▶ EngineEngine Manufacturer Daedong TYM Engine Model CS2530H: 3L123-TH4C; CS2530CH: 3L123-TH4A A1700N6-BUTR_3 Engine Type 3-cylinder, liquid-cooled inline diesel Vertical, 4-stroke, water-cooled diesel No. of Cylinders 3 3 Displacement 75.2 in³ 104.7 in³ Rated Engine Speed 3000 rpm 2100 rpm Engine Power (Gross) 24.5 hp 24.5 hp PTO Power 19.3 hp 19.1 hp Engine Emissions Constraints Not Published Not Published Cooling System Type Liquid-cooled Water-cooled Air Cleaner Not Published Dry Fuel System Indirect injection Not Published Alternator Not Published 50 A, 12 V ▶ HydraulicsPump Type Not Published Gear type (primary 0.8 in³/rev, secondary 0.4 in³/rev) Implement Flow 4.9 gpm 7.5 gpm Steering Flow 2.0 gpm 4 gpm Total Hydraulic Flow 6.97 gpm 11.5 gpm Overall Hydraulic Pump Flow 6.97 gpm 11.5 gpm Hydraulic System Type Open center Open center Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves Not Published Not Published No. of Optional Remote Valves Not Published 2 ▶ Fluid CapacityFuel Tank Capacity 6.7 gal 7.13 gal Coolant Capacity 0.53 gal 1.32 gal Crankcase Capacity 0.98 gal 1.14 gal Transmission / Hydraulic System Capacity 2.75 gal Manual: 8.98 gal; HST: 9.77 gal Front Axle Fluid Capacity 0.53 gal Not Published ▶ PTO & HitchPTO Type Independent Independent PTO Rear 540 rpm 533 rpm Mid-PTO Availability Available (2,200 rpm) Not Published Category, 3-Point Hitch Category I Category I Hitch Lift Capacity 1,580 lb 3,306.9 lb Hitch Lift Capacity (at 24”) 700 lb 2,425 lb Lift Control Type Position Position control ▶ Transmission & DrivetrainTransmission Type Hydrostatic (HST) Hydrostatic (HST) No. of Speeds Infinite, 2 range (High/Low) 3 range (A/B/C) Max Travel Speed (Forward) 8.99 mph Not Published Max Travel Speed (Reverse) 6.15 mph Not Published Clutch None (hydrostatic transmission) None (HST) Differential Lock & Limited Slip Options Rear differential lock (standard) Mechanical rear differential lock ▶ Chassis, Steering & ControlsFrame Type Not Published Heavy-duty steel frame with cast iron axles Steering Power steering Fully hydraulic power steering Brakes Wet disc Wet multi-disc Seat Suspension & Adjustability Not Published Not Published Front Axle Type Mechanical 4WD Selectable 4WD Front Axle Rating Not Published Not Published Drawbar Capacity Not Published Not Published ▶ Dimensions & ManeuverabilityOverall Length with 3-Point Hitch 102.9 in 134.88 in Overall Width 48.8 in 56.7 in Wheelbase 55.1 in 65.7 in Ground Clearance 6.4 in 15 in Min. Turn Radius without Brakes 8.33 ft Not Published Height to Top of ROPS 87.6 in 96.85 in Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model 83 in Not Published ▶ WeightTractor Weight (Base) CS2530H: 1,735 lb; CS2530CH: 2,403 lb 2,969.6 lb Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options R4 Industrial: 18x8.5-10 front, 26x12.00-12 rear; R3 Turf: 18x8.5-10 front, 26x12.00-12 rear R1 Agricultural (8.0-16 / 12.4-24 standard), R4 Industrial (25x8.50-14 / 15-19.5) R1 Agricultural - Front 18x8.5-10 8.0-16 R1 Agricultural - Rear Not Published 12.4-24 R3 Turf - Front 18x8.5-10 Not Published R3 Turf - Rear 26x12.00-12 Not Published R4 Industrial - Front 18x8.5-10 25x8.50-14 R4 Industrial - Rear 26x12.00-12 15-19.5 ▶ Loader & AttachmentsQuick Attach Loader System Quick attach bucket, 48 in Quick attach front loader Loader Model SL2530 BBL400 Loader Lift Height SL2530: 70.9 in 104 in Loader Lift Capacity (Full Height) SL2530: 871 lb 2,200 lb Loader Breakout Force SL2530: 1,299 lb 3,660 lbf ▶ WarrantyWarranty Length & Coverage Non-commercial: 24 months, unlimited hours, parts and labor, 0% deductible; non-commercial powertrain (engine and driveline): 72 months, unlimited hours Engine and powertrain: 72 months or 2,000 hours; other tractor parts: 24 months or 1,000 hours; loader and backhoe: 24 months from shipment, 12 months from sale, or 500 hours ▶ ITC Company AccessoriesAccessories that fit None tagged yet
