▶ EngineEngine Manufacturer KIOTI (Daedong) LS Mtron Engine Model 4A220 L3C19-T Engine Type Not Published Diesel, 3-cylinder, turbocharged No. of Cylinders 4 3 Displacement 134.1 in³ 115.9 in³ Rated Engine Speed 2600 rpm 2600 rpm Engine Power (Gross) 45 hp 45 hp PTO Power 38 hp 36 hp Engine Emissions Constraints Not Published Tier 4 Cooling System Type Not Published Liquid-cooled Air Cleaner Dual stage air filter cartridge Replaceable dry element Fuel System Not Published Common rail direct injection Alternator Not Published 70 A ▶ HydraulicsPump Type Not Published Not Published Implement Flow 9.9 gpm 8.2 gpm Steering Flow 4.3 gpm 5.3 gpm Total Hydraulic Flow 14.2 gpm 13.5 gpm (8.2 + 5.3, computed) Overall Hydraulic Pump Flow 14.2 gpm Not Published Hydraulic System Type Not Published Open center Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves 1 1 No. of Optional Remote Valves Not Published 2 ▶ Fluid CapacityFuel Tank Capacity 11.5 gal 10.5 gal Coolant Capacity Not Published Not Published Crankcase Capacity Not Published Not Published Transmission / Hydraulic System Capacity Not Published Not Published Front Axle Fluid Capacity Not Published Not Published ▶ PTO & HitchPTO Type Hydraulic independent Independent rear PTO, electro-hydraulic engagement PTO Rear 540 rpm 540 rpm Mid-PTO Availability Not Published Optional, 2000 rpm Category, 3-Point Hitch Category I (Category II ends optional) Category I Hitch Lift Capacity 3,968 lb Not Published Hitch Lift Capacity (at 24”) 2,987 lb 2,756 lb Lift Control Type Position, Draft and Mixed control Mechanical draft control (MDC) ▶ Transmission & DrivetrainTransmission Type Synchronized shuttle 3-range hydrostatic (optional) No. of Speeds 12F/12R 3 ranges Max Travel Speed (Forward) 15.84 mph 17.9 mph Max Travel Speed (Reverse) Not Published Not Published Clutch Dry single plate n/a (no clutch on hydrostatic) Differential Lock & Limited Slip Options Mechanical rear differential lock Mechanical differential lock ▶ Chassis, Steering & ControlsFrame Type Not Published Not Published Steering Hydraulic power steering Power steering Brakes Wet disc Wet multi-disc Seat Suspension & Adjustability Adjustable seat Deluxe seat with armrests and an adjustable backrest Front Axle Type 4WD (MFWD) Mechanical Front Drive (MFD) Front Axle Rating Not Published Not Published Drawbar Capacity Not Published Not Published ▶ Dimensions & ManeuverabilityOverall Width 61.0 in 69.1 in Wheelbase 71.6 in 73.2 in Ground Clearance 14.5 in Not Published Min. Turn Radius without Brakes 123.2 in Not Published Height to Top of ROPS 87.5 in 97.1 in Height to Top of ROPS (folded) 64.5 in 78.6 in Height to Top of Cab Model 91 in Not Applicable Overall Length 130.7 in (with 3-point hitch) 128.1 in ▶ WeightTractor Weight (Base) 3,895 lb (ag tires, ROPS) 3,770 lb Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options R1 Agricultural, R3 Turf, R4 Industrial R1 Agricultural; R3 Turf; R4 Industrial R1 Agricultural - Front 9.5-16 9.5-16 R1 Agricultural - Rear 14.9-24 13.6-24 R3 Turf - Front 29x12.5-15 28x8.50-15 R3 Turf - Rear 21.5L-16.1 41x14.00-20 R4 Industrial - Front 12x16.5 12-16.5 R4 Industrial - Rear 17.5L-24 17.5L-24 ▶ Loader & AttachmentsQuick Attach Loader System Not Published Quick-Attach faceplate; mid-mount frame for fast loader connect and disconnect (L360A) Loader Model KL249; KL1470; KL1590 L360A Loader Lift Height KL249: 107.5 in; KL1470: 111.44 in; KL1590: 121.06 in 112 in Loader Lift Capacity (Full Height) KL249: 2,050 lb; KL1470: 2,100 lb; KL1590: 2,500 lb 1,830 lb at 31.5 in. forward of pivot pin Loader Breakout Force KL249: 3,695 lb; KL1470: 3,400 lb; KL1590: 4,000 lb 3,114 lbf ▶ WarrantyWarranty Length & Coverage Not Published Basic 2 years; powertrain 4 additional years (6-year, 72-month total) ▶ ITC Company AccessoriesAccessories that fit None tagged yet
