▶ EnginePTO Power 28.3 hp 28 hp Alternator 50 A, 12 V 70 A, 12 V Air Cleaner Not Published Dry Engine Type 4-cycle, liquid-cooled, diesel 4-stroke, vertical, water cooling, CRDI Fuel System Not Published Delphi, CRDI Displacement 100.5 in³ 114.7 in³ No. of Cylinders 3 3 Rated Engine Speed 2700 rpm 2600 rpm Cooling System Type Liquid-cooled Water-cooled Engine Manufacturer KIOTI (Daedong) LS Mtron Engine Power (Gross) 35 hp 35 hp Engine Emissions Constraints Not Published Tier 4 ▶ WeightWeight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Applicable ▶ WarrantyWarranty Length & Coverage Limited: Tractors (Non-Commercial Application) 24 months parts & labor; Extended (driveline): 48 months parts & labor 6-year limited powertrain warranty; 2-year bumper-to-bumper warranty ▶ HydraulicsPump Type Not Published Gear pump, engine drive Steering Flow 4.7 gpm 5.5 gpm Implement Flow 7.8 gpm 7.8 gpm Total Hydraulic Flow 12.5 gpm 13.3 gpm Hydraulic System Type Not Published Open center Rear Remote Hydraulic Flow Not Published Not Published Overall Hydraulic Pump Flow 12.5 gpm 13.3 gpm No. of Optional Remote Valves 1 Not Published No. of Standard Remote Valves 0 2 Pair ▶ PTO & HitchPTO Rear 540 rpm 540 rpm PTO Type Independent Independent PTO with wet disk clutch Lift Control Type Position and draft control Position & Draft Hitch Lift Capacity 2,270 lb (listed as “at ends”) 1,808 lbs Mid-PTO Availability Optional (2000 rpm) Option (2,000 rpm) Category, 3-Point Hitch Category I Category I Hitch Lift Capacity (at 24”) 2,425 lb 1,433 lbs ▶ Tire OptionsR3 Turf - Rear 41X14-20 41X14-20 R3 Turf - Front 27X8.50-15 25X8.5-14 Tire Size & Options R1 Agricultural, R3 Turf, R4 Industrial R1 Agricultural, R3 Turf, R4 Industrial R4 Industrial - Rear 14.9X24 43X16-20 R4 Industrial - Front 10X16.5 25X8.5-14 R1 Agricultural - Rear 12.4-24 11.2-24 R1 Agricultural - Front 7-16 7.0-14 ▶ Fluid CapacityCoolant Capacity Not Published 1.9 gal Crankcase Capacity Not Published 1.5 gal Fuel Tank Capacity 11.5 gal 10.6 gal Front Axle Fluid Capacity 10 qt 1.7 gal Transmission / Hydraulic System Capacity 7.8 gal 7.9 gal ▶ Loader & AttachmentsLoader Lift Height Not Published 94.4 in Loader Breakout Force Not Published 3,612 lbs Quick Attach Loader System Not Published LL3116: Standard Skid Steer Coupler (skid-steer compatible quick-attach) Loader Lift Capacity (Full Height) Not Published 2,185 lbs ▶ Transmission & DrivetrainClutch Not Published Not Applicable No. of Speeds 8F/8R 2 Pedal with 3 Range - HST Transmission Type Synchronized shuttle Hydrostatic Drive Max Travel Speed (Forward) Not Published Not Published Max Travel Speed (Reverse) Not Published Not Published Differential Lock & Limited Slip Options Not Published Mechanical differential lock (pedal) ▶ Chassis, Steering & ControlsBrakes Wet disc Wet, Multi-disc Steering Hydrostatic power steering Hydrostatic Power Steering Frame Type 4x4 MFWD 4WD Not Published Front Axle Type 4WD (MFWD) Not Published Drawbar Capacity Not Published Not Published Front Axle Rating Not Published Not Published Seat Suspension & Adjustability Not Published Not Published ▶ Dimensions & ManeuverabilityWheelbase 65.7 in 69.1 in Overall Width 57.1 in 59.3 in Ground Clearance 11.4 in Not Published Height to Top of ROPS 92.5 in 94.0 in Height to Top of Cab Model Not Published Not Applicable Height to Top of ROPS (folded) Not Published Not Published Min. Turn Radius without Brakes Not Published Not Published Overall Length with 3-Point Hitch 126.3 in 136.1 in ▶ ITC Company AccessoriesAccessories that fit None tagged yet
