▶ EnginePTO Power 23 hp 26.2 hp Alternator Not Published 55 A, 12 V Air Cleaner Not Published Dry Engine Type Liquid-cooled, diesel 3-cylinder, Liquid-cooled, Diesel, NA, IDI Fuel System Not Published IDI Displacement 91.5 in³ 100.2 in³ No. of Cylinders 3 3 Rated Engine Speed 2600 rpm 2600 rpm Cooling System Type Liquid-cooled Liquid-cooled Engine Manufacturer KIOTI (Daedong) YANMAR Engine Power (Gross) 30 hp 31.7 hp Engine Emissions Constraints Tier 4 Tier 4 ▶ WeightWeight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Applicable Not Published ▶ HydraulicsPump Type Not Published Gear pump Steering Flow Not Published 5.0 gpm Implement Flow Not Published 6.7 gpm Total Hydraulic Flow 12.7 gpm 11.7 gpm Hydraulic System Type Not Published Open center Rear Remote Hydraulic Flow Not Published Not Published Overall Hydraulic Pump Flow 12.7 gpm 11.7 gpm No. of Optional Remote Valves Not Published Not Published No. of Standard Remote Valves Not Published 1 ▶ PTO & HitchPTO Rear 540/1000 rpm 540 rpm PTO Type Live (two-stage clutch) Independent Lift Control Type Not Published Position control Hitch Lift Capacity 1,764 lb (at 24 in) 1808 lb Mid-PTO Availability Yes (2,000 rpm) Available (option) Category, 3-Point Hitch Category 1 Category I Hitch Lift Capacity (at 24”) 1,764 lb 1433 lb ▶ Tire OptionsR3 Turf - Rear 41X14.00-20 41X14.00-20 R3 Turf - Front 27X8.50-15 25X8.50-14 Tire Size & Options R1 Agricultural, R3 Turf, R4 Industrial R1 Agricultural, R3 Turf, R4 Industrial R4 Industrial - Rear 15-19.5 43X16.00-20 R4 Industrial - Front 25X8.50-14 27X8.50-15 R1 Agricultural - Rear 11.2-24 11.2-24 R1 Agricultural - Front 7.0-14 7-14 ▶ Fluid CapacityCoolant Capacity Not Published Not Published Crankcase Capacity Not Published Not Published Fuel Tank Capacity 7.9 gal 11.4 gal Front Axle Fluid Capacity Not Published Not Published Transmission / Hydraulic System Capacity Not Published Not Published ▶ Loader & AttachmentsLoader Lift Height 92.5 in 94.3 in Loader Breakout Force 2,046 lb 3,723 lb Quick Attach Loader System Not Published LL3003: ISO 24410 Quick Attaching Coupler Loader Lift Capacity (Full Height) 1,155 lb 2,506 lb ▶ Transmission & DrivetrainClutch Two-stage clutch Not Applicable No. of Speeds 8F/8R 3 ranges Transmission Type 8-speed synchronized shuttle Hydrostatic Drive Max Travel Speed (Forward) 14.2 mph Not Published Max Travel Speed (Reverse) Not Published Not Published Differential Lock & Limited Slip Options Not Published Mechanical differential lock (pedal) ▶ Chassis, Steering & ControlsBrakes Wet disc brakes Wet, Multi-disc Steering Power steering Hydrostatic power steering Frame Type Not Published Not Published Front Axle Type 4WD Not Published Drawbar Capacity Not Published Not Published Front Axle Rating Not Published Not Published Seat Suspension & Adjustability Not Published Not Published ▶ Dimensions & ManeuverabilityWheelbase 66.1 in 69 in Overall Width 54.6 in 66 in Ground Clearance 13.82 in Not Published Height to Top of ROPS 96.8 in Not Applicable Height to Top of Cab Model Not Applicable 90 in Height to Top of ROPS (folded) Not Published Not Applicable Min. Turn Radius without Brakes Not Published 11.5 ft (3.5 m) Overall Length with 3-Point Hitch 122.2 in 125 in ▶ WarrantyWarranty Length & Coverage Limited: Tractors (Non-Commercial Application) 24 months parts & labor; Extended (driveline): 48 months parts & labor 6-year limited powertrain warranty; 2-year bumper-to-bumper warranty ▶ ITC Company AccessoriesAccessories that fit None tagged yet
