John Deere 6155R vs John Deere 2025R | Side-by-side comparison

ITC Company

Good things come to those who wait.


PTO Power	—	18.2 hp
Alternator	—	40 A, 12 V
Air Cleaner	—	Dual element
Engine Type	—	Diesel
Fuel System	—	Indirect injection
Displacement	—	77.3 in³
No. of Cylinders	—	3
Rated Engine Speed	—	3200 rpm
Cooling System Type	—	Water pump (liquid-cooled)
Engine Manufacturer	—	Yanmar
Engine Emissions Constraints	—	Tier 4
Engine Power (Gross)	—	23.9 hp @ 200 rpm

Tractor Weight with Loader	—	Open station: 1872 lb; Cab: 2392 lb
Weight with Cab and Loader	—	~2,392 lb base cab shipping weight (loader weight additive)
Weight with ROPS and Loader	—	~2,005 lb (open station shipping weight 1,872 lb / 1,871.7 lb base; with H130 loader approx. 2,005 lb estimated)

Pump Type	—	Gear
Steering Flow	—	3.5 gpm
Implement Flow	—	3.5 gpm
Total Hydraulic Flow	—	5.6 gpm 21.2 lpm
Hydraulic System Type	—	Open center
Rear Remote Hydraulic Flow	—	3.4 gpm implement circuit; 7.0 gpm combined pump output
Overall Hydraulic Pump Flow	—	3.4 gpm 12.9 lpm
No. of Optional Remote Valves	—	2
No. of Standard Remote Valves	—	0

PTO Rear	—	540 rpm
PTO Type	—	independent
Lift Control Type	—	position control
Mid-PTO Availability	—	Mid - 2100 rpm
Category, 3-Point Hitch	—	Limited Category 1
Hitch Lift Capacity	—	915 lb
Hitch Lift Capacity (at 24”)	—	915 lb

R3 Turf - Rear	—	12-16.5 or R3 Radial: 280/70 R16
R3 Turf - Front	—	23x8.50-12 or R3 Radial: 220/55-R12
Tire Size & Options	—	Front: 23x8.5-12 (R4 industrial / R3 turf); Rear: 31x12-16.5 (R4 industrial / R3 turf)
R4 Industrial - Rear	—	12-16.5
R4 Industrial - Front	—	23x8.50-12
R1 Agricultural - Rear	—	Not separately listed; industrial R4 rear: 31x12.00-16.5
R1 Agricultural - Front	—	Not separately listed; industrial R4 front: 23x8.50-12

Coolant Capacity	—	0.84 gal
Crankcase Capacity	—	0.84 gal
Fuel Tank Capacity	—	6.1 gal
Front Axle Fluid Capacity	—	0.89 gal
Transmission / Hydraulic System Capacity	—	3.5 gal

Loader Lift Height	—	Gen 1 (H130): 78.9 in at pin; Gen 2 (120R): 72 in at pivot
Loader Breakout Force	—	Gen 1 (H130): 2,508 lb at pin; Gen 2 (120R): 1,963 lb at pivot
Quick Attach Loader System	—	Quick-park / quick-attach system (H130 loader on Gen 1; 120R loader on Gen 2)
Loader Lift Capacity (Full Height)	—	Gen 1 (H130): 1,023 lb at pin; Gen 2 (120R): 754 lb at pivot
Price for Backhoe Option	—	Not Published
Price for Mid-Mount Mower	—	Not Published

Clutch	—	wet disc
No. of Speeds	—	Two range (Hi and Lo)
Transmission Type	—	Hydrostatic - two range
Max Travel Speed (Forward)	—	12.3 mph
Max Travel Speed (Reverse)	—	11.4 mph
Differential Lock & Limited Slip Options	—	Differential lock: Yes; Limited slip differential: No

Brakes	—	Wet disc
Steering	—	Power steering
Frame Type	—	Open center; spur gear final drive; wet disc brakes
Front Axle Type	—	Four-wheel drive
Front Axle Rating	—	1349 lb
Seat Suspension & Adjustability	—	Fore/aft adjustable; seat flips forward for weather protection; no mechanical suspension listed

