▶ EngineEngine Manufacturer KIOTI KIOTI (Daedong) Engine Model CK3520: 3H-TM4-U; CK3520H: 3H-TH4-U; CK3520SE, CK3520SEH, CK3520SEH CAB: 3H-TM4-U2 / 3H-TH4-U2 3H-TH4D Engine Type 3-cylinder, in-line, liquid-cooled diesel 3-cylinder, liquid-cooled diesel No. of Cylinders 3 3 Displacement 111.4 in³ 111.4 in³ Rated Engine Speed 2600 rpm 2600 rpm Engine Power (Gross) 34.9 hp 39.6 hp PTO Power CK3520, CK3520SE: 30.9 hp; CK3520H, CK3520SEH, CK3520SEH CAB: 28.9 hp 29.1 hp Engine Emissions Constraints Not Published Tier 4 Cooling System Type Liquid-cooled Liquid-cooled Air Cleaner Dry element Dry element Fuel System Not Published Not Published Alternator Not Published Not Published ▶ HydraulicsPump Type Gear Gear Implement Flow CK3520, CK3520H: 7.14 gpm; CK3520SE, CK3520SEH, CK3520SEH CAB: 6.86 gpm 9.62 gpm Steering Flow CK3520, CK3520H: 4.59 gpm; CK3520SE, CK3520SEH, CK3520SEH CAB: 4.46 gpm 6.87 gpm Total Hydraulic Flow CK3520, CK3520H: 11.73 gpm; CK3520SE, CK3520SEH, CK3520SEH CAB: 11.33 gpm 16.5 gpm Overall Hydraulic Pump Flow CK3520, CK3520H: 11.73 gpm; CK3520SE, CK3520SEH, CK3520SEH CAB: 11.33 gpm 16.5 gpm Hydraulic System Type Open center Not Published Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves CK3520, CK3520H: 0; CK3520SE, CK3520SEH, CK3520SEH CAB: 2 2 No. of Optional Remote Valves CK3520, CK3520H: 2 Not Published ▶ Fluid CapacityFuel Tank Capacity 9.0 gal 12.7 gal Coolant Capacity 0.89 gal 2.1 gal Crankcase Capacity 1.6 gal 1.95 gal Transmission / Hydraulic System Capacity 5.8 gal 11.4 gal Front Axle Fluid Capacity 1.6 gal 1.48 gal ▶ PTO & HitchPTO Type CK3520, CK3520H: Live; CK3520SE, CK3520SEH, CK3520SEH CAB: Independent Independent PTO Rear 540 rpm (1-3/8 in, 6 splines) 540 rpm Mid-PTO Availability Optional, 2,000 rpm Optional (2,000 rpm) Category, 3-Point Hitch Category I Category I Hitch Lift Capacity 2,270 lb 2,998 lb Hitch Lift Capacity (at 24”) 1,631 lb 2,716 lb Lift Control Type Position control Position ▶ Transmission & DrivetrainTransmission Type CK3520: Manual; CK3520H, CK3520SEH, CK3520SEH CAB: Hydrostatic; CK3520SE: Synchro shuttle Hydrostatic (HST) No. of Speeds CK3520: 9F/3R; CK3520H, CK3520SEH, CK3520SEH CAB: Infinite, 3 range; CK3520SE: 12F/12R 3 ranges (hydrostatic, infinite speeds) Max Travel Speed (Forward) CK3520: 14.64 mph; CK3520H, CK3520SEH, CK3520SEH CAB: 14.88 mph; CK3520SE: 15.53 mph 18.45 mph Max Travel Speed (Reverse) CK3520: 9.56 mph; CK3520H, CK3520SEH, CK3520SEH CAB: 10.41 mph; CK3520SE: 15.14 mph 12.92 mph Clutch CK3520: Dry dual stage; CK3520H, CK3520SE: Dry single stage; CK3520SEH, CK3520SEH CAB: None (hydrostatic) None (hydrostatic transmission) Differential Lock & Limited Slip Options Rear differential lock (standard) Rear differential lock (standard) ▶ Chassis, Steering & ControlsFrame Type Not Published Not Published Steering Hydrostatic power steering Hydrostatic power steering Brakes Wet multi-disc Wet multi-disc Seat Suspension & Adjustability Not Published Deluxe suspension seat Front Axle Type 4WD, manual engagement Mechanical 4WD Front Axle Rating Not Published Not Published Drawbar Capacity 1,433 lb 1,655 lb (max. drawbar vertical load) ▶ Dimensions & ManeuverabilityOverall Length with 3-Point Hitch 120.9 in 125.5 in Overall Width 54.5 in 62.8 in Wheelbase 65.7 in 71.3 in Ground Clearance 13.4 in 14.5 in Min. Turn Radius without Brakes 107.5 in 102.8 in (with brake applied) Height to Top of ROPS 92.9 in 96.8 in Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model 92.5 in 93.0 in ▶ WeightTractor Weight (Base) CK3520: 2,679 lb; CK3520H: 2,734 lb; CK3520SE: 2,906 lb; CK3520SEH: 2,921 lb; CK3520SEH CAB: 3,397 lb 3,523 lb (DK4220SEH); 4,043 lb (DK4220SEH CAB) Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options Front AG 7-16 (Turf 28x8.5-15/6, Industrial 27x8.5-15); Rear AG 11.2-24 (Turf 41x14-20/4, Industrial 15-19.5) R1 Agricultural, R3 Turf, R4 Industrial, R14 R1 Agricultural - Front 7-16 8-16 R1 Agricultural - Rear 11.2-24 13.6-24 R3 Turf - Front 28x8.5-15/6 29-12.5-15 R3 Turf - Rear 41x14-20/4 21.5L-16.1 R4 Industrial - Front 27x8.5-15 10-16.5 R4 Industrial - Rear 15-19.5 14.9-24 ▶ Loader & AttachmentsQuick Attach Loader System Not Published Quick attach (QA) bucket, 66 in or 72 in Loader Model KL4030; KL4030C KL5520; KL5521 (Cab models) Loader Lift Height 98.4 in (KL4030 and KL4030C loaders) KL5520: 107.7 in; KL5521: 107.7 in Loader Lift Capacity (Full Height) KL4030: 1,835 lb; KL4030C: 1,969 lb KL5520: 2,474 lb; KL5521: 2,474 lb Loader Breakout Force KL4030: 3,464 lb; KL4030C: 2,989 lb KL5520: 3,895 lb; KL5521: 3,895 lb ▶ WarrantyWarranty Length & Coverage 24 months unlimited hours, parts and labor (non-commercial); powertrain 72 months unlimited hours, parts and labor Non-commercial: 24 months, unlimited hours, parts and labor, 0% deductible; non-commercial powertrain (engine and driveline): 72 months, unlimited hours ▶ ITC Company AccessoriesAccessories that fit
