PTO Power	—	18.2 hp
Mid PTO (Type / RPM)	—	2100 rpm
Rear PTO (Type / RPM)	—	540 rpm

Three-Point Hitch Category	—	Limited Category 1
Lift Capacity at 24 in Behind	—	758 lb

PTO Power	—	18.2 hp
Alternator	—	40 A
Air Cleaner	—	Dual element with mechanical restriction indicator
Engine Type	—	Diesel
Fuel System	—	Indirect injection
Displacement	—	77.3 in³
No. of Cylinders	—	3
Rated Engine Speed	—	3200 rpm
Cooling System Type	—	Water pump
Engine Manufacturer	—	Yanmar
Engine Emissions Constraints	—	Tier 4
Engine Power (Gross)	—	23.9 hp @ 200 rpm

Tractor Weight (Base)	—	Open station: 1556 lb
Weight with Cab and Loader	—	approx. 1,996 lb shipping weight with cab
Weight with ROPS and Loader	—	approx. 1,444 lb shipping weight open station (no loader); operating weight with loader approx. 1,556 lb shipping

Pump Type	—	Single gear
Steering Flow	—	3.5 gpm
Implement Flow	—	3.5 gpm
Pump Flow (Total)	—	6.3 gpm
Pump Flow (Steering)	—	3.5 gpm
Total Hydraulic Flow	—	6.3 gpm 23.8 lpm
Hydraulic System Type	—	Open center
Pump Flow (Implement)	—	3.5 gpm
System Operating Pressure	—	2000 psi
Rear Remote Hydraulic Flow	—	3.5 gpm per pump (implement circuit); total system output 6.3 gpm
Overall Hydraulic Pump Flow	—	3.5 gpm 13.2 lpm
No. of Optional Remote Valves	—	Three

Wheelbase	—	57.1 in.
Ground Clearance	—	7.7 in.

PTO Rear	—	540 rpm
PTO Type	—	Independent
Lift Control Type	—	position control
Mid-PTO Availability	—	2100 rpm
Category, 3-Point Hitch	—	Limited Category 1
Hitch Lift Capacity	—	758 lb

R3 Turf - Rear	—	26x12-12
R3 Turf - Front	—	18x8.50-10
Tire Size & Options	—	Front: R3 Turf 18x8.50-10, R3 Turf Radial 18x8.50-10, R4 18x8.5-10 \| Rear: R3 Turf 26x12-12, R4 26x12-12
R4 Industrial - Rear	—	26x12-12
R4 Industrial - Front	—	18x8.5-10
R1 Agricultural - Rear	—	26x12.00-12 (R4 Industrial standard; R1 Agricultural not a standard listed option)
R1 Agricultural - Front	—	18x8.50-10 (R3 Turf / R4 Industrial listed; R1 Agricultural not a standard listed option)

Transmission Type	—	Hydrostatic - two range

Coolant Capacity	—	0.98 gal
Crankcase Capacity	—	0.71 gal
Fuel Tank Capacity	—	5.6 gal
Front Axle Fluid Capacity	—	0.74 gal
Transmission / Hydraulic System Capacity	—	3.3 gal
Transmission/Hydraulic Capacity	—	3.2 gal.

Loader Lift Height	—	72 in to maximum height at pivot pin (120R loader)
Loader Breakout Force	—	120R: 1,823 lbf at pivot point; H120: 1,724 lbf at pivot point
Quick Attach Loader System	—	120R Quik-Park Loader System
Loader Lift Capacity (Full Height)	—	120R: 754 lb at pivot point to max height; H120: 703 lb at pivot point to max height

Clutch	—	wet disc
No. of Speeds	—	Infinite (hydrostatic), 2-range (Hi/Lo) forward and reverse
Transmission Type	—	hydrostatic
Max Travel Speed (Forward)	—	9.1 mph
Max Travel Speed (Reverse)	—	9.1 mph
Differential Lock & Limited Slip Options	—	Differential lock Yes; Limited slip differential No

Brakes	—	Wet disc (left-hand pedal)
Steering	—	Power
Frame Type	—	Semi-flat platform; two-post folding ROPS; 4WD with mechanical front-wheel drive
Front Axle Type	—	Four-wheel drive
Front Axle Rating	—	Front 1349 lb
Seat Suspension & Adjustability	—	Premium seat; adjusts fore/aft; seat flips forward; high seat back and armrests; retractable seat belt

Wheelbase	—	57.1 inches 57.1 in
Overall Width	—	47 in
Ground Clearance	—	7.7 in.
Min. Turn Radius without Brakes	—	2.51 m 8.2 ft

Financing Options	—	0% APR fixed rate for 60 months; 0% APR fixed rate for 72 Months PLUS $1,000 off
Warranty Length & Coverage	—	6-year / 2,000-hour powertrain warranty (standard); PowerGard extended warranty available
