▶ EnginePTO Power n/a 18.2 hp Alternator n/a 40 A Air Cleaner n/a Dual element with mechanical restriction indicator Engine Type n/a Diesel Fuel System n/a Indirect injection Displacement n/a 77.3 in³ No. of Cylinders n/a 3 Rated Engine Speed n/a 3200 rpm Cooling System Type n/a Water pump Engine Manufacturer n/a Yanmar Engine Power (Gross) n/a 23.9 hp @ 200 rpm Engine Emissions Constraints n/a Tier 4 ▶ WeightTractor Weight (Base) n/a Open station: 1556 lb Weight with Cab and Loader n/a approx. 1,996 lb shipping weight with cab Weight with ROPS and Loader n/a approx. 1,444 lb shipping weight open station (no loader); operating weight with loader approx. 1,556 lb shipping ▶ WarrantyWarranty Length & Coverage n/a 6-year / 2,000-hour powertrain warranty (standard); PowerGard extended warranty available ▶ HydraulicsPump Type n/a Single gear Steering Flow n/a 3.5 gpm Implement Flow n/a 3.5 gpm Total Hydraulic Flow n/a 6.3 gpm 23.8 lpm Hydraulic System Type n/a Open center System Operating Pressure n/a 2000 psi Rear Remote Hydraulic Flow n/a 3.5 gpm per pump (implement circuit); total system output 6.3 gpm Overall Hydraulic Pump Flow n/a 3.5 gpm 13.2 lpm No. of Optional Remote Valves n/a Three ▶ PTO & HitchPTO Rear n/a 540 rpm PTO Type n/a Independent Lift Control Type n/a position control Hitch Lift Capacity n/a 758 lb Mid-PTO Availability n/a 2100 rpm Category, 3-Point Hitch n/a Limited Category 1 Hitch Lift Capacity (at 24”) n/a 758 lb ▶ Tire OptionsR3 Turf - Rear n/a 26x12-12 R3 Turf - Front n/a 18x8.50-10 Tire Size & Options n/a Front: R3 Turf 18x8.50-10, R3 Turf Radial 18x8.50-10, R4 18x8.5-10 | Rear: R3 Turf 26x12-12, R4 26x12-12 R4 Industrial - Rear n/a 26x12-12 R4 Industrial - Front n/a 18x8.5-10 R1 Agricultural - Rear n/a 26x12.00-12 (R4 Industrial standard; R1 Agricultural not a standard listed option) R1 Agricultural - Front n/a 18x8.50-10 (R3 Turf / R4 Industrial listed; R1 Agricultural not a standard listed option) ▶ Fluid CapacityCoolant Capacity n/a 0.98 gal Crankcase Capacity n/a 0.71 gal Fuel Tank Capacity n/a 5.6 gal Front Axle Fluid Capacity n/a 0.74 gal Transmission / Hydraulic System Capacity n/a 3.3 gal ▶ Loader & AttachmentsLoader Lift Height n/a 72 in to maximum height at pivot pin (120R loader) Loader Breakout Force n/a 120R: 1,823 lbf at pivot point; H120: 1,724 lbf at pivot point Quick Attach Loader System n/a 120R Quik-Park Loader System Loader Lift Capacity (Full Height) n/a 120R: 754 lb at pivot point to max height; H120: 703 lb at pivot point to max height ▶ Transmission & DrivetrainClutch n/a wet disc No. of Speeds n/a Infinite (hydrostatic), 2-range (Hi/Lo) forward and reverse Transmission Type n/a hydrostatic Max Travel Speed (Forward) n/a 9.1 mph Max Travel Speed (Reverse) n/a 9.1 mph Differential Lock & Limited Slip Options n/a Differential lock Yes; Limited slip differential No ▶ Chassis, Steering & ControlsBrakes n/a Wet disc (left-hand pedal) Steering n/a Power Frame Type n/a Semi-flat platform; two-post folding ROPS; 4WD with mechanical front-wheel drive Front Axle Type n/a Four-wheel drive Front Axle Rating n/a Front 1349 lb Seat Suspension & Adjustability n/a Premium seat; adjusts fore/aft; seat flips forward; high seat back and armrests; retractable seat belt ▶ Dimensions & ManeuverabilityWheelbase n/a 57.1 inches 57.1 in Overall Width n/a 47 in Ground Clearance n/a 7.7 in. Min. Turn Radius without Brakes n/a 2.51 m 8.2 ft
