▶ EngineEngine Manufacturer KIOTI Mahindra Engine Model 3HT-TH4C Not Published Engine Type 3-cylinder, liquid-cooled diesel 5145: naturally aspirated, direct injection, liquid-cooled diesel; 5155: turbocharged, direct injection, liquid-cooled diesel No. of Cylinders 3 4 Displacement 111.4 in³ 166.2 in³ Rated Engine Speed 2600 rpm 2300 rpm Engine Power (Gross) 44.9 hp 45 hp PTO Power 33.4 hp 38 hp Engine Emissions Constraints Tier 4 Not Published Cooling System Type Liquid-cooled Not Published Air Cleaner Dry element Not Published Fuel System Not Published Not Published Alternator Not Published 55 A, 12 V ▶ HydraulicsPump Type Gear Open center; adjustable lower links with stabilizer Implement Flow 9.62 gpm 8.71 gpm Steering Flow 6.87 gpm 4.62 gpm Total Hydraulic Flow 16.5 gpm Not Published Overall Hydraulic Pump Flow 16.5 gpm Not Published Hydraulic System Type Not Published Open center Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves Not Published 1 No. of Optional Remote Valves Not Published 1 (optional second rear valve) ▶ Fluid CapacityFuel Tank Capacity 12.7 gal 17.1 gal Coolant Capacity 2.1 gal Not Published Crankcase Capacity 1.95 gal Not Published Transmission / Hydraulic System Capacity 11.4 gal Not Published Front Axle Fluid Capacity 1.48 gal Not Published ▶ PTO & HitchPTO Type Independent Independent PTO Rear 540 rpm 540 rpm @ 2300 rpm; 540E @ 1725 rpm Mid-PTO Availability Optional (2,000 rpm) Not Published Category, 3-Point Hitch Category I CAT I & II w/ Telescopic Stabilizers & Flex Links Hitch Lift Capacity 2,998 lb (at lower link ball) 3,748 lb Hitch Lift Capacity (at 24”) 2,716 lb Not Published Lift Control Type Position Not Published ▶ Transmission & DrivetrainTransmission Type Hydrostatic (HST) Full synchromesh with forward/reverse synchro shuttle and constant-mesh range No. of Speeds 3 ranges (hydrostatic, infinite speeds) 12F / 12R Max Travel Speed (Forward) 18.45 mph Not Published Max Travel Speed (Reverse) 12.92 mph Not Published Clutch None (hydrostatic transmission) Dual Dry with Cerametallic Lining Differential Lock & Limited Slip Options Rear differential lock (standard) Not Published ▶ Chassis, Steering & ControlsFrame Type Not Published Not Published Steering Hydrostatic power steering Tilt, power-assisted steering Brakes Wet multi-disc Fully-enclosed, 7-in Diameter, Dry Disc Seat Suspension & Adjustability Deluxe suspension seat Not Published Front Axle Type Mechanical 4WD Not Published Front Axle Rating Not Published Not Published Drawbar Capacity 1,655 lb (max. drawbar vertical load) Not Published ▶ Dimensions & ManeuverabilityOverall Length with 3-Point Hitch 125.5 in Not Published Overall Width 62.8 in Not Published Wheelbase 71.3 in 77.9 in Ground Clearance 14.5 in 5145: 15.2 in; 5155: 16.4 in Min. Turn Radius without Brakes 102.8 in (with brake applied) 10.8 ft Height to Top of ROPS 96.8 in 60.6 in Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model 93.0 in Not Published ▶ WeightTractor Weight (Base) 3,523 lb (DK4720SEH); 4,025 lb (DK4720SEH CAB) 5,390 lb Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options Agricultural, Industrial, Turf, R14 Not Published R1 Agricultural - Front 8-16 9.5 x 20 R1 Agricultural - Rear 13.6-24 14.9 x 28 R3 Turf - Front 29-12.5-15 Not Published R3 Turf - Rear 21.5L-16.1 Not Published R4 Industrial - Front 10-16.5 10.5/80x18 R4 Industrial - Rear 14.9-24 16.9 x 24 ▶ Loader & AttachmentsQuick Attach Loader System Quick attach (QA) bucket, 66 in or 72 in Not Published Loader Model KL5520; KL5521 (Cab models) 5155-4L Loader Lift Height KL5520: 107.7 in (to pivot point); KL5521: 107.7 in (to pivot point) 5155-4L: 122 in Loader Lift Capacity (Full Height) KL5520: 2,474 lb (at pivot pins); KL5521: 2,474 lb (at pivot pins) 5155-4L: 3,100 lb Loader Breakout Force KL5520: 3,895 lb (at pivot pins); KL5521: 3,895 lb (at pivot pins) 5155-4L: 5,200 lb ▶ WarrantyWarranty Length & Coverage Non-commercial: basic 24 months, unlimited hours, parts and labor, 0% deductible; powertrain 72 months, unlimited hours 5-year, 3000-hour limited powertrain warranty ▶ ITC Company AccessoriesAccessories that fit None tagged yet
