▶ EngineEngine Manufacturer KIOTI (Daedong) Yanmar Engine Model 3A165LXE 3TNV88C-KJPT Engine Type Not Published 4-cycle, inline, water-cooled diesel, naturally aspirated No. of Cylinders 3 3 Displacement 100.5 in³ 100.2 in³ Rated Engine Speed 2600 rpm 2800 rpm Engine Power (Gross) 34 hp 34.2 hp PTO Power 28.3 hp 30.4 hp Engine Emissions Constraints Not Published Tier 4 Cooling System Type Not Published Liquid Air Cleaner Dual stage air filter cartridge Dry Fuel System Not Published Direct injection Alternator Not Published 55 A, 12 V ▶ HydraulicsPump Type Not Published 2 single-section external gear pumps, 1 on each side of the engine timing-gear cover Implement Flow 7.8 gpm 5.9 gpm Steering Flow 4.7 gpm 4.4 gpm Total Hydraulic Flow 12.5 gpm 10.3 gpm Overall Hydraulic Pump Flow 12.5 gpm 10.3 gpm Hydraulic System Type Not Published Open center Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves 1 None No. of Optional Remote Valves 1 Up to two (optional) ▶ Fluid CapacityFuel Tank Capacity 11.5 gal 9.7 gal Coolant Capacity Not Published 1.2 gal Crankcase Capacity Not Published 1.1 gal Transmission / Hydraulic System Capacity Not Published 9.2 gal Front Axle Fluid Capacity Not Published 1.0 gal ▶ PTO & HitchPTO Type Hydraulic independent Mechanical control; transmission clutch; wet disk brake (mid/rear PTO) PTO Rear 540 rpm 540 rpm at 2800 rpm engine (rated) Mid-PTO Availability Optional (2,000 rpm) Not Published Category, 3-Point Hitch Category I Category I Hitch Lift Capacity 2,270 lb Not Published Hitch Lift Capacity (at 24”) Not Published 1,670 lb Lift Control Type Position, Draft and Mixed control Position control ▶ Transmission & DrivetrainTransmission Type Synchronized shuttle 8F/8R synchromesh shuttle shift gear transmission No. of Speeds 8F/8R (16F/16R with optional creeper gear) 8F/8R Max Travel Speed (Forward) 13.93 mph Not Published Max Travel Speed (Reverse) Not Published Not Published Clutch Dry single plate Single dry traction clutch Differential Lock & Limited Slip Options Rear differential lock (mechanical) Differential lock: Yes ▶ Chassis, Steering & ControlsFrame Type Not Published Not Published Steering Hydraulic power steering Power steering Brakes Wet disc Wet disk Seat Suspension & Adjustability Adjustable seat Not Published Front Axle Type 4WD (MFWD) MFWD (4WD) Front Axle Rating Not Published 1,940 lb Drawbar Capacity Not Published 1,102 lb (static vertical load) ▶ Dimensions & ManeuverabilityOverall Width 57.1 in 57.3 in Wheelbase 65.7 in 62 in Ground Clearance 11.4 in 14 in Min. Turn Radius without Brakes 125.9 in 6.9 ft (with brake applied) Height to Top of ROPS 92.5 in Not Published Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model Not Published Not Published Overall Length 126.3 in (with 3-point hitch) 111.2 in ▶ WeightTractor Weight (Base) 3,475 lb (with ag tires) 2,800 lb Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options R1 Agricultural, R3 Turf, R4 Industrial R1 Bar, R3 Turf, R4 Industrial R1 Agricultural - Front 7-16 7-14 R1 Agricultural - Rear 12.4-24 11.2-24 R3 Turf - Front 27x8.5-15 27X8.5-15 R3 Turf - Rear 41x14-20 41X14-20 R4 Industrial - Front 27x10.5-15 25X8.5-14 R4 Industrial - Rear 43x16-20 15-19.5 ▶ Loader & AttachmentsQuick Attach Loader System Not Published Quick-change attachment carrier Loader Model KL1450 300E Loader Lift Height KL1450: 103.5 in 84 in (at pivot pin) Loader Lift Capacity (Full Height) KL1450: 1,350 lb (at pivot pin) 1,186 lb (at pivot pin) Loader Breakout Force KL1450: 2,100 lb (at pivot pin) 1,704 lbf (at pivot pin) ▶ WarrantyWarranty Length & Coverage Not Published Basic 2 years or 2,000 hours; powertrain 6 years or 2,000 hours ▶ ITC Company AccessoriesAccessories that fit None tagged yet
