▶ EngineEngine Manufacturer KIOTI (Daedong) LS Mtron Engine Model 3HT-TM4B L3C19-T Engine Type 3-cylinder, turbocharged, common-rail, liquid-cooled diesel Diesel, 3-cylinder, turbocharged No. of Cylinders 3 3 Displacement 111.4 in³ 115.9 in³ Rated Engine Speed 2600 rpm 2600 rpm Engine Power (Gross) 44.9 hp 45 hp PTO Power 41.6 hp 36 hp Engine Emissions Constraints Tier 4 Tier 4 Cooling System Type Water-cooled Liquid-cooled Air Cleaner Not Published Replaceable dry element Fuel System Common Rail Direct Injection (CRDI) Common rail direct injection Alternator Not Published 70 A ▶ HydraulicsPump Type Gear Not Published Implement Flow Not Published 8.2 gpm Steering Flow Not Published 5.3 gpm Total Hydraulic Flow 14.5 gpm 13.5 gpm (8.2 + 5.3, computed) Overall Hydraulic Pump Flow 14.5 gpm Not Published Hydraulic System Type Open center Open center Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves None 1 No. of Optional Remote Valves 2 2 ▶ Fluid CapacityFuel Tank Capacity 11.9 gal 10.5 gal Coolant Capacity Not Published Not Published Crankcase Capacity Not Published Not Published Transmission / Hydraulic System Capacity Not Published Not Published Front Axle Fluid Capacity Not Published Not Published ▶ PTO & HitchPTO Type Independent Independent rear PTO, electro-hydraulic engagement PTO Rear 540 rpm 540 rpm Mid-PTO Availability Not Published Optional, 2000 rpm Category, 3-Point Hitch Category I Category I Hitch Lift Capacity Not Published Not Published Hitch Lift Capacity (at 24”) 2,716 lb 2,756 lb Lift Control Type Position Mechanical draft control (MDC) ▶ Transmission & DrivetrainTransmission Type Synchronized shuttle 3-range hydrostatic (optional) No. of Speeds 8F/8R 3 ranges Max Travel Speed (Forward) 17.3 mph 17.9 mph Max Travel Speed (Reverse) 16.9 mph Not Published Clutch Dry type, single stage n/a (no clutch on hydrostatic) Differential Lock & Limited Slip Options Rear differential lock (standard) Mechanical differential lock ▶ Chassis, Steering & ControlsFrame Type Not Published Not Published Steering Hydrostatic power steering Power steering Brakes Wet multi disc Wet multi-disc Seat Suspension & Adjustability Adjustable suspension seat Deluxe seat with armrests and an adjustable backrest Front Axle Type Mechanical 4WD Mechanical Front Drive (MFD) Front Axle Rating Not Published Not Published Drawbar Capacity Not Published Not Published ▶ Dimensions & ManeuverabilityOverall Width 62.8 in 69.1 in Wheelbase 71.3 in 73.2 in Ground Clearance 14.5 in Not Published Min. Turn Radius without Brakes 8.6 ft (with brake applied) Not Published Height to Top of ROPS 92.0 in 97.1 in Height to Top of ROPS (folded) Not Published 78.6 in Height to Top of Cab Model Not Published Not Applicable Overall Length 124.3 in (with 3-point hitch) 128.1 in ▶ WeightTractor Weight (Base) 3,373 lb 3,770 lb Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options Not Published R1 Agricultural; R3 Turf; R4 Industrial R1 Agricultural - Front 8-16 9.5-16 R1 Agricultural - Rear 13.6-24 13.6-24 R3 Turf - Front 29-12.5-15 28x8.50-15 R3 Turf - Rear 21.5L-16.1 41x14.00-20 R4 Industrial - Front 10-16.5 12-16.5 R4 Industrial - Rear 14.9-24 17.5L-24 ▶ Loader & AttachmentsQuick Attach Loader System Quick attach (QA) bucket, 66 in / 72 in Quick-Attach faceplate; mid-mount frame for fast loader connect and disconnect (L360A) Loader Model KL5520 L360A Loader Lift Height KL5520: 105.7 in (to pivot pin) 112 in Loader Lift Capacity (Full Height) KL5520: 2,474 lb (at pivot pins) 1,830 lb at 31.5 in. forward of pivot pin Loader Breakout Force KL5520: 3,895 lb (at pivot pins) 3,114 lbf ▶ WarrantyWarranty Length & Coverage Not Published Basic 2 years; powertrain 4 additional years (6-year, 72-month total) ▶ ITC Company AccessoriesAccessories that fit None tagged yet
