▶ EngineEngine Manufacturer KIOTI Mahindra Engine Model CK4020, CK4020H: 3H-TM4A; CK4020SE, CK4020SEH, CK4020SEH CAB: 3H-TM4B Not Published Engine Type 3-cylinder, in-line, liquid-cooled diesel Naturally aspirated direct injection diesel No. of Cylinders 3 4 Displacement 111.4 in³ 166.7 in³ Rated Engine Speed 2600 rpm 2600 rpm Engine Power (Gross) 39.6 hp 39.4 hp PTO Power CK4020, CK4020SE: 34.8 hp; CK4020H, CK4020SEH, CK4020SEH CAB: 33.3 hp 35 hp Engine Emissions Constraints Not Published Tier 4 Cooling System Type Liquid-cooled Liquid-cooled Air Cleaner Dry element Not Published Fuel System Not Published Direct injection Alternator Not Published 45 A, 12 V ▶ HydraulicsPump Type Gear Not Published Implement Flow CK4020, CK4020H: 7.14 gpm; CK4020SE, CK4020SEH, CK4020SEH CAB: 6.86 gpm 8.2 gpm Steering Flow CK4020, CK4020H: 4.59 gpm; CK4020SE, CK4020SEH, CK4020SEH CAB: 4.46 gpm 4.5 gpm Total Hydraulic Flow CK4020, CK4020H: 11.73 gpm; CK4020SE, CK4020SEH, CK4020SEH CAB: 11.33 gpm 12.7 gpm (8.2 + 4.5, computed) Overall Hydraulic Pump Flow CK4020, CK4020H: 11.73 gpm; CK4020SE, CK4020SEH, CK4020SEH CAB: 11.33 gpm Not Published Hydraulic System Type Open center Open center Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves CK4020, CK4020H: None; CK4020SE, CK4020SEH, CK4020SEH CAB: 2 Not Published No. of Optional Remote Valves CK4020, CK4020H: 2 Not Published ▶ Fluid CapacityFuel Tank Capacity 9.0 gal 9.0 gal Coolant Capacity 0.89 gal Not Published Crankcase Capacity 1.6 gal Not Published Transmission / Hydraulic System Capacity 5.8 gal Not Published Front Axle Fluid Capacity 1.6 gal Not Published ▶ PTO & HitchPTO Type CK4020, CK4020H: Live; CK4020SE, CK4020SEH, CK4020SEH CAB: Independent Independent PTO Rear 540 rpm (1-3/8 in, 6 splines) 540 rpm @ 2650 rpm Mid-PTO Availability Optional, 2,000 rpm Not Published Category, 3-Point Hitch Category I CAT I with check chains Hitch Lift Capacity 2,270 lb 2,646 lb Hitch Lift Capacity (at 24”) 1,631 lb Not Published Lift Control Type Position control Position control ▶ Transmission & DrivetrainTransmission Type CK4020: Manual; CK4020H, CK4020SEH, CK4020SEH CAB: Hydrostatic; CK4020SE: Synchro shuttle Synchro shuttle with partial synchromesh No. of Speeds CK4020: 9F/3R; CK4020H, CK4020SEH, CK4020SEH CAB: Infinite, 3 range; CK4020SE: 12F/12R 12F/12R Max Travel Speed (Forward) CK4020: 14.64 mph; CK4020H, CK4020SEH, CK4020SEH CAB: 14.88 mph; CK4020SE: 15.53 mph Not Published Max Travel Speed (Reverse) CK4020: 9.56 mph; CK4020H, CK4020SEH, CK4020SEH CAB: 10.41 mph; CK4020SE: 15.14 mph Not Published Clutch CK4020: dry, dual-stage; CK4020H, CK4020SE: dry, single-stage; CK4020SEH, CK4020SEH CAB: n/a (hydrostatic) Single plate, dry Differential Lock & Limited Slip Options Rear differential lock (standard) Not Published ▶ Chassis, Steering & ControlsFrame Type Not Published Not Published Steering Hydrostatic power steering Hydrostatic power steering, tilt Brakes Wet multi-disc Wet disc Seat Suspension & Adjustability Not Published Adjustable suspension seat Front Axle Type 4WD, manual engagement Not Published Front Axle Rating Not Published Not Published Drawbar Capacity 1,433 lb Not Published ▶ Dimensions & ManeuverabilityOverall Width 54.5 in 59.8 in Wheelbase 65.7 in Not Published Ground Clearance 13.4 in Not Published Min. Turn Radius without Brakes 107.5 in 7.87 ft Height to Top of ROPS 92.9 in 94.4 in Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model CK4020SEH CAB: 92.5 in; other variants: n/a (ROPS) Not Published Overall Length 120.87 in (with 3-point hitch) 119.3 in ▶ WeightTractor Weight (Base) CK4020: 2,679 lb; CK4020H: 2,734 lb; CK4020SE: 2,906 lb; CK4020SEH: 2,921 lb; CK4020SEH CAB: 3,397 lb 3,285 lb (operating weight) Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options Front AG 7-16 (Turf 28x8.5-15/6, Industrial 27x8.5-15); Rear AG 11.2-24 (Turf 41x14-20/4, Industrial 15-19.5) Ag, Industrial (turf N/A) R1 Agricultural - Front 7-16 8.3x16 R1 Agricultural - Rear 11.2-24 12.4x24 R3 Turf - Front 28x8.5-15/6 Not Published R3 Turf - Rear 41x14-20/4 Not Published R4 Industrial - Front 27x8.5-15 10-16.5 R4 Industrial - Rear 15-19.5 43x16-20 ▶ Loader & AttachmentsQuick Attach Loader System Not Published Not Published Loader Model KL4030; KL4030C 2540L Loader Lift Height 98.4 in (KL4030 and KL4030C loaders) 2540L: 101.9 in Loader Lift Capacity (Full Height) KL4030: 1,835 lb; KL4030C: 1,969 lb 2540L: 2,041 lb (at pivot pin) Loader Breakout Force KL4030: 3,464 lb; KL4030C: 2,989 lb 2540L: 3,430 lb (at pivot pin) ▶ WarrantyWarranty Length & Coverage Non-commercial: basic 24 months, powertrain 72 months, unlimited hours, parts and labor 5-year powertrain warranty ▶ ITC Company AccessoriesAccessories that fit None tagged yet
