▶ EngineEngine Manufacturer KIOTI Iseki Engine Model CS2530H: 3L123-TH4C; CS2530CH: 3L123-TH4A E3112 Engine Type 3-cylinder, water-cooled diesel 3-cylinder, liquid-cooled diesel No. of Cylinders 3 3 Displacement 75.2 in³ 68.5 in³ Rated Engine Speed 3000 rpm 3000 rpm Engine Power (Gross) 24.5 hp 24.5 hp PTO Power 19.3 hp 19.6 hp Engine Emissions Constraints Not Published Tier 4 Cooling System Type Water-cooled Liquid-cooled Air Cleaner Not Published Dry Fuel System Indirect injection Indirect injection Alternator Not Published 40 A ▶ HydraulicsPump Type Not Published Not Published Implement Flow 4.9 gpm 4.9 gpm Steering Flow 2.03 gpm 2.0 gpm Total Hydraulic Flow 6.97 gpm 6.8 gpm Overall Hydraulic Pump Flow 6.97 gpm Not Published Hydraulic System Type Open center Open center Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves Not Published Not Published No. of Optional Remote Valves Not Published Not Published ▶ Fluid CapacityFuel Tank Capacity 6.6 gal 6.6 gal Coolant Capacity 0.53 gal 1.23 gal Crankcase Capacity 0.98 gal 0.68 gal Transmission / Hydraulic System Capacity 2.75 gal 2.9 gal Front Axle Fluid Capacity 0.53 gal 1.05 gal ▶ PTO & HitchPTO Type Independent Independent PTO Rear 540 rpm 540 rpm (1.375 in, six spline) Mid-PTO Availability Available (2,200 rpm) Independent, 2000 rpm (1 in, fifteen spline) Category, 3-Point Hitch Category I Category I Hitch Lift Capacity 1,580 lb 1,191 lb Hitch Lift Capacity (at 24”) 700 lb 661 lb Lift Control Type Position Not Published ▶ Transmission & DrivetrainTransmission Type Hydrostatic (HST) 2-range hydrostatic with side-by-side foot pedals and cruise control No. of Speeds Infinite, 2 range (High/Low) Infinite forward and reverse (2-range hydrostatic) Max Travel Speed (Forward) 8.99 mph Not Published Max Travel Speed (Reverse) 6.15 mph Not Published Clutch None (hydrostatic transmission) Not Published Differential Lock & Limited Slip Options Rear differential lock (standard) Locking rear differential (4WD) ▶ Chassis, Steering & ControlsFrame Type Not Published Not Published Steering Power steering Power steering Brakes Wet disc Wet disc Seat Suspension & Adjustability Not Published Not Published Front Axle Type Mechanical 4WD 4WD front axle Front Axle Rating Not Published Not Published Drawbar Capacity Not Published Not Published ▶ Dimensions & ManeuverabilityOverall Width CS2530H: 48.8 in; CS2530CH: 50.0 in 46.7 in (minimum width, with R1 tires) Wheelbase 55.1 in 57.1 in Ground Clearance 6.4 in 6.7 in Min. Turn Radius without Brakes 100.0 in (with brake applied) Not Published Height to Top of ROPS 87.6 in 72.8 in Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model 82.6 in Not Published Overall Length CS2530H: 102.9 in; CS2530HC: 107.1 in (without front weight, with 3-point hitch) 97.6 in ▶ WeightTractor Weight (Base) CS2530H: 1,735 lb; CS2530CH: 2,403 lb 1,532 lb Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options R4 Industrial: 18x8.5-10 front, 26x12.00-12 rear; R3 Turf: 18x8.5-10 front, 26x12.00-12 rear AG, Turf or R4 Industrial: front 18x8.50-10, rear 26x12.00-12 R1 Agricultural - Front 18x8.5-10 18x8.50-10 R1 Agricultural - Rear Not Published 26x12.00-12 R3 Turf - Front 18x8.5-10 18x8.50-10 R3 Turf - Rear 26x12.00-12 26x12.00-12 R4 Industrial - Front 18x8.5-10 18x8.50-10 R4 Industrial - Rear 26x12.00-12 26x12.00-12 ▶ Loader & AttachmentsQuick Attach Loader System Quick attach bucket, 48 in Skid steer quick attach Loader Model SL2530 FL1805 Loader Lift Height SL2530: 70.9 in (at pivot pin) 74 in Loader Lift Capacity (Full Height) SL2530: 871 lb 922 lb Loader Breakout Force SL2530: 1,299 lb (at pivot pin) 1,392 lb ▶ WarrantyWarranty Length & Coverage Non-commercial: basic 24 months, unlimited hours, parts and labor, 0% deductible; powertrain 6 years, unlimited hours Five-year powertrain warranty
