▶ EngineEngine Manufacturer KIOTI (Daedong) KIOTI (Daedong) Engine Model 3H-TH4D 3A165D Engine Type 3-cylinder, liquid-cooled diesel Indirect injection, vertical, water-cooled, 4-cycle diesel No. of Cylinders 3 3 Displacement 111.4 in³ 100.5 in³ Rated Engine Speed 2600 rpm 2600 rpm Engine Power (Gross) 39.6 hp 35 hp PTO Power 29.1 hp 28.3 hp Engine Emissions Constraints Tier 4 Not Published Cooling System Type Liquid-cooled Liquid-cooled Air Cleaner Dry element Dual stage air filter cartridge Fuel System Not Published Indirect injection Alternator Not Published 50 A, 12 V ▶ HydraulicsPump Type Gear Not Published Implement Flow 9.62 gpm 7.6 gpm Steering Flow 6.87 gpm 4.7 gpm Total Hydraulic Flow 16.5 gpm 12.5 gpm Overall Hydraulic Pump Flow 16.5 gpm 12.5 gpm Hydraulic System Type Not Published Not Published Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves 2 1 No. of Optional Remote Valves Not Published 1 ▶ Fluid CapacityFuel Tank Capacity 12.7 gal 11.5 gal Coolant Capacity 2.1 gal 1.9 gal Crankcase Capacity 1.95 gal 1.5 gal Transmission / Hydraulic System Capacity 11.4 gal 11.6 gal Front Axle Fluid Capacity 1.48 gal 2.0 gal ▶ PTO & HitchPTO Type Independent Independent PTO Rear 540 rpm 540 rpm Mid-PTO Availability Optional (2,000 rpm) Optional (2,000 rpm) Category, 3-Point Hitch Category I Category I Hitch Lift Capacity 2,998 lb 2,270 lb Hitch Lift Capacity (at 24”) 2,716 lb Not Published Lift Control Type Position Position, Draft and Mixed control ▶ Transmission & DrivetrainTransmission Type Hydrostatic (HST) Synchronized shuttle No. of Speeds 3 ranges (hydrostatic, infinite speeds) 8F/8R Max Travel Speed (Forward) 18.45 mph 13.89 mph Max Travel Speed (Reverse) 12.92 mph 12.81 mph Clutch None (hydrostatic transmission) Dry single stage Differential Lock & Limited Slip Options Rear differential lock (standard) Rear differential lock (mechanical) ▶ Chassis, Steering & ControlsFrame Type Not Published 4x4 MFWD 4WD Steering Hydrostatic power steering Hydraulic power steering Brakes Wet multi-disc Wet disc type Seat Suspension & Adjustability Deluxe suspension seat Adjustable seat Front Axle Type Mechanical 4WD 4WD (MFWD) Front Axle Rating Not Published Not Published Drawbar Capacity 1,655 lb (max. drawbar vertical load) Not Published ▶ Dimensions & ManeuverabilityOverall Length with 3-Point Hitch 125.5 in 126.3 in Overall Width 62.8 in 56.7 in Wheelbase 71.3 in 65.7 in Ground Clearance 14.5 in 11.4 in Min. Turn Radius without Brakes 102.8 in (with brake applied) 125.9 in Height to Top of ROPS 96.8 in 92.5 in Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model 93.0 in Not Published ▶ WeightTractor Weight (Base) 3,523 lb (DK4220SEH); 4,043 lb (DK4220SEH CAB) 3,475 lb Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options R1 Agricultural, R3 Turf, R4 Industrial, R14 R1 Agricultural, R3 Turf, R4 Industrial R1 Agricultural - Front 8-16 7-16 R1 Agricultural - Rear 13.6-24 12.4-24 R3 Turf - Front 29-12.5-15 27x8.5-15 R3 Turf - Rear 21.5L-16.1 41x14-20 R4 Industrial - Front 10-16.5 27x10.5-15 R4 Industrial - Rear 14.9-24 43x16-20 ▶ Loader & AttachmentsQuick Attach Loader System Quick attach (QA) bucket, 66 in or 72 in Not Published Loader Model KL5520; KL5521 (Cab models) KL1450 Loader Lift Height KL5520: 107.7 in; KL5521: 107.7 in KL1450: 103.5 in Loader Lift Capacity (Full Height) KL5520: 2,474 lb; KL5521: 2,474 lb KL1450: 1,350 lb Loader Breakout Force KL5520: 3,895 lb; KL5521: 3,895 lb KL1450: 2,100 lb ▶ WarrantyWarranty Length & Coverage Non-commercial: 24 months, unlimited hours, parts and labor, 0% deductible; non-commercial powertrain (engine and driveline): 72 months, unlimited hours Limited: Tractors (Non-Commercial Application) 24 months parts & labor; Extended (driveline): 48 months parts & labor ▶ ITC Company AccessoriesAccessories that fit
