▶ EnginePTO Power n/a 18.2 hp Alternator n/a 40 A, 12 V Air Cleaner n/a Dual element Engine Type n/a Diesel Fuel System n/a Indirect injection Displacement n/a 77.3 in³ No. of Cylinders n/a 3 Rated Engine Speed n/a 3200 rpm Cooling System Type n/a Water pump (liquid-cooled) Engine Manufacturer n/a Yanmar Engine Power (Gross) n/a 23.9 hp @ 200 rpm Engine Emissions Constraints n/a Tier 4 ▶ WeightWeight with ROPS and Loader n/a ~2,005 lb (open station shipping weight 1,872 lb / 1,871.7 lb base; with H130 loader approx. 2,005 lb estimated) Weight with Cab and Loader n/a ~2,392 lb base cab shipping weight (loader weight additive) ▶ WarrantyWarranty Length & Coverage n/a 2-year bumper-to-bumper (comprehensive) + 6-year/2,000-hour powertrain warranty ▶ HydraulicsPump Type n/a Gear Steering Flow n/a 3.5 gpm Implement Flow n/a 3.5 gpm Total Hydraulic Flow n/a 5.6 gpm 21.2 lpm Hydraulic System Type n/a Open center Rear Remote Hydraulic Flow n/a 3.4 gpm implement circuit; 7.0 gpm combined pump output Overall Hydraulic Pump Flow n/a 3.4 gpm 12.9 lpm No. of Optional Remote Valves n/a 2 No. of Standard Remote Valves n/a 0 ▶ PTO & HitchPTO Rear n/a 540 rpm PTO Type n/a independent Lift Control Type n/a position control Hitch Lift Capacity n/a 915 lb Mid-PTO Availability n/a Mid - 2100 rpm Category, 3-Point Hitch n/a Limited Category 1 Hitch Lift Capacity (at 24”) n/a 915 lb ▶ Tire OptionsR3 Turf - Rear n/a 12-16.5 or R3 Radial: 280/70 R16 R3 Turf - Front n/a 23x8.50-12 or R3 Radial: 220/55-R12 Tire Size & Options n/a Front: 23x8.5-12 (R4 industrial / R3 turf); Rear: 31x12-16.5 (R4 industrial / R3 turf) R4 Industrial - Rear n/a 12-16.5 R4 Industrial - Front n/a 23x8.50-12 R1 Agricultural - Rear n/a Not separately listed; industrial R4 rear: 31x12.00-16.5 R1 Agricultural - Front n/a Not separately listed; industrial R4 front: 23x8.50-12 ▶ Fluid CapacityCoolant Capacity n/a 0.84 gal Crankcase Capacity n/a 0.84 gal Fuel Tank Capacity n/a 6.1 gal Front Axle Fluid Capacity n/a 0.89 gal Transmission / Hydraulic System Capacity n/a 3.5 gal ▶ Loader & AttachmentsLoader Lift Height n/a Gen 1 (H130): 78.9 in at pin; Gen 2 (120R): 72 in at pivot Loader Breakout Force n/a Gen 1 (H130): 2,508 lb at pin; Gen 2 (120R): 1,963 lb at pivot Quick Attach Loader System n/a Quick-park / quick-attach system (H130 loader on Gen 1; 120R loader on Gen 2) Loader Lift Capacity (Full Height) n/a Gen 1 (H130): 1,023 lb at pin; Gen 2 (120R): 754 lb at pivot ▶ Transmission & DrivetrainClutch n/a wet disc No. of Speeds n/a Two range (Hi and Lo) Transmission Type n/a Hydrostatic - two range Max Travel Speed (Forward) n/a 12.3 mph Max Travel Speed (Reverse) n/a 11.4 mph Differential Lock & Limited Slip Options n/a Differential lock: Yes; Limited slip differential: No ▶ Chassis, Steering & ControlsBrakes n/a Wet disc Steering n/a Power steering Frame Type n/a Open center; spur gear final drive; wet disc brakes Front Axle Type n/a Four-wheel drive Drawbar Capacity n/a Not Published Front Axle Rating n/a 1349 lb Seat Suspension & Adjustability n/a Fore/aft adjustable; seat flips forward for weather protection; no mechanical suspension listed ▶ Dimensions & ManeuverabilityWheelbase n/a 63 in. Overall Width n/a Not Published Ground Clearance n/a 12.5 in Height to Top of ROPS n/a Two-post foldable ROPS (folded/upright height not confirmed in sources) Height to Top of Cab Model n/a Not Published Height to Top of ROPS (folded) n/a Not Published Min. Turn Radius without Brakes n/a 2.51 m 8.2 ft Overall Length with 3-Point Hitch n/a 109.2 in