Wheelbase	—	63 in.
Ground Clearance	—	12.5 in
Height to Top of ROPS	—	Two-post foldable ROPS (folded/upright height not confirmed in sources)
Min. Turn Radius without Brakes	—	2.51 m 8.2 ft
Overall Length with 3-Point Hitch	—	109.2 in
Overall Width	—	Not Published
Height to Top of Cab Model	—	Not Published
Height to Top of ROPS (folded)	—	Not Published

Financing Options	—	0% APR fixed rate for 60 months AND Get $500 off on new John Deere 2025R Compact Tractors
Warranty Length & Coverage	—	2-year bumper-to-bumper (comprehensive) + 6-year/2,000-hour powertrain warranty

Brakes	—	Wet disc
Steering	—	Power steering
Frame Type	—	Open operator station; folding ROPS
Front Axle Type	—	Four-wheel drive (4WD)
Drawbar Capacity	—	Not Published
Front Axle Rating	—	1,349 lb
Seat Suspension & Adjustability	—	High-back seat with suspension

Financing Options	—	90 Day No Interest No Payment; Free Delivery (up to $125)
Base Price with Loader	—	Not Published
Warranty Length & Coverage	—	6-year/2,000-hour powertrain; 2-year/2,000-hour basic (full machine)
Base Price with Loader + Cab	—	Not Published

Accessories that fit	ITC SawBoss - Lifetime Warranty Chainsaw Scabbard $180.00 The best chainsaw carrier ever built for a tractor. ITC Tractor Recovery Kit $300.00 The one and only Kinetic Recovery Kit designed with tractor owners in mind with some major upgrades over the entire marketplace. Milwaukee Packout Mount for Tractors $100.00 Universal-fitting Milwaukee Packout bracket. Major upgrade to on tractor storage. ITC Tractor Toolbox Kit $120.00 Toolbox kit from out Modular Tool System. Part of a larger ecosystem of attachments. Semi Universal Tractor Grab Handle $75.00 Quick Clamp on grab handle that fits most tractors, check the product listing for fitment details.	ITC SawBoss - Lifetime Warranty Chainsaw Scabbard $180.00 The best chainsaw carrier ever built for a tractor. ITC Tractor Recovery Kit $300.00 The one and only Kinetic Recovery Kit designed with tractor owners in mind with some major upgrades over the entire marketplace. Milwaukee Packout Mount for Tractors $100.00 Universal-fitting Milwaukee Packout bracket. Major upgrade to on tractor storage. ITC Tractor Toolbox Kit $120.00 Toolbox kit from out Modular Tool System. Part of a larger ecosystem of attachments. Semi Universal Tractor Grab Handle $75.00 Quick Clamp on grab handle that fits most tractors, check the product listing for fitment details.

PTO Power

—

18.2 hp

Alternator

—

40 A, 12 V

Air Cleaner

—

Dual element

Engine Type

—

Diesel

Fuel System

—

Indirect injection

Displacement

—

77.3 in³

No. of Cylinders

—

Rated Engine Speed

—

3200 rpm

Cooling System Type

—

Water pump (liquid-cooled)

Engine Manufacturer

—

Yanmar

Engine Emissions Constraints

—

Tier 4

Engine Power (Gross)

—

23.9 hp @ 200 rpm

Tractor Weight with Loader

—

Open station: 1872 lb; Cab: 2392 lb

Weight with Cab and Loader

—

~2,392 lb base cab shipping weight (loader weight additive)

Weight with ROPS and Loader

—

~2,005 lb (open station shipping weight 1,872 lb / 1,871.7 lb base; with H130 loader approx. 2,005 lb estimated)

