▶ EnginePTO Power — 18.2 hp Alternator — 40 A Air Cleaner — Dual element with mechanical restriction indicator Engine Type — Diesel Fuel System — Indirect injection Displacement — 77.3 in³ No. of Cylinders — 3 Rated Engine Speed — 3200 rpm Cooling System Type — Water pump Engine Manufacturer — Yanmar Engine Power (Gross) — 23.9 hp @ 200 rpm Engine Emissions Constraints — Tier 4 ▶ WeightTractor Weight (Base) — Open station: 1556 lb Weight with Cab and Loader — approx. 1,996 lb shipping weight with cab Weight with ROPS and Loader — approx. 1,444 lb shipping weight open station (no loader); operating weight with loader approx. 1,556 lb shipping ▶ WarrantyWarranty Length & Coverage — 6-year / 2,000-hour powertrain warranty (standard); PowerGard extended warranty available ▶ HydraulicsPump Type — Single gear Steering Flow — 3.5 gpm Implement Flow — 3.5 gpm Total Hydraulic Flow — 6.3 gpm 23.8 lpm Hydraulic System Type — Open center System Operating Pressure — 2000 psi Rear Remote Hydraulic Flow — 3.5 gpm per pump (implement circuit); total system output 6.3 gpm Overall Hydraulic Pump Flow — 3.5 gpm 13.2 lpm No. of Optional Remote Valves — Three ▶ PTO & HitchPTO Rear — 540 rpm PTO Type — Independent Lift Control Type — position control Hitch Lift Capacity — 758 lb Mid-PTO Availability — 2100 rpm Category, 3-Point Hitch — Limited Category 1 Hitch Lift Capacity (at 24”) — 758 lb ▶ Tire OptionsR3 Turf - Rear — 26x12-12 R3 Turf - Front — 18x8.50-10 Tire Size & Options — Front: R3 Turf 18x8.50-10, R3 Turf Radial 18x8.50-10, R4 18x8.5-10 | Rear: R3 Turf 26x12-12, R4 26x12-12 R4 Industrial - Rear — 26x12-12 R4 Industrial - Front — 18x8.5-10 R1 Agricultural - Rear — 26x12.00-12 (R4 Industrial standard; R1 Agricultural not a standard listed option) R1 Agricultural - Front — 18x8.50-10 (R3 Turf / R4 Industrial listed; R1 Agricultural not a standard listed option) ▶ Fluid CapacityCoolant Capacity — 0.98 gal Crankcase Capacity — 0.71 gal Fuel Tank Capacity — 5.6 gal Front Axle Fluid Capacity — 0.74 gal Transmission / Hydraulic System Capacity — 3.3 gal ▶ Loader & AttachmentsLoader Lift Height — 72 in to maximum height at pivot pin (120R loader) Loader Breakout Force — 120R: 1,823 lbf at pivot point; H120: 1,724 lbf at pivot point Quick Attach Loader System — 120R Quik-Park Loader System Loader Lift Capacity (Full Height) — 120R: 754 lb at pivot point to max height; H120: 703 lb at pivot point to max height ▶ Transmission & DrivetrainClutch — wet disc No. of Speeds — Infinite (hydrostatic), 2-range (Hi/Lo) forward and reverse Transmission Type — hydrostatic Max Travel Speed (Forward) — 9.1 mph Max Travel Speed (Reverse) — 9.1 mph Differential Lock & Limited Slip Options — Differential lock Yes; Limited slip differential No ▶ Chassis, Steering & ControlsBrakes — Wet disc (left-hand pedal) Steering — Power Frame Type — Semi-flat platform; two-post folding ROPS; 4WD with mechanical front-wheel drive Front Axle Type — Four-wheel drive Front Axle Rating — Front 1349 lb Seat Suspension & Adjustability — Premium seat; adjusts fore/aft; seat flips forward; high seat back and armrests; retractable seat belt ▶ Dimensions & ManeuverabilityWheelbase — 57.1 inches 57.1 in Overall Width — 47 in Ground Clearance — 7.7 in. Min. Turn Radius without Brakes — 2.51 m 8.2 ft
