▶ EngineEngine Manufacturer KIOTI (Daedong) KIOTI Engine Model 4A200T 3HT-S4TH50A Engine Type Turbocharged diesel 3-cylinder, in-line vertical, water-cooled, 4-cycle turbo diesel, CRDI No. of Cylinders 4 3 Displacement 122 in³ 111.4 in³ Rated Engine Speed 2600 rpm 2600 rpm Engine Power (Gross) 49 hp 50.3 hp PTO Power 41.5 hp 41.8 hp Engine Emissions Constraints Not Published Tier 4 Cooling System Type Not Published Water-cooled Air Cleaner Dual stage air filter cartridge Dry element Fuel System Not Published Common Rail Diesel (CRDI) Alternator Not Published Not Published ▶ HydraulicsPump Type Not Published Gear Implement Flow 9.9 gpm 9.61 gpm Steering Flow 4.3 gpm 6.87 gpm Total Hydraulic Flow 14.2 gpm 16.5 gpm Overall Hydraulic Pump Flow 14.2 gpm 16.5 gpm Hydraulic System Type Open center Open Center Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves 1 1 No. of Optional Remote Valves Not Published 1 ▶ Fluid CapacityFuel Tank Capacity 11.5 gal 13.2 gal Coolant Capacity Not Published 2.03 gal Crankcase Capacity Not Published 1.95 gal Transmission / Hydraulic System Capacity Not Published 9.51 gal Front Axle Fluid Capacity Not Published 2.25 gal ▶ PTO & HitchPTO Type Hydraulic independent Independent PTO Rear 540 rpm 540 rpm Mid-PTO Availability Not Published Optional (2,000 rpm) Category, 3-Point Hitch Category I (Category II ends optional) Category I Hitch Lift Capacity Not Published 2,940 lb Hitch Lift Capacity (at 24”) 2,828 lb 2,493 lb Lift Control Type Position, Draft and Mixed control Position with Draft Control ▶ Transmission & DrivetrainTransmission Type Synchronized shuttle Hydrostatic No. of Speeds 12F/12R 3-Range Max Travel Speed (Forward) 15.84 mph 17.5 mph Max Travel Speed (Reverse) Not Published 12.2 mph Clutch Dry single plate Not Published Differential Lock & Limited Slip Options Mechanical rear differential lock Mechanical differential lock: rear standard ▶ Chassis, Steering & ControlsFrame Type Not Published Not Published Steering Hydraulic power steering Hydrostatic Power Steering Brakes Wet disc Wet disc type Seat Suspension & Adjustability Adjustable seat Deluxe suspension seat Front Axle Type 4WD (MFWD) Not Published Front Axle Rating Not Published Not Published Drawbar Capacity Not Published Not Published ▶ Dimensions & ManeuverabilityOverall Width 61.0 in 67.1 in Wheelbase 71.6 in 75.5 in Ground Clearance 14.5 in 13.4 in Min. Turn Radius without Brakes 125.2 in 11.0 ft (with brake applied) Height to Top of ROPS 88 in 98.4 in Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model 91 in Not Published Overall Length 130.7 in (with 3-point hitch) 136.4 in (with 3-point hitch) ▶ WeightTractor Weight (Base) 3,813 lb (with ag tires) 4,027 lb (with AG tires) Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options R1 Agricultural, R3 Turf, R4 Industrial Agricultural, Turf, Industrial R1 Agricultural - Front 9.5-16 8-16 R1 Agricultural - Rear 14.9-24 13.6-24 R3 Turf - Front 29x12.5-15 29-12.5-15 R3 Turf - Rear 21.5L-16.1 21.5L-16.1 R4 Industrial - Front 12x16.5 10-16.5 R4 Industrial - Rear 17.5L-24 14.9-24 ▶ Loader & AttachmentsQuick Attach Loader System Not Published Built-in parking stand; quick attach/detach; single-lever joystick control with float; bucket level indicator Loader Model KL1470; KL1590 KL5810 Loader Lift Height KL1470: 111.44 in; KL1590: 121.06 in KL5810: 106.3 in (to pivot pin) Loader Lift Capacity (Full Height) KL1470: 2,100 lb; KL1590: 2,500 lb KL5810: 2,621 lb (at pivot pin) Loader Breakout Force KL1470: 3,400 lb; KL1590: 4,000 lb KL5810: 3,896 lb (at pivot pin) ▶ WarrantyWarranty Length & Coverage Not Published Non-commercial: basic 24 months, powertrain 72 months, unlimited hours, parts and labor ▶ ITC Company AccessoriesAccessories that fit None tagged yet
