in (straddle mount and IOOS); 85 in (cab 2WD); 86 in (cab MFWD) 88.6 in Ground Clearance 19 in (2WD); 18 in (MFWD) crop clearance, straddle mount and IOOS; 19 in (2WD cab); 15.75 in (MFWD cab) Not Published Min. Turn Radius without Brakes 154 in (2WD); 172 in (MFWD engaged); 155 in (MFWD disengaged) Not Published Height to Top of ROPS 97 in (straddle mount); 105 in (isolated open operator station) Not Published Height to Top of ROPS (folded) 78.5 in (straddle mount); 86 in (isolated open operator station) Not Published Height to Top of Cab Model 100 in 106.1 in Overall Length 151.5 in (straddle mount and IOOS, 2WD and MFWD); 145.5 in (cab 2WD); 148 in (cab MFWD) (including draft links) 147.8 in ▶ WeightTractor Weight (Base) 4,809 lb (2WD straddle mount); 5,849 lb (MFWD straddle mount); 5,124 lb (2WD IOOS); 6,164 lb (MFWD IOOS); 6,224 lb (2WD cab); 7,264 lb (MFWD cab) (shipping weight) 9,811 lb (base machine weight, with all fluids) Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options Front: 6.50-16, 7.50-16, 9.5L-15, 27/9.5-15, 11L-15 (2WD); 9.5-16, 8.3-24, 9.5-24, 12.5/80-18, 11.2-24 (MFWD). Rear: 14.9-28, 16.9-24, 16.9-28, 16.9-30 320/85R24 (12.4R24) R1-W radial front and 460/85R30 (18.4R30) R1-W radial rear standard; optional 11.2R28/13.6R38, 380/70R20/480/70R28, 13.6R24/16.9R34, 380/70R24/480/70R34 R1; R3 44x18-20/23.1-26; R4 12.5/80-18/19.5L-24 R1 Agricultural - Front 11.2-24 (MFWD) 320/85R24 (12.4R24) R1-W radial R1 Agricultural - Rear 16.9-30 460/85R30 (18.4R30) R1-W radial R3 Turf - Front Not Published 44x18-20 R3 Turf - Rear Not Published 23.1-26 R4 Industrial - Front Not Published 12.5/80-18 R4 Industrial - Rear Not Published 19.5L-24 ▶ Loader & AttachmentsQuick Attach Loader System Not Published Global carrier in base; John Deere 500-style carrier optional (540R) Loader Model 520M (NSL and MSL) 540R (non self-leveling and mechanical self-leveling) Loader Lift Height 520M NSL: 127 in; 520M MSL: 127 in 540R: 141.5 in Loader Lift Capacity (Full Height) 520M NSL: 3,671 lb; 520M MSL: 2,687 lb (to maximum height at pivot point) 540R NSL: 4,246 lb (measured at pivot) Loader Breakout Force 520M NSL: 4,504 lbf; 520M MSL: 4,542 lbf (at pivot point) 540R NSL: 4,945 lbf (measured at pivot) ▶ WarrantyWarranty Length & Coverage Not Published Not Published
