▶ EngineEngine Manufacturer KIOTI (Daedong) Yanmar Engine Model 3C100LWH-U3 3TNV76F Engine Type In-Line Vertical, Water-Cooled 4-Cycle Diesel (3-cylinder) 3-cylinder, indirect injection (swirl chamber), water-cooled No. of Cylinders 3 3 Displacement 61.5 in³ 68.0 in³ Rated Engine Speed 3200 rpm 3000 rpm Engine Power (Gross) 21 hp 21.5 hp PTO Power 16.3 hp 15 hp Engine Emissions Constraints U.S. EPA non-road emission regulation Tier 4 Cooling System Type Water-cooled Water-cooled Air Cleaner Not Published Dry Fuel System Injection pump In-line injection pump Alternator 50 A, 12 V 40 A, 12 V ▶ HydraulicsPump Type Gear Gear pump, transmission driven Implement Flow 7.0 gpm 4.6 gpm Steering Flow Not Published 2.1 gpm Total Hydraulic Flow 7.0 gpm 6.7 gpm Overall Hydraulic Pump Flow 7.0 gpm 6.7 gpm Hydraulic System Type Open center Open center system, position control Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves 1 0 No. of Optional Remote Valves Not Published 1 pair (2 quick couplers) ▶ Fluid CapacityFuel Tank Capacity 6.7 gal 6.6 gal Coolant Capacity 0.87 gal 0.9 gal Crankcase Capacity 1.0 gal 0.8 gal Transmission / Hydraulic System Capacity 2.75 gal 3.0 gal (3.4 gal with front-end loader; 4.7 gal with front-end loader and backhoe) Front Axle Fluid Capacity 0.53 gal 0.5 gal ▶ PTO & HitchPTO Type Independent Independent (electro-hydraulic) PTO Rear 540 rpm Standard (540 rpm) Mid-PTO Availability Available (2,200 rpm) Standard (2,500 rpm) Category, 3-Point Hitch Category I Category I Hitch Lift Capacity 1,580 lb 970 lb Hitch Lift Capacity (at 24”) 700 lb 728 lb Lift Control Type Position Position control ▶ Transmission & DrivetrainTransmission Type Hydrostatic (HST) Hydrostatic Drive No. of Speeds Infinite, 2 range (High/Low) 2 ranges Max Travel Speed (Forward) 9.6 mph 8.70 mph Max Travel Speed (Reverse) 6.6 mph 5.22 mph Clutch None (hydrostatic transmission) Not Published Differential Lock & Limited Slip Options Rear differential lock (standard) Mechanical pedal type ▶ Chassis, Steering & ControlsFrame Type Not Published Not Published Steering Hydrostatic power steering Hydrostatic power steering Brakes Wet multi disc Wet, multi-disc Seat Suspension & Adjustability Not Published High-Back Seat with Foldable Armrest and Retractable Seatbelt; fore/aft adjustable Front Axle Type Mechanical 4WD Front wheel mechanical assist (4WD) Front Axle Rating Not Published Not Published Drawbar Capacity Not Published Hitch: 882 lb vertical, 3,527 lb horizontal; drawbar with clevis: 772 lb vertical, 3,527 lb horizontal ▶ Dimensions & ManeuverabilityOverall Length with 3-Point Hitch 99.3 in 97 in Overall Width 45.9 in 47 in Wheelbase 55.1 in 56 in Ground Clearance 6.4 in Not Published Min. Turn Radius without Brakes 8.2 ft (with brake applied) 7.87 ft Height to Top of ROPS 87.6 in 87 in Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model Not Published Not Published ▶ WeightTractor Weight (Base) 1,554 lb 1,433 lb Weight with ROPS and Loader 2,127 lb Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options R1 Agricultural, R3 Turf and R4 Industrial: 18x8.5-10 front, 26x12.00-12 rear Front 18x8.50-10, rear 26x12.0-12; offered in industrial or turf R1 Agricultural - Front 18x8.5-10 Not Published R1 Agricultural - Rear 26x12.00-12 Not Published R3 Turf - Front 18x8.5-10 18x8.50-10 R3 Turf - Rear 26x12.00-12 26x12.0-12 R4 Industrial - Front 18x8.5-10 18x8.50-10 R4 Industrial - Rear 26x12.00-12 26x12.0-12 ▶ Loader & AttachmentsQuick Attach Loader System Quick attach (QA) bucket, 48 in LL1101: Pin-Type Bucket (standard); Quick Attach Assembly (Optional) - Compact Type (dual-lever LH/RH); LL1700: Quick Attach Implement System Loader Model SL2420 LL1101; LL1100 Loader Lift Height SL2420: 73.7 in LL1101: 72.0 in; LL1100: 72.0 in (at pivot pin) Loader Lift Capacity (Full Height) SL2420: 1,062.3 lb LL1101: 966 lb; LL1100: 1,005 lb (at pivot pin, maximum height) Loader Breakout Force SL2420: 1,329.0 lb LL1101: 1,960 lb; LL1100: 2,083 lb (at pivot pin) ▶ WarrantyWarranty Length & Coverage Tractors (Non-Commercial Application): 24 months, unlimited hours, parts & labor; Non-commercial powertrain (engine and driveline) on qualifying tractors: 72 months, unlimited hours, parts & labor 6-year limited warranty ▶ ITC Company AccessoriesAccessories that fit None tagged yet
