▶ EngineEngine Manufacturer KIOTI (Daedong) LS Mtron Engine Model 4A220 L3C19-T3 Engine Type Not Published 3-cylinder, turbocharged, common-rail, liquid-cooled diesel No. of Cylinders 4 3 Displacement 134.1 in³ 114.7 in³ Rated Engine Speed 2600 rpm 2600 rpm Engine Power (Gross) 45 hp 45 hp PTO Power 38 hp XR4145, XR4145C (gear): 38.7 hp; XR4145H, XR4145HC (HST): 36 hp Engine Emissions Constraints Not Published Tier 4 Cooling System Type Not Published Water-cooled Air Cleaner Dual stage air filter cartridge Dry Fuel System Not Published CRDI (common rail direct injection) Alternator Not Published 70 A, 12 V ▶ HydraulicsPump Type Not Published Gear pump, engine driven Implement Flow 9.9 gpm XR4145, XR4145C (gear): 8.2 gpm; XR4145H, XR4145HC (HST): 7.3 gpm Steering Flow 4.3 gpm XR4145, XR4145C (gear): 4.1 gpm; XR4145H, XR4145HC (HST): 5.5 gpm Total Hydraulic Flow 14.2 gpm XR4145, XR4145C (gear): 12.3 gpm; XR4145H, XR4145HC (HST): 13.7 gpm Overall Hydraulic Pump Flow 14.2 gpm XR4145, XR4145C (gear): 12.3 gpm; XR4145H, XR4145HC (HST): 13.7 gpm Hydraulic System Type Not Published Not Published Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves 1 2 pairs No. of Optional Remote Valves Not Published 2 or 6 quick couplers (optional) ▶ Fluid CapacityFuel Tank Capacity 11.5 gal XR4145, XR4145H (ROPS): 10.6 gal; XR4145C, XR4145HC (cab): 12.4 gal Coolant Capacity Not Published 2.3 gal Crankcase Capacity Not Published 1.6 gal Transmission / Hydraulic System Capacity Not Published 11.4 gal Front Axle Fluid Capacity Not Published 2.1 gal ▶ PTO & HitchPTO Type Hydraulic independent Independent PTO Rear 540 rpm 540 rpm (3-speed 540/750/1000 optional) Mid-PTO Availability Not Published Optional, 2000 rpm Category, 3-Point Hitch Category I (Category II ends optional) Category I Hitch Lift Capacity 3,968 lb 2,755 lb Hitch Lift Capacity (at 24”) 2,987 lb 2,469 lb Lift Control Type Position, Draft and Mixed control Position and draft control ▶ Transmission & DrivetrainTransmission Type Synchronized shuttle XR4145, XR4145C (gear): Synchro shuttle; XR4145H, XR4145HC (HST): HST No. of Speeds 12F/12R XR4145, XR4145C (gear): F16 x R16; XR4145H, XR4145HC (HST): 3 ranges (HST) Max Travel Speed (Forward) 15.84 mph Not Published Max Travel Speed (Reverse) Not Published Not Published Clutch Dry single plate Mechanical: dry single clutch; HST: not applicable Differential Lock & Limited Slip Options Mechanical rear differential lock Mechanical differential lock (pedal) ▶ Chassis, Steering & ControlsFrame Type Not Published Not Published Steering Hydraulic power steering Hydrostatic power steering Brakes Wet disc Wet, multi-disc Seat Suspension & Adjustability Adjustable seat Not Published Front Axle Type 4WD (MFWD) Not Published Front Axle Rating Not Published Not Published Drawbar Capacity Not Published Not Published ▶ Dimensions & ManeuverabilityOverall Width 61.0 in 62.5 in Wheelbase 71.6 in 73.2 in Ground Clearance 14.5 in Not Published Min. Turn Radius without Brakes 123.2 in 9.5 ft (with brake applied) Height to Top of ROPS 87.5 in 93 in Height to Top of ROPS (folded) 64.5 in Not Published Height to Top of Cab Model 91 in 88.1 in Overall Length 130.7 in (with 3-point hitch) 133 in (bumper to link) ▶ WeightTractor Weight (Base) 3,895 lb (ag tires, ROPS) ROPS: 3,770 lb; Cab: 4,210 lb Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options R1 Agricultural, R3 Turf, R4 Industrial Ag, industrial or turf tires at no additional cost R1 Agricultural - Front 9.5-16 9.5-16 R1 Agricultural - Rear 14.9-24 13.6-24 R3 Turf - Front 29x12.5-15 28x8.5-15 R3 Turf - Rear 21.5L-16.1 41x14-20 R4 Industrial - Front 12x16.5 12-16.5 R4 Industrial - Rear 17.5L-24 17.5L-24 ▶ Loader & AttachmentsQuick Attach Loader System Not Published LL4104: quick attach, skid steer compatible Loader Model KL249; KL1470; KL1590 LL4104 Loader Lift Height KL249: 107.5 in; KL1470: 111.44 in; KL1590: 121.06 in LL4104: 96.3 in Loader Lift Capacity (Full Height) KL249: 2,050 lb; KL1470: 2,100 lb; KL1590: 2,500 lb LL4104: 2,713 lb (at pivot pin) Loader Breakout Force KL249: 3,695 lb; KL1470: 3,400 lb; KL1590: 4,000 lb LL4104: 3,802 lb (at pivot pin) ▶ WarrantyWarranty Length & Coverage Not Published 5-year limited warranty ▶ ITC Company AccessoriesAccessories that fit None tagged yet