Pump Type

—

Gear

Steering Flow

—

3.5 gpm

Implement Flow

—

3.5 gpm

Total Hydraulic Flow

—

5.6 gpm 21.2 lpm

Hydraulic System Type

—

Open center

Rear Remote Hydraulic Flow

—

3.4 gpm implement circuit; 7.0 gpm combined pump output

Overall Hydraulic Pump Flow

—

3.4 gpm 12.9 lpm

No. of Optional Remote Valves

—

No. of Standard Remote Valves

—

PTO Rear

—

540 rpm

PTO Type

—

independent

Lift Control Type

—

position control

Mid-PTO Availability

—

Mid - 2100 rpm

Category, 3-Point Hitch

—

Limited Category 1

Hitch Lift Capacity

—

915 lb

Hitch Lift Capacity (at 24”)

—

915 lb

R3 Turf - Rear

—

12-16.5 or R3 Radial: 280/70 R16

R3 Turf - Front

—

23x8.50-12 or R3 Radial: 220/55-R12

Tire Size & Options

—

Front: 23x8.5-12 (R4 industrial / R3 turf); Rear: 31x12-16.5 (R4 industrial / R3 turf)

R4 Industrial - Rear

—

12-16.5

R4 Industrial - Front

—

23x8.50-12

R1 Agricultural - Rear

—

Not separately listed; industrial R4 rear: 31x12.00-16.5

R1 Agricultural - Front

—

Not separately listed; industrial R4 front: 23x8.50-12

Coolant Capacity

—

0.84 gal

Crankcase Capacity

—

0.84 gal

Fuel Tank Capacity

—

6.1 gal

Front Axle Fluid Capacity

—

0.89 gal

Transmission / Hydraulic System Capacity

—

3.5 gal

Loader Lift Height

—

Gen 1 (H130): 78.9 in at pin; Gen 2 (120R): 72 in at pivot

Loader Breakout Force

—

Gen 1 (H130): 2,508 lb at pin; Gen 2 (120R): 1,963 lb at pivot

Quick Attach Loader System

—

Quick-park / quick-attach system (H130 loader on Gen 1; 120R loader on Gen 2)

Loader Lift Capacity (Full Height)

—

Gen 1 (H130): 1,023 lb at pin; Gen 2 (120R): 754 lb at pivot

Price for Backhoe Option

—

Not Published

Price for Mid-Mount Mower

—

Not Published

Clutch

—

wet disc

No. of Speeds

—

Two range (Hi and Lo)

Transmission Type

—

Hydrostatic - two range

Max Travel Speed (Forward)

—

12.3 mph

Max Travel Speed (Reverse)

—

11.4 mph

Differential Lock & Limited Slip Options

—

Differential lock: Yes; Limited slip differential: No

Brakes

—

Wet disc

Steering

—

Power steering

Frame Type

—

Open center; spur gear final drive; wet disc brakes

Front Axle Type

—

Four-wheel drive

Front Axle Rating

—

1349 lb

Seat Suspension & Adjustability

—

Fore/aft adjustable; seat flips forward for weather protection; no mechanical suspension listed

Wheelbase

—

63 in.

Ground Clearance

—

12.5 in

Height to Top of ROPS

—

Two-post foldable ROPS (folded/upright height not confirmed in sources)

Min. Turn Radius without Brakes

—

2.51 m 8.2 ft

Overall Length with 3-Point Hitch

—

109.2 in

Overall Width

—

Not Published

Height to Top of Cab Model

—

Not Published

Height to Top of ROPS (folded)

—

Not Published

Financing Options

—

0% APR fixed rate for 60 months AND Get $500 off on new John Deere 2025R Compact Tractors

Warranty Length & Coverage

—

2-year bumper-to-bumper (comprehensive) + 6-year/2,000-hour powertrain warranty

Brakes

—

Wet disc

Steering

—

Power steering

Frame Type

—

Open operator station; folding ROPS

Front Axle Type

—

Four-wheel drive (4WD)

Drawbar Capacity

—

Not Published

Front Axle Rating

—

1,349 lb

Seat Suspension & Adjustability

—

High-back seat with suspension

Financing Options

—

90 Day No Interest No Payment; Free Delivery (up to $125)

Base Price with Loader

—

Not Published

Warranty Length & Coverage

—

6-year/2,000-hour powertrain; 2-year/2,000-hour basic (full machine)

Base Price with Loader + Cab

—

Not Published
