▶ EngineEngine Manufacturer KIOTI (Daedong) Mahindra Engine Model 3HT-TM4B DH45 Engine Type 3-cylinder, liquid-cooled diesel Four-stroke, naturally aspirated, direct injection, water cooled diesel No. of Cylinders 3 4 Displacement 111.4 in³ 166.2 in³ Rated Engine Speed 2600 rpm 2300 rpm Engine Power (Gross) 44.9 hp 45 hp PTO Power 38.9 hp 38 hp Engine Emissions Constraints Tier 4 Tier 4 Cooling System Type Liquid-cooled Water-cooled Air Cleaner Not Published Not Published Fuel System Not Published Direct injection Alternator Not Published 55 A ▶ HydraulicsPump Type Gear Not Published Implement Flow 9.62 gpm 8.71 gpm Steering Flow 4.94 gpm 4.62 gpm Total Hydraulic Flow 14.56 gpm 13.3 gpm Overall Hydraulic Pump Flow 14.56 gpm 13.3 gpm Hydraulic System Type Not Published Open center Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves 0 (2 optional) 1 No. of Optional Remote Valves 2 1 ▶ Fluid CapacityFuel Tank Capacity 11.9 gal 17.1 gal Coolant Capacity 0.89 gal Not Published Crankcase Capacity 1.95 gal Not Published Transmission / Hydraulic System Capacity 11.4 gal Not Published Front Axle Fluid Capacity 1.48 gal Not Published ▶ PTO & HitchPTO Type Independent Independent PTO Rear 540 rpm 540 rpm @ 2300 engine rpm; 540E rpm @ 1725 engine rpm Mid-PTO Availability No mid PTO (N/A) Not Published Category, 3-Point Hitch Category I CAT I & II with telescopic stabilizers & flex links Hitch Lift Capacity 2,998 lb Not Published Hitch Lift Capacity (at 24”) 2,716 lb 3748 lb Lift Control Type Position Position control ▶ Transmission & DrivetrainTransmission Type Synchronized shuttle Full synchromesh with forward/reverse synchro shuttle & constant mesh range No. of Speeds 8F/8R 12F / 12R Max Travel Speed (Forward) 16.71 mph 17.9 mph Max Travel Speed (Reverse) 16.28 mph Not Published Clutch Dry single stage Dual dry with cerametallic lining Differential Lock & Limited Slip Options Rear differential lock (standard) Not Published ▶ Chassis, Steering & ControlsFrame Type Not Published Not Published Steering Hydrostatic power steering Hydrostatic power steering with tilt steering wheel Brakes Wet multi-disc Fully-enclosed, 7-in diameter, dry disc Seat Suspension & Adjustability Deluxe suspension seat Adjustable seat with contoured cushions, armrests and a soft-coil suspension Front Axle Type Mechanical 4WD Not Published Front Axle Rating Not Published Not Published Drawbar Capacity 1,655 lb (max. drawbar vertical load) Not Published ▶ Dimensions & ManeuverabilityOverall Length with 3-Point Hitch 124.3 in 136.6 in Overall Width 62.8 in 74.8 in Wheelbase 71.3 in 77.9 in Ground Clearance 14.5 in 15.2 in Min. Turn Radius without Brakes 102.8 in (with brake applied) 10.8 ft Height to Top of ROPS 96.8 in Not Published Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model Not Published Not Published ▶ WeightTractor Weight (Base) 3,373 lb 5390 lb Weight with ROPS and Loader Not Published 6,690 lb Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options R1 Agricultural, R3 Turf, R4 Industrial, R14 R1 Agricultural or R4 Industrial R1 Agricultural - Front 8-16 9.5 x 20 R1 Agricultural - Rear 13.6-24 14.9 x 28 R3 Turf - Front 29-12.5-15 Not Published R3 Turf - Rear 21.5L-16.1 Not Published R4 Industrial - Front 10-16.5 10.5/80 x 18 R4 Industrial - Rear 14.9-24 16.9 x 24 ▶ Loader & AttachmentsQuick Attach Loader System Quick attach (QA) bucket, 66 in or 72 in Skid-steer style quick-attach coupler Loader Model KL5520 5155-4L (front loader); 65B (rear backhoe) Loader Lift Height KL5520: 107.7 in 5155-4L: 122 in Loader Lift Capacity (Full Height) KL5520: 2,474 lb 5155-4L: 3,100 lb Loader Breakout Force KL5520: 3,895 lb 5155-4L: 5,200 lb ▶ WarrantyWarranty Length & Coverage Non-commercial: 24 months, unlimited hours, parts and labor, 0% deductible; non-commercial powertrain (engine and driveline): 72 months, unlimited hours 5-year limited powertrain warranty ▶ ITC Company AccessoriesAccessories that fit None tagged yet
