▶ EngineEngine Manufacturer KIOTI (Daedong) LS Mtron Engine Model 3HT-TM4B L3CRV-T9A Engine Type 3-cylinder, liquid-cooled diesel 3-cylinder, turbocharged, liquid-cooled diesel No. of Cylinders 3 3 Displacement 111.4 in³ 114.7 in³ Rated Engine Speed 2600 rpm 2600 rpm Engine Power (Gross) 44.9 hp 45 hp PTO Power 38.9 hp Gear: 38.2 hp; HST: 36 hp Engine Emissions Constraints Tier 4 Tier 4 Cooling System Type Liquid-cooled Liquid cooled Air Cleaner Not Published Replaceable primary and inner elements Fuel System Not Published Electronically controlled common rail direct injection Alternator Not Published ROPS: 70 A, 12 V; Cab: 85 A, 12 V ▶ HydraulicsPump Type Gear Gear Implement Flow 9.62 gpm 8.2 gpm Steering Flow 4.94 gpm Gear: 4.2 gpm; HST: 5.3 gpm Total Hydraulic Flow 14.56 gpm Gear: 12.4 gpm; HST: 13.5 gpm Overall Hydraulic Pump Flow 14.56 gpm Gear: 12.4 gpm; HST: 13.5 gpm Hydraulic System Type Not Published Open center Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves 0 (2 optional) 1 No. of Optional Remote Valves 2 Up to 2 (second valve optional) ▶ Fluid CapacityFuel Tank Capacity 11.9 gal ROPS: 10.5 gal; Cab: 12.4 gal Coolant Capacity 0.89 gal 2.3 gal Crankcase Capacity 1.95 gal 5.8 qt Transmission / Hydraulic System Capacity 11.4 gal 11.4 gal Front Axle Fluid Capacity 1.48 gal 2.2 gal ▶ PTO & HitchPTO Type Independent Independent, electro-hydraulic engagement PTO Rear 540 rpm 540 rpm Mid-PTO Availability No mid PTO (N/A) Standard (2000 rpm) Category, 3-Point Hitch Category I Category I Hitch Lift Capacity 2,998 lb 2,756 lb Hitch Lift Capacity (at 24”) 2,716 lb 2,116 lb Lift Control Type Position Position control (draft control optional) ▶ Transmission & DrivetrainTransmission Type Synchronized shuttle Gear: 16x16 synchronized shuttle shift (SSS); HST: 3-range hydrostatic, dual pedal No. of Speeds 8F/8R Gear: 16F/16R; HST: 3-range Max Travel Speed (Forward) 16.71 mph Gear: 17.0 mph; HST: 17.9 mph Max Travel Speed (Reverse) 16.28 mph Gear: 15.3 mph; HST: 11.37 mph Clutch Dry single stage Gear: dry single disc (10.8 in); HST: n/a Differential Lock & Limited Slip Options Rear differential lock (standard) Mechanical rear differential lock (pedal) ▶ Chassis, Steering & ControlsFrame Type Not Published Not Published Steering Hydrostatic power steering Power steering Brakes Wet multi-disc Wet multi-disc Seat Suspension & Adjustability Deluxe suspension seat ROPS: adjustable suspension seat (fore/aft, weight and height adjustment); Cab: cloth suspension seat with weight control, fore/aft adjustment and adjustable armrests Front Axle Type Mechanical 4WD Four-wheel drive (FWD) Front Axle Rating Not Published Not Published Drawbar Capacity 1,655 lb (max. drawbar vertical load) Short position: 2,317 lb; Regular position: 1,598 lb; Extended position: 1,091 lb ▶ Dimensions & ManeuverabilityOverall Length with 3-Point Hitch 124.3 in 128.1 in Overall Width 62.8 in 69.1 in Wheelbase 71.3 in 73.2 in Ground Clearance 14.5 in 15 in Min. Turn Radius without Brakes 102.8 in (with brake applied) 111.8 in (right turn); 123.2 in (left turn) (with brake applied) Height to Top of ROPS 96.8 in 97.1 in Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model Not Published 94 in ▶ WeightTractor Weight (Base) 3,373 lb ROPS Gear: 3,424 lb; ROPS HST: 3,490 lb; Cab: 4,194 lb Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options R1 Agricultural, R3 Turf, R4 Industrial, R14 R1 Agricultural, R3 Turf, R4 Industrial R1 Agricultural - Front 8-16 9.5-16 R1 Agricultural - Rear 13.6-24 13.6-24 R3 Turf - Front 29-12.5-15 28x8.50-15 R3 Turf - Rear 21.5L-16.1 41x14.00-20 R4 Industrial - Front 10-16.5 12x16.5 R4 Industrial - Rear 14.9-24 17.5Lx24 ▶ Loader & AttachmentsQuick Attach Loader System Quick attach (QA) bucket, 66 in or 72 in New Holland Quick Mount loader; optional skid steer quick attach plates Loader Model KL5520 260TLA Loader Lift Height KL5520: 107.7 in 260TLA: 109 in Loader Lift Capacity (Full Height) KL5520: 2,474 lb 260TLA: 2,371 lb Loader Breakout Force KL5520: 3,895 lb 260TLA: 4,081 lb ▶ WarrantyWarranty Length & Coverage Non-commercial: 24 months, unlimited hours, parts and labor, 0% deductible; non-commercial powertrain (engine and driveline): 72 months, unlimited hours Boomer Guard6 limited warranty: 2 years/750 hours full coverage plus 4 more years of powertrain coverage (6 years/1,500 hours total) ▶ ITC Company AccessoriesAccessories that fit None tagged yet
