▶ EngineEngine Manufacturer KIOTI (Daedong) Kubota Kubota Engine Model CK2610: 3A165LWM-U; CK2610 HST: 3A165LWH-U D1703-M-DI-E4 D1305-E4-D36-R Engine Type 3 cylinder, in-line vertical, water-cooled 4-cycle diesel Direct injection, vertical, water-cooled, 4-cycle diesel 3-cylinder, indirect injection, liquid-cooled diesel No. of Cylinders 3 3 3 Displacement 100.5 in³ 100.47 in³ 77 in³ Rated Engine Speed 2600 rpm 2200 rpm 2500 rpm Engine Power (Gross) 24.5 hp 24.8 hp 24.8 hp PTO Power CK2610: 21.7 hp; CK2610 HST: 21.5 hp 19 hp 19.5 hp Engine Emissions Constraints Tier 4 Tier 4 Not Published Cooling System Type Water-cooled Water-cooled Pressurized radiator Air Cleaner Not Published Dry paper single element (dual optional) 4.5 in Dual paper element Fuel System Not Published Direct injection Indirect injection Alternator Not Published 40 A, 12 V 40 A, 12 V ▶ HydraulicsPump Type Gear Open center tandem pump, gear type Dual pump Implement Flow Not Published 5.15 gpm 5.0 gpm Steering Flow Not Published 3.11 gpm 3.7 gpm Total Hydraulic Flow 11.7 gpm 8.26 gpm 8.7 gpm Overall Hydraulic Pump Flow 11.7 gpm 8.26 gpm 8.7 gpm Hydraulic System Type Open center Open center Open center Rear Remote Hydraulic Flow Not Published Not Published Not Published No. of Standard Remote Valves None (2 optional) Not Published None (remote valves optional) No. of Optional Remote Valves 2 (4 ports) Up to 3: self-canceling detent valve or float detent valve Optional, up to 2 ▶ Fluid CapacityFuel Tank Capacity 9 gal 10.0 gal 7.1 gal Coolant Capacity Not Published 6.3 qt 4.5 qt Crankcase Capacity Not Published 6.0 qt 4.2 qt Transmission / Hydraulic System Capacity Not Published HST (4WD): 6.2 gal; DT (2WD): 7.1 gal; DT (4WD): 7.3 gal 4.0 gal Front Axle Fluid Capacity Not Published 6.9 qt 5.0 qt ▶ PTO & HitchPTO Type Live F (2WD), DT (4WD): Transmission driven with overrunning clutch; HST (4WD): Live-continuous running Independent PTO Rear 540 rpm 540 rpm 540 rpm Mid-PTO Availability Optional, 2,000 rpm No mid-PTO offered 2500 rpm Category, 3-Point Hitch Category I Category I Category I Hitch Lift Capacity Not Published 1,918 lb 2,139 lb Hitch Lift Capacity (at 24”) 1,631 lb 1,389 lb 1,676 lb Lift Control Type Position control Position control Position control valve ▶ Transmission & DrivetrainTransmission Type CK2610: Manual; CK2610 HST: Hydrostatic Hydrostatic transmission (3-range) Hydrostatic transmission No. of Speeds CK2610: 9F/3R; CK2610 HST: Infinite, 3 range 3-range 3 ranges Max Travel Speed (Forward) CK2610: 10.08 mph; CK2610 HST: 10.31 mph 11.5 mph 11.2 mph Max Travel Speed (Reverse) CK2610: 6.58 mph; CK2610 HST: 9.25 mph 10.3 mph 8.4 mph Clutch CK2610: Dry dual stage; CK2610 HST: Dry single stage Not Published Not Applicable Differential Lock & Limited Slip Options Rear differential lock (standard) Rear differential lock standard Differential lock standard ▶ Chassis, Steering & ControlsFrame Type Not Published Not Published Not Published Steering Hydrostatic power steering Integral type power steering Hydraulic power steering Brakes Wet multi-disc Wet disc type Multi-plate wet disc Seat Suspension & Adjustability Not Published Suspension seat with fore/aft travel adjustment and suspension tension adjustment Deluxe high-back suspension seat Front Axle Type 4WD, mechanical engagement (standard) Bevel gear front axle, non-adjustable tread spacing Not Published Front Axle Rating Not Published 2,865 lb (4WD, at 43.1 in tread) Not Published Drawbar Capacity Not Published 730 lb 1,100 lb ▶ Dimensions & ManeuverabilityOverall Width 54.5 in 55.1 in 53.7 in Wheelbase 65.7 in 63.3 in 65.6 in Ground Clearance 13.4 in 13.4 in 14.6 in Min. Turn Radius without Brakes 8 ft (with brake applied) 8.2 ft (with brake applied) 6.9 ft (with brake applied) Height to Top of ROPS 99.2 in 91.7 in 88.4 in Height to Top of ROPS (folded) Not Published Not Published Not Published Height to Top of Cab Model Not Published Not Published Not Applicable Overall Length 120.9 in (with 3-point hitch) 106.3 in (without 3-point hitch) 101.8 in (without 3-point hitch) ▶ WeightTractor Weight (Base) CK2610: 2,646 lb; CK2610 HST: 2,701 lb 2,623 lb 1,830 lb Weight with ROPS and Loader Not Published Not Published Not Published Weight with Cab and Loader Not Published Not Published Not Published ▶ Tire OptionsTire Size & Options Front AG 7-16 (Turf 28x8.5-15/6, Industrial 27x8.5-15); Rear AG 11.2-24 (Turf 41x14-20/4, Industrial 15-19.5) R1 Agricultural; R4 Industrial R1 Agricultural, R3 Turf, R4 Industrial, R14 R1 Agricultural - Front 7-16 7.2-16 7-12 R1 Agricultural - Rear 11.2-24 11.2-24 12.4-16 R3 Turf - Front 28x8.5-15/6 Not Published 24x8.50-14 R3 Turf - Rear 41x14-20/4 Not Published 13.6-16 R4 Industrial - Front 27x8.5-15 27X8.50-15 23X8.50-14 / 25X8.50-14 R4 Industrial - Rear 15-19.5 15-19.5 12.4-16 / 15-19.5 ▶ Loader & AttachmentsQuick Attach Loader System Quick-attach (QA) bucket Front Loader (LA525 - 2 Lever Quick Coupler) LA535: 2-lever quick coupler, standard; Swift-Tach, optional Loader Model KL2610 LA525 LA535 Loader Lift Height 98.4 in (KL2610 loader) 94.3 in (at pivot pin) 84 in (at pivot pin) Loader Lift Capacity (Full Height) KL2610: 1,252 lb (at pivot pin) 1,082 lb (at pivot pin) 1,067 lb (at pivot pin) Loader Breakout Force KL2610: 2,110 lb (at pivot pin) 2,373 lbf (at pivot pin) 2,245 lb (at pivot pin) ▶ WarrantyWarranty Length & Coverage Not Published Residential: basic 24 months or 1,500 hours, powertrain 72 months or 2,000 hours; commercial: basic 24 months or 1,500 hours, powertrain 36 months or 2,000 hours Residential: basic 24 months or 1,500 hours, powertrain 72 months or 2,000 hours; commercial: basic 24 months or 1,500 hours, powertrain 36 months or 2,000 hours ▶ ITC Company AccessoriesAccessories that fit
