▶ EngineEngine Manufacturer KIOTI LS Mtron Engine Model CK3520, CK3520H: 3H-TM4A; CK3520SE, CK3520SEH, CK3520SEH CAB: 3H-TM4B L3C19-T5 Engine Type 3-cylinder, in-line, liquid-cooled diesel 3-cylinder, turbocharged, liquid-cooled diesel No. of Cylinders 3 3 Displacement 111.4 in³ 114.7 in³ Rated Engine Speed 2600 rpm 2600 rpm Engine Power (Gross) 34.9 hp 35 hp PTO Power CK3520, CK3520SE: 30.9 hp; CK3520H, CK3520SEH, CK3520SEH CAB: 28.9 hp Gear: 29.7 hp; HST: 28 hp Engine Emissions Constraints Not Published Tier 4 Cooling System Type Liquid-cooled Pressurized liquid with recirculating bypass Air Cleaner Dry element Dual element (primary and inner safety element) Fuel System Not Published High pressure common rail, ECU-controlled timing Alternator Not Published 70 A, 12 V ▶ HydraulicsPump Type Gear Gear Implement Flow CK3520, CK3520H: 7.14 gpm; CK3520SE, CK3520SEH, CK3520SEH CAB: 6.86 gpm 8.2 gpm Steering Flow CK3520, CK3520H: 4.59 gpm; CK3520SE, CK3520SEH, CK3520SEH CAB: 4.46 gpm Gear: 4.2 gpm; HST: 5.3 gpm Total Hydraulic Flow CK3520, CK3520H: 11.73 gpm; CK3520SE, CK3520SEH, CK3520SEH CAB: 11.33 gpm Gear: 12.4 gpm; HST: 13.5 gpm Overall Hydraulic Pump Flow CK3520, CK3520H: 11.73 gpm; CK3520SE, CK3520SEH, CK3520SEH CAB: 11.33 gpm Gear: 12.4 gpm; HST: 13.5 gpm Hydraulic System Type Open center Open center Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves CK3520, CK3520H: None; CK3520SE, CK3520SEH, CK3520SEH CAB: 2 Not Published No. of Optional Remote Valves CK3520, CK3520H: 2 1 or 2 ▶ Fluid CapacityFuel Tank Capacity 9.0 gal 7.4 gal Coolant Capacity 0.89 gal 7.5 qt Crankcase Capacity 1.6 gal 5.8 qt Transmission / Hydraulic System Capacity 5.8 gal 8.5 gal Front Axle Fluid Capacity 1.6 gal 6.9 qt ▶ PTO & HitchPTO Type CK3520, CK3520H: Live; CK3520SE, CK3520SEH, CK3520SEH CAB: Independent Independent, electro-hydraulic engagement PTO Rear 540 rpm (1-3/8 in, 6 splines) 540 rpm Mid-PTO Availability Optional, 2,000 rpm HST: Standard; Gear: Optional (2,000 rpm) Category, 3-Point Hitch Category I Category I Hitch Lift Capacity 2,270 lb 1,808 lb Hitch Lift Capacity (at 24”) 1,631 lb 1,433 lb Lift Control Type Position control Position control ▶ Transmission & DrivetrainTransmission Type CK3520: Manual; CK3520H, CK3520SEH, CK3520SEH CAB: Hydrostatic; CK3520SE: Synchro shuttle Gear: 12x12 synchronized shuttle; HST: 3-range hydrostatic, dual pedal No. of Speeds CK3520: 9F/3R; CK3520H, CK3520SEH, CK3520SEH CAB: Infinite, 3 range; CK3520SE: 12F/12R Gear: 12F/12R; HST: Infinite (3 ranges) Max Travel Speed (Forward) CK3520: 14.64 mph; CK3520H, CK3520SEH, CK3520SEH CAB: 14.88 mph; CK3520SE: 15.53 mph Gear: 14.2 mph; HST: 14.8 mph Max Travel Speed (Reverse) CK3520: 9.56 mph; CK3520H, CK3520SEH, CK3520SEH CAB: 10.41 mph; CK3520SE: 15.14 mph Gear: 13.63 mph; HST: 14.96 mph Clutch CK3520: dry, dual-stage; CK3520H, CK3520SE: dry, single-stage; CK3520SEH, CK3520SEH CAB: n/a (hydrostatic) Gear: 9.4 in single dry disc; HST: Not applicable Differential Lock & Limited Slip Options Rear differential lock (standard) Mechanical rear differential lock ▶ Chassis, Steering & ControlsFrame Type Not Published Not Published Steering Hydrostatic power steering Power steering Brakes Wet multi-disc Wet, multi-disc Seat Suspension & Adjustability Not Published Mechanical suspension seat, fore/aft adjustable, tilting Front Axle Type 4WD, manual engagement 4WD Front Axle Rating Not Published Not Published Drawbar Capacity 1,433 lb Not Published ▶ Dimensions & ManeuverabilityOverall Width 54.5 in 66.5 in Wheelbase 65.7 in 67.5 in Ground Clearance 13.4 in 13 in Min. Turn Radius without Brakes 107.5 in 123 in (left turn); 124 in (right turn) Height to Top of ROPS 92.9 in 87.7 in Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model n/a (ROPS model) Not Published Overall Length 120.87 in (with 3-point hitch) 121 in ▶ WeightTractor Weight (Base) CK3520: 2,679 lb; CK3520H: 2,734 lb; CK3520SE: 2,906 lb; CK3520SEH: 2,921 lb; CK3520SEH CAB: 3,397 lb 3,067 lb Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options Front AG 7-16 (Turf 28x8.5-15/6, Industrial 27x8.5-15); Rear AG 11.2-24 (Turf 41x14-20/4, Industrial 15-19.5) R1 Agricultural, R3 Turf, R4 Industrial R1 Agricultural - Front 7-16 7-14 R1 Agricultural - Rear 11.2-24 11.2-24 R3 Turf - Front 28x8.5-15/6 25x8.50-14 R3 Turf - Rear 41x14-20/4 41x14.00-20 R4 Industrial - Front 27x8.5-15 25x8.50-14 R4 Industrial - Rear 15-19.5 43x16-20 ▶ Loader & AttachmentsQuick Attach Loader System Not Published 140TL: tool-free quick-mount system; optional skid-steer quick-attach plates Loader Model KL4030; KL4030C 140TL Loader Lift Height 98.4 in (KL4030 and KL4030C loaders) 140TL: 91.5 in (at pivot pin) Loader Lift Capacity (Full Height) KL4030: 1,835 lb; KL4030C: 1,969 lb 140TL: 1,500 lb (at bucket pivot pin, max height) Loader Breakout Force KL4030: 3,464 lb; KL4030C: 2,989 lb 140TL: 2,700 lb (at bucket pivot pin) ▶ WarrantyWarranty Length & Coverage Non-commercial: basic 24 months, powertrain 72 months, unlimited hours, parts and labor Basic 2 years or 750 hours; powertrain to 6 years or 1,500 hours total ▶ ITC Company AccessoriesAccessories that fit None tagged yet
