▶ EngineEngine Manufacturer KIOTI LS Mtron Engine Model CK3520, CK3520H: 3H-TM4A; CK3520SE, CK3520SEH, CK3520SEH CAB: 3H-TM4B L3CRV-T5 Engine Type 3-cylinder, in-line, liquid-cooled diesel 3-cylinder, turbocharged, liquid-cooled diesel No. of Cylinders 3 3 Displacement 111.4 in³ 114.7 in³ Rated Engine Speed 2600 rpm 2600 rpm Engine Power (Gross) 34.9 hp 35 hp PTO Power CK3520, CK3520SE: 30.9 hp; CK3520H, CK3520SEH, CK3520SEH CAB: 28.9 hp Gear: 29.7 hp; HST: 28 hp Engine Emissions Constraints Not Published Tier 4B (final) Cooling System Type Liquid-cooled Liquid cooled Air Cleaner Dry element Replaceable primary and inner elements Fuel System Not Published Electronically controlled common rail direct injection Alternator Not Published 70 A, 12 V ▶ HydraulicsPump Type Gear Gear Implement Flow CK3520, CK3520H: 7.14 gpm; CK3520SE, CK3520SEH, CK3520SEH CAB: 6.86 gpm 8.2 gpm Steering Flow CK3520, CK3520H: 4.59 gpm; CK3520SE, CK3520SEH, CK3520SEH CAB: 4.46 gpm Gear: 4.2 gpm; HST: 5.3 gpm Total Hydraulic Flow CK3520, CK3520H: 11.73 gpm; CK3520SE, CK3520SEH, CK3520SEH CAB: 11.33 gpm Gear: 12.4 gpm; HST: 13.5 gpm Overall Hydraulic Pump Flow CK3520, CK3520H: 11.73 gpm; CK3520SE, CK3520SEH, CK3520SEH CAB: 11.33 gpm Gear: 12.4 gpm; HST: 13.5 gpm Hydraulic System Type Open center Open center Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves CK3520, CK3520H: None; CK3520SE, CK3520SEH, CK3520SEH CAB: 2 1 No. of Optional Remote Valves CK3520, CK3520H: 2 Up to 2 (second valve optional) ▶ Fluid CapacityFuel Tank Capacity 9.0 gal 10.5 gal Coolant Capacity 0.89 gal 7.5 qt Crankcase Capacity 1.6 gal 5.8 qt Transmission / Hydraulic System Capacity 5.8 gal 8.5 gal Front Axle Fluid Capacity 1.6 gal 6.87 qt ▶ PTO & HitchPTO Type CK3520, CK3520H: Live; CK3520SE, CK3520SEH, CK3520SEH CAB: Independent Independent, electro-hydraulic engagement PTO Rear 540 rpm (1-3/8 in, 6 splines) 540 rpm Mid-PTO Availability Optional, 2,000 rpm Standard (2000 rpm) Category, 3-Point Hitch Category I Category I Hitch Lift Capacity 2,270 lb 1,808 lb Hitch Lift Capacity (at 24”) 1,631 lb 1,345 lb Lift Control Type Position control Position control (draft control optional) ▶ Transmission & DrivetrainTransmission Type CK3520: Manual; CK3520H, CK3520SEH, CK3520SEH CAB: Hydrostatic; CK3520SE: Synchro shuttle Gear: 12x12 synchronized shuttle shift (SSS); HST: 3-range hydrostatic, dual pedal No. of Speeds CK3520: 9F/3R; CK3520H, CK3520SEH, CK3520SEH CAB: Infinite, 3 range; CK3520SE: 12F/12R Gear: 12F/12R; HST: 3-range Max Travel Speed (Forward) CK3520: 14.64 mph; CK3520H, CK3520SEH, CK3520SEH CAB: 14.88 mph; CK3520SE: 15.53 mph Gear: 14.2 mph; HST: 14.8 mph Max Travel Speed (Reverse) CK3520: 9.56 mph; CK3520H, CK3520SEH, CK3520SEH CAB: 10.41 mph; CK3520SE: 15.14 mph Gear: 13.63 mph; HST: 13.60 mph Clutch CK3520: dry, dual-stage; CK3520H, CK3520SE: dry, single-stage; CK3520SEH, CK3520SEH CAB: n/a (hydrostatic) Gear: dry single disc (9.4 in); HST: n/a Differential Lock & Limited Slip Options Rear differential lock (standard) Mechanical rear differential lock (pedal) ▶ Chassis, Steering & ControlsFrame Type Not Published Not Published Steering Hydrostatic power steering Power steering Brakes Wet multi-disc Wet multi-disc Seat Suspension & Adjustability Not Published Adjustable suspension seat (fore/aft, weight and height adjustment) Front Axle Type 4WD, manual engagement Four-wheel drive (FWD) Front Axle Rating Not Published Not Published Drawbar Capacity 1,433 lb Not Published ▶ Dimensions & ManeuverabilityOverall Width 54.5 in 66.4 in Wheelbase 65.7 in 66 in Ground Clearance 13.4 in Not Published Min. Turn Radius without Brakes 107.5 in 9.2 ft (with brake applied) Height to Top of ROPS 92.9 in 92.7 in Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model n/a (ROPS model) Not Published Overall Length 120.87 in (with 3-point hitch) 119 in ▶ WeightTractor Weight (Base) CK3520: 2,679 lb; CK3520H: 2,734 lb; CK3520SE: 2,906 lb; CK3520SEH: 2,921 lb; CK3520SEH CAB: 3,397 lb Gear: 2,804 lb; HST: 2,870 lb Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options Front AG 7-16 (Turf 28x8.5-15/6, Industrial 27x8.5-15); Rear AG 11.2-24 (Turf 41x14-20/4, Industrial 15-19.5) R1 Agricultural, R3 Turf, R4 Industrial R1 Agricultural - Front 7-16 7-14 R1 Agricultural - Rear 11.2-24 11.2-24 R3 Turf - Front 28x8.5-15/6 25x8.50-14 R3 Turf - Rear 41x14-20/4 41x14.00-20 R4 Industrial - Front 27x8.5-15 25x8.50-14 R4 Industrial - Rear 15-19.5 43x16.00-20 ▶ Loader & AttachmentsQuick Attach Loader System Not Published Tool-free loader mount; optional skid-steer quick-attach plates Loader Model KL4030; KL4030C 250TLA Loader Lift Height 98.4 in (KL4030 and KL4030C loaders) 250TLA: 104 in (at pivot pin) Loader Lift Capacity (Full Height) KL4030: 1,835 lb; KL4030C: 1,969 lb 250TLA: 1,822 lb (at bucket pivot pin, max height) Loader Breakout Force KL4030: 3,464 lb; KL4030C: 2,989 lb 250TLA: 3,257 lb (at bucket pivot pin) ▶ WarrantyWarranty Length & Coverage Non-commercial: basic 24 months, powertrain 72 months, unlimited hours, parts and labor Basic 2 years or 750 hours; powertrain 4 more years (6 years or 1,500 hours total) ▶ ITC Company AccessoriesAccessories that fit None tagged yet
