▶ EngineEngine Manufacturer KIOTI YANMAR Engine Model 3C100LWH-U3 3TNM74F Engine Type In-Line Vertical, Water-Cooled Diesel (3-cylinder) 4-cycle inline, water-cooled diesel, naturally aspirated No. of Cylinders 3 3 Displacement 61.5 in³ 60.6 in³ Rated Engine Speed 3200 rpm 3200 rpm Engine Power (Gross) 21 hp 21.5 hp PTO Power 16.3 hp 15.6 hp Engine Emissions Constraints U.S. EPA non-road emission regulation Tier 4 Cooling System Type Water-cooled Liquid cooled Air Cleaner Not Published Not Published Fuel System Not Published Not Published Alternator Not Published 40 A ▶ HydraulicsPump Type Gear Dual hydraulic pump Implement Flow 7.0 gpm 4.3 gpm Steering Flow Not Published 3.7 gpm Total Hydraulic Flow 7.0 gpm 8.0 gpm (4.3 + 3.7, computed) Overall Hydraulic Pump Flow 7.0 gpm 8.0 gpm (4.3 + 3.7, computed) Hydraulic System Type Open center Open center Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves Not Published Not Published No. of Optional Remote Valves Not Published Not Published ▶ Fluid CapacityFuel Tank Capacity 6.7 gal 6.1 gal Coolant Capacity 0.87 gal 3.0 qt Crankcase Capacity 1.0 gal 3.1 qt Transmission / Hydraulic System Capacity 2.75 gal 4.1 gal Front Axle Fluid Capacity 0.53 gal 3.2 qt ▶ PTO & HitchPTO Type Independent Independent PTO Rear 540 rpm 554 rpm @ 3200 engine rpm Mid-PTO Availability Available (2,200 rpm) Independent mid-PTO, 2057 rpm at 3200 engine rpm Category, 3-Point Hitch Category I Limited Category I Hitch Lift Capacity 1,580 lb Not Published Hitch Lift Capacity (at 24”) 700 lb 660 lb Lift Control Type Position Select control ▶ Transmission & DrivetrainTransmission Type Hydrostatic (HST) Hydrostatic transmission No. of Speeds Infinite, 2 range (High/Low) Infinite forward and reverse (hydrostatic); 1 range Max Travel Speed (Forward) 9.6 mph 8.6 mph (with R4 tires) Max Travel Speed (Reverse) 6.6 mph 6.3 mph (with R4 tires) Clutch None (hydrostatic transmission) Not Published Differential Lock & Limited Slip Options Rear differential lock (standard) Differential lock pedal (optional) ▶ Chassis, Steering & ControlsFrame Type Not Published Full-frame chassis Steering Hydrostatic power steering Hydrostatic power steering Brakes Wet multi disc Wet disc Seat Suspension & Adjustability Not Published Fore-and-aft adjustable operator seat Front Axle Type Mechanical 4WD Selectable 2WD/4WD Front Axle Rating Not Published Not Published Drawbar Capacity Not Published Not Published ▶ Dimensions & ManeuverabilityOverall Width 45.9 in 47.3 in (with R4 tires) Wheelbase 55.1 in 57.9 in Ground Clearance 6.4 in 6.4 in (with R4 tires) Min. Turn Radius without Brakes 8.2 ft (with brake applied) 7.87 ft Height to Top of ROPS 87.6 in 82.3 in (with R4 tires) Height to Top of ROPS (folded) Not Published 66.3 in (folded ROPS, top of steering wheel, R4 tires) Height to Top of Cab Model Not Published Not Published Overall Length 99.3 in (with 3-point hitch) 102.1 in (with 3-point hitch) ▶ WeightTractor Weight (Base) 1,554 lb (with AG. tires) 1,537 lb (with ROPS, R4 tires) Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options Agricultural, Turf and Industrial: 18x8.5-10 front, 26x12.00-12 rear R3 Turf; R4 Industrial R1 Agricultural - Front 18x8.5-10 Not Published R1 Agricultural - Rear 26x12.00-12 Not Published R3 Turf - Front 18x8.5-10 18x8.50-10 4PR R3 Turf - Rear 26x12.00-12 26x12.0-12 4PR R4 Industrial - Front 18x8.5-10 18x8.50-10 6PR R4 Industrial - Rear 26x12.00-12 26x12.0-12 4PR ▶ Loader & AttachmentsQuick Attach Loader System Quick attach (QA) bucket, 48 in YL110: YANMAR quick attachment system Loader Model SL2420 YL110 Loader Lift Height SL2420: 73.7 in (at pivot pin) YL110: 71 in to pivot pin (51 in under level bucket) Loader Lift Capacity (Full Height) SL2420: 1,062 lb YL110: 825 lb at pivot pin Loader Breakout Force SL2420: 1,329 lb (at pivot pin) YL110: 1,342 lb at pivot pin ▶ WarrantyWarranty Length & Coverage Non-commercial: basic 24 months, powertrain 72 months on qualifying tractors, unlimited hours, parts and labor Private individual use: basic 24 months or 2,000 hours, powertrain 10 years or 3,000 hours; attachments 1 year ▶ ITC Company AccessoriesAccessories that fit None tagged yet
